NOTE: At the end of a charging session, always disconnect the cable from the vehicle
before disconnecting from the charger.
Operating instructions for this charger are shown on the unit fascia. For more detail, refer
to the EV Driver App User Guide included within the charger packaging.

VendElectric EV Driver Application

The VendElectric EV Driver Application is a free download for use with smartphones
running Google Android or Apple IOS. The application may be downloaded from Google
Play or the Apple App Store.
Alternatively, the application can be used via a web browser.
https://app.vendelectric.com
For operation of the system using the online application, please refer to the EV Driver App
User Guide included within the charger packaging.

Status Indicator Guide

Flashing blue light
Flashing green light
Fixed blue light
Fixed green light
Fixed red light
Flashing red light
No light
1. Make sure the status indicator shows that the unit is ready to charge.
2. Connect the charging cable to the charger.
3. Connect the other end of the cable to the vehicle
4. Use the mobile application to start the charge session.
5. Alternatively use an RFID card/fob to start the charge session.
The charger will issue a 'beep' sound to indicate the card has been recognised
and accepted.
6. Make sure the status indicator changes to a fixed green light.
Quantum:EV OpenCharge
Page 19 of 25
Socket Available.
Socket Available for 'Plug and Go' charging
(optional feature to be activated by the Host).
Cable plugged in but not charging.
Charge in progress.
Potential earth leak fault detected by the 6mA DC device.
Potential Communications Fault.
No power to the unit or the breaker within the unit has
tripped and needs to be reset.
