Mounting Solutions CMT-H3 Series Quick Start Manual

The CMT-H3x is a heavy-duty
speaker ceiling mount with rotation
and tilt functionality.
This bracket supports loudspeakers
weighing up to 45 kg (100 lbs.) and
comes with a design factor of 7:1.
Its speaker & ceiling mount bracket
are installed separately and coupled
SPECIFICATIONS:
Functions
Mounting holes
Rotation angle
Tilt angle
Pan angle
Load limit
Design factor
Dimensions
Shipping dimensions
Net weight
Shipping weight (2 pcs per box)
COMPABILITY:
Compatible MAG
Cinema speakers:
Compatible JBL
speakers:
Compatible QSC
speakers:
Compatible SLS
speakers:
Compatible Klipsch
speakers:
Compatible Vive Audio
speakers:
Compatible Alcons
speakers:
Compatible Meyer
Sound speakers:
Compatible Krix
speakers:
www.mnmounting.com
info@mnmounting.com
2 Merezhna str., Bila Tserkva,
Kyiv region, 09100, Ukraine
CMT-H3x
very easily by just one person.
Tilt adjustments
achieved by means of a self-locking
mechanism holding the speaker in
place, even with all the bolts fully
released.
The CMT-H3x
loudspeakers that are foreseen
Celing Speaker Mounts
4x dia 9 mm (dia 0.34") (5" x 2,75" pattern)
4x dia 9 mm (dia 0.34") (4,25" x 2" pattern)
4x dia 9 mm (dia 0.34") (6,9" x 3,4" pattern)
VESA 75x75 / VESA 100x100
0° ... 180°
45 kg
257 x 220 x 123 mm
300 x 250 x 240 mm
1,8 kg
3,9 kg
SUR-63, SUR-83, SUR-103, SUR-123, SUR-153, SUR-
153H, SUR-408, SUR-410, SUR-420.
8102, 9350, 9300, 9310, 9320
SR-800, SR-8101, SR-1000, SR-8200, SR-1020, SR-1030,
SR-1290, SR-1590
CS1090, SC1290S-CM, SC-1290S, 114RT-I-PXO, 8290V2,
DSR 1260/1280
KPT-250, KPT-1201, KPT-1200M, KPT-1260 H, KPT-8001
LS1S, LS2S, LS5S, LA3Si, LA4S
CCS8, CCS8S, CCS12
HMS-5, HMS-10, HMS-12, HMS-15, Ultra-X20
KX-1152, KX-1570
EMEA & Asian region:
+32 (0) 472 630212
USA, LATAM, Canada, Australia
& New Zealand region:
+1 (562) 607 7348
are simply
mount fits all
360°
0° ... 90°
100 lbs
7:1 ratio
10,12" x 8,66" x 4,84"
11,81" x 9,84" x 9,44"
3,97 lbs
8,60 lbs
Ceiling Speaker Mounts
100 lbs (45 kg) max load
VESA 75x75 / 100x100 / 5''x2,75''
from a universal mounting patterns
(5" x 2,75", 4,25" x 2", 6,9" x 3,4", VESA
75x75 and 100x100).
The CMT-H3x is the way to go in
all immersive sound applications
given its rotation of 360°, 0° to 90°
vertical tilt and 0° to 180° horizontal
tilt.
SAFETY INSTRUCTIONS
1. Entrust mounting equipment only to
experienced professionals and strictly follow
the provided safety instructions. Improperly
installed equipment may result in property
damage, personal injury and/or liability for the
installing contractor.
2. Always use safety cables! This will prevent
equipment from falling during setup or while
exploitation.
3. Always carefully check the mounting
surface of the wall. Make sure the wall or
ceiling structure allows to hold the weight of
the speaker including its bracket.
4. Only use appropriate fastening hardware.
5. Always make sure to securely use and lock
all mounting bolts. Loose bolts may become
unscrewed over time due to vibration which
will then create a safety hazard.
PACKAGE CONTENTS
1. CMT-H3x celing
speaker mounts - 2 pcs
2. Installation manual - 1 pcs
3. Hex key 5 - 1 pcs
OPTIONAL ACCESSORIES
1. CMT-D Fixed Length
2. CMT-D Telescopic Length
