CARAVAN
HOOK-UPS &
DIRECT
CONNECTION
INSTALLATION
& OPERATION MANUAL
MODELS:
LSHU0010
LSDC0110
LSHU0015
LSDC0120
LSHU0020
LSDC0130
LSHU0025
LSDC0210
LSHU0030
LSDC0220
LSHU0040
LSDC0230
LSHU0045
LSHU0040-10A
LSHU0110-10A
LSHU0110
LSHU0115
LSHU0120-10A
LSHU0120
LSHU0130-10A
LSHU0125
LSHU0140-10A
LSHU0130
LSHU0020-6A
LSHU0140
LSHU0010-10A
LSHU0210
LSHU0020-10A
LSHU0215
LSHU0030-10A
Installation & Operation Manual
ROECUIDM-01-V01-R0 June 2022
UNITS

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Caravan LSHU0010 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for ROLEC Caravan LSHU0010

  • Page 1 CARAVAN HOOK-UPS & DIRECT CONNECTION UNITS INSTALLATION & OPERATION MANUAL MODELS: LSHU0010 LSDC0110 LSHU0015 LSDC0120 LSHU0020 LSDC0130 LSHU0025 LSDC0210 LSHU0030 LSDC0220 LSHU0040 LSDC0230 LSHU0045 LSHU0040-10A LSHU0110-10A LSHU0110 LSHU0115 LSHU0120-10A LSHU0120 LSHU0130-10A LSHU0125 LSHU0140-10A LSHU0130 LSHU0020-6A LSHU0140 LSHU0010-10A LSHU0210 LSHU0020-10A LSHU0215 LSHU0030-10A Installation &...
  • Page 2 Date Published: June 2022 Rolec Services Ltd are the publishers of this document and own the rights to use the text, images and all technical content contained within. Content supplied by third parties / partner organisations remains the property of that organisation and is used by agreement with the supplier.
  • Page 3: Table Of Contents

    Safety Contents Safety Safety Advice within this Manual Product Overview Specifications Hook-Up Units (Interlocked) Hook-up Unit Schematics (Interlocked) Direct Connection Units Direct Connection Unit Schematics Certifications and Compliances Labelling Installation Before Installation Install the Unit If a mounting post is supplied: If a mounting post is not supplied: Security Operation...
  • Page 4: Safety

    Safety Safety This manual is specifically applicable to the Rolec Caravan Hook-ups and Direct Connection units listed on page 1 and is provided as a guide to their installation and use. NOTE: This manual covers a variety of Hook-Up Units. Not all features described will apply to all models.
  • Page 5: Product Overview

    Product Overview Product Overview Rolec Caravan Hook-ups and Direct Connection Units are available in a variety of models and power ratings. Specifications Input Voltage 220 to 250 VAC / 50 Hz (Single Phase) Enclosure Material Polycarbonate (UV stabilised) Operating Temp -25°C to +60°C...
  • Page 6 Product Overview Figure 2 Large Enclosure Dimensions NOTE: Direct Connection Units have the same enclosure dimensions as socketed Hook- ups (minus the socket dimensions). ROECUIDM-01-V01-R0 Installation and Operation Manual Outdoor Electrical Connection Units Page 5 of 20 June 2022...
  • Page 7: Hook-Up Units (Interlocked)

    Product Overview Hook-Up Units (Interlocked) Product Code Edition - Socket Units 1 WAY LSHU0010 1 Way 16A Hook-Up Unit LSHU0010-10A 1 Way 16A / 10A Hook-Up Unit LSHU0015 1 Way 32A Hook-Up Unit LSHU0110 1 Way 16A Metered Hook-Up Unit LSHU0110-10A 1 Way 16A / 10A Metered Hook-Up Unit LSHU0115...
  • Page 8: Hook-Up Unit Schematics (Interlocked)

    Product Overview Hook-up Unit Schematics (Interlocked) NOTE: In accordance with the specific power rating of the unit, individual components may differ to those shown. Cable routing and connections are as shown. IMPORTANT: Installers must make sure to use the correct type of Unit in accordance with the requirements of the location.
  • Page 9 Product Overview LSHU0020 LSHU0120 LSHU0020-6A LSHU0120-10A LSHU0020-10A LSHU0125 LSHU0025 LSHU0030 LSHU0030-10A Outdoor Electrical Connection Units ROECUIDM-01-V01-R0 Installation and Operation Manual Page 8 of 20 June 2022...
  • Page 10 Product Overview LSHU0130 LSHU0130-10A LSHU0040 LSHU0040-10A LSHU0045 ROECUIDM-01-V01-R0 Installation and Operation Manual Outdoor Electrical Connection Units Page 9 of 20 June 2022...
  • Page 11 Product Overview LSHU0140 LSHU0140-10A Outdoor Electrical Connection Units ROECUIDM-01-V01-R0 Installation and Operation Manual Page 10 of 20 June 2022...
  • Page 12: Direct Connection Units

    Product Overview Direct Connection Units Product Code Direct Connection Units kWh Metered LSDC0110 1 x 16A 230V Metered Direct Connection Unit LSDC0120 1 x 32A 230V Metered Direct Connection Unit LSDC0130 1 x 63A 230V Metered Direct Connection Unit LSDC0210 1 x 16A 230V Smartcard Metered Direct Connection Unit LSDC0220 1 x 32A 230V Smartcard Metered Direct Connection Unit...
  • Page 13: Certifications And Compliances

    Product Overview LSDC0210 LSDC0230 LSDC0220 Certifications and Compliances This product has been designed and built in accordance with the following standards and legislation: Enclosure EN 60670-1, EN 60670-22 Wiring Regulations 18th Edition BS7671:2018+A1:2020 (where applicable) Flame Retardance IEC 60695-2-11:2014 Low Voltage (LVD) The Low Voltage Directive (2014/35/EU) The Electrical Equipment (Safety) Regulations 2016 (SI 2016/1101)
  • Page 14: Labelling

    Labelling Labelling Users must observe the information given on labels to ensure safe use of the product. Labels may be in the form of adhesive ‘stickers’, plates, and/or moulded into the surface of components. Figure 3 Typical Product Label(s) Figure 4 Typical Smartcard Meter Label NOTE: Labels may vary depending on the model.
  • Page 15: Installation

    Installation Installation Before Installation WARNING: Electrical Power Installation of this equipment must only be performed by an appropriately qualified and competent electrician, in accordance with the regulations in force in the region of installation. The instructions below are illustrative only and do NOT override anything written in the current regulations.
  • Page 16: If A Mounting Post Is Not Supplied

    Installation If a mounting post is not supplied: 11. Carefully place the rear enclosure of the Unit in the desired location and mark the four fixing points. Remove the enclosure before drilling. WARNING: Equipment Damage Do NOT use the enclosure as a drilling guide. Debris from drilling can damage internal components.
  • Page 17: Operation

    Operation Operation Warning: Electrical Hazard Do NOT exceed the power rating displayed on the label. Do NOT change the cable plug/coupler to accept a connection to a higher rated power source. Do NOT extend cables without taking advice from a qualified electrician. Do NOT place strain on the connection(s) or stretch the cable.
  • Page 18: Disconnect The Power Connection Cable From An Interlocked Hook-Up Unit

    Operation Disconnect the Power Connection Cable from an Interlocked Hook-Up Unit 1. Make sure the rotary power switch is turned to the OFF position. 2. Pull the Hook-Up cable from the Hook-Up unit. 3. Make sure the socket cover is closed when not connected to a cable. 4.
  • Page 19: Unit Maintenance

    Unit Maintenance Unit Maintenance WARNING: Electrical maintenance of this product must only be performed by an appropriately qualified and competent person, in accordance with the regulations in force in the region of installation. Replacement sockets/couplers must be of the same type and rating as the original items.
  • Page 20: Rcbos

    (RCD). Operation by the end user is virtually identical for all these devices. Each Rolec Hook-Up Unit is equipped with an RCBO of the appropriate rating which will cut power to the Hook-Up socket(s) or cable in the event of: Earth Leak –...
  • Page 21: Troubleshooting

    Unit Maintenance Troubleshooting 1. Cannot connect cable to 1. Make sure the correct cable/plug is being used. Hook-Up Unit 2. Rotary power switch already in the ON position. Try to turn the switch to the OFF position and attempt to connect the cable. 3.
  • Page 24 LEADING MANUFACTURER OF HOOK-UP & ELECTRICAL DISTRIBUTION EQUIPMENT Head office contact: @ @ RolecLeisure t: +44 (0) 1205 724754 www.rolecserv.com f: +44 (0) 1205 724876 rolec@rolecserv.co.uk...
