Summary of Contents for Hoist Fitness MC-7031
- Page 1 MC-7031 BASKET OPTION Note: Both Serial Number and Model Number are Required when Ordering Parts Customer Service RECORD SERIAL NUMBER HERE (800) 548-5438 (858) 578-7676 MACHINE CODE (858) 578-9558...
-
Page 2: Table Of Contents
OWNER'S MANUAL CONTENTS INSTRUCTIONS ..............FRAME ASSEMBLY .............. DECAL PLACEMENT............. DECAL REFERENCE............. PART LIST................ABBREVIATIONS..............LIMITED WARRANTY............PAGE 01 MC-7031 ASSEMBLY... -
Page 3: Instructions
Be sure to have your serial number and this manual when calling. When all parts have been accounted for, continue on. TOOLS REQUIRED Ratchet Wrench 1/2", 9/16" and 3/4" Sockets Adjustable Wrench Rubber Mallet Tape Measure Level Hex Key Wrench Set Two People MC-7031 ASSEMBLY PAGE 02... - Page 4 OWNER'S MANUAL ***THIS PAGE WAS INTENTIONALLY LEFT BLANK*** PAGE 03 MC-7031 ASSEMBLY...
-
Page 5: Frame Assembly
- SOME PARTS MAY HAVE BEEN REMOVED FOR CLARITY. ASSEMBLY FOR BASKET ON BOTTOM SHELF ASSEMBLY FOR BASKET ON TOP SHELF OTHER STATIONS MAY BE USED INSTEAD OF THE MC-7017, SUCH AS THE MC-7018 OR MC-7019 MC-7017 MC-7031 ASSEMBLY PAGE 04... -
Page 6: Decal Placement
OWNER'S MANUAL DECAL PLACEMENT NOTE: - ALL DECALS ARE CENTERED UNLESS OTHERWISE STATED. - SOME PARTS MAY HAVE BEEN REMOVED FOR CLARITY. PAGE 05 MC-7031 ASSEMBLY... -
Page 7: Decal Reference
OWNER'S MANUAL DECAL REFERENCE SERIAL # DECAL MC-7031 ASSEMBLY PAGE 06... -
Page 8: Part List
1/2" X 27mm SAE FLAT WASHER (Ni) 011-0116113 1/2"-13UNC X 2.50" LOW HEAD SHCS (Ni) 012-0504002 1/2"-13 UNC THIN NYLOCK NUT (Ni) 011-0116126 1/2"-13UNC X 5.75" LOW HEAD SHCS (Ni) SERIAL # DECAL DECAL HOIST SERIAL # 1.63" X 2.63" PAGE 07 MC-7031 ASSEMBLY... -
Page 9: Abbreviations
HHB = Hex Head Bolt FHCS = Flat Head Cap Screw BHCS = Button Head Cap Screw SHCS = Socket Head Cap Screw Low Head SHCS = Low Head Socket Head Cap Screw SHSS = Socket Head Shoulder Screw MC-7031 ASSEMBLY PAGE 08... -
Page 10: Limited Warranty
Hoist Fitness Systems sole responsibility shall be to repair or replace the component within the terms stated above. Hoist Fitness Systems shall not be liable for any loss or damage of any kind including any incidental or consequential damages resulting, directly or indirectly from any warranty expressed or implied or any other failure of this product.
