Installation Guide CMT-H3x Installation Guide for CMT-H3x Overhead Mounting Systems. The CMT-H3x is a heavy-duty speaker ceiling mount with rotation, tilt and pan functionality. SAFETY INSTRUCTIONS 1. Only entrust loudspeaker mounting equipment to experienced professionals. Also strictly follow the provided safety instructions.
Page 2
Installation Guide CMT-H3x Installation Instructions: 1. First, release the upper bolt which securing the speaker plate to the 2. Screw the speaker plate to the rear bracket. Now remove the speaker plate (4) holes of the loudspeaker by using all from the ceiling mount bracket.
Page 3
Installation Guide CMT-H3x 5.1 First position. 5.2 Second position. Slide the speaker plate along with Slide the speaker plate along with the loudspeaker onto the lower bolt of the loudspeaker onto the lower bolt of the tilt mechanism. Press down on the the tilt mechanism.
