Summary of Contents for Goblin GSV303R-21
- Page 1 GSV303R-21 Corded stick vacuum User Guide 220-240V~50-60Hz, 450W IMPORTANT: RETAIN FOR FUTURE REFERENCE...
-
Page 2: About This Guide
About this guide We’re here to help you get the most from your corded stick vacuum, so please keep hold of this manual for future use. WARNINGS: THIS PRODUCT WAS DESIGNED AND MANUFACTURED TO MEET STRICT QUALITY AND SAFETY STANDARDS. THERE ARE, HOWEVER, SOME OPERATIONAL PRECAUTIONS YOU SHOULD BE AWARE OF. - Page 3 12. Ensure you assemble the stick vac correctly before use. 13. Do not use attachments not recommended by the manufacturer. 14. Always disconnect the appliance from the power supply before assembling, disassembling or cleaning. 15. This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or...
- Page 4 25. DO NOT use the stick vac to suck up large objects or objects that are likely to damage the vacuum cleaner. 26. DO NOT attempt to vacuum long hair, string, pieces of cloth etc., as these may clog the vacuum cleaner. 27.
-
Page 5: What's In The Box
AUTOMATIC THERMAL CUT OUT A safety thermostat inside the cleaner protects the motor from overheating if the airways or filters are clogged. If the stick vac suddenly stops working during operation, switch off and unplug immediately. Allow the motor to cool for an hour, empty the dust canister and thoroughly clean the filters and airways. - Page 6 Features Carry handle Mount hook Main body Power on/off button Dust canister Dust canister release button Extension pole Release clip Power cord Floor head Plug...
- Page 7 Assembling/disassembling and using the stick vac Before assembling or disassembling attachments, ensure the stick vac is not plugged into the mains supply and is switched off. 1. Align the top of the extension pole with the bottom of the stick vac main body and push up until the extension pole clicks into place.
- Page 8 4. Turn the stick vac on by pushing the power on/off switch downwards. 5. Move the floor head back and forth over the surface. Use even strokes. Don’t press hard; allow the floor head to suck away the debris. 6. When finished turn off the power on the vac and to the mains supply.
- Page 9 3. Align the main body with the top of the floor head and push down until it clicks into place. Turn on the power. This set up is useful when cleaning stairs or sofas. When finished turn the power off on the stick vac and at the mains supply.
- Page 10 Removing and emptying the dust canister Ensure the stick vac is switched off before emptying the dust canister. As a tip, it is easier to remove the dust canister without any attachments on the vac. 1. Press the dust canister release button located underneath the dust canister (1) and pull away from the main body, keeping the...
-
Page 11: Cleaning The Filters
Cleaning the filters Before starting any cleaning, ensure the stick vac is not plugged into the mains supply and is switched off. 1. Remove the dust canister and filter assembly and empty as shown in the ‘Removing and emptying the dust canister’... -
Page 12: Clearing A Blockage
It is important to regularly maintain and clean the filters. A clogged filter reduces suction power and can shorten the life of your stick vac. Below is a recommended guide for how often you should clean the filters: Filter Type Recommended cleaning times •... - Page 13 Storing the stick vac Your stick vac can be stored safely and securely by hanging from the wall mount supplied with your product or by removing all the attachments and stowing together in a cupboard. Either way will help avoid the product falling over and causing damage.
- Page 14 Storing the stick vac with the wall mount 1. Find a suitable spot in your household where you’d like to secure your stick vac. 2. Mark the desired screw hole positions on the wall using a pencil. We recommend that the stick vac hangs slightly lifted off the floor.
- Page 15 ASDA,Leeds LS11 5AD any problems, please contact customer services at the telephone number or address shown opposite. Product name: GSV303R-21 Corded stick vac N.B. When calling or writing please Product site code: 15A.09.22.229 quote the product site code.
- Page 16 Copyright Disposal © 2020 ASDA Stores Limited. This symbol on the product or in the instructions means that your electrical and All other trademarks appearing herein are electronic equipment should be disposed the property of their representative owners. at the end of its life separately from your Specifications are subject to change household waste.
