Item #000-000
Model #13H-001-4DS
USE AND CARE GUIDE
MADISON 4PC SHUTTER BACK DEEP SEATING SET
(2 Lounge Chairs and 1 Love Seat)
Questions, problems, missing parts? Before returning to the store,
call Hampton Bay Customer Service
8.00 a.m. - 6.00 p.m., EST, Monday - Friday
1-877-527-0313
HOMEDEPOT.COM
THANK YOU
We appreciate the trust and con dence you have placed in Hampton Bay through the purchase of this outdoor seating set. We Strive
to continually create quality products designed to enhance your home. Visit us online to see our full line of products available
for your home improvement needs. Thank you for choosing Hampton Bay!
Advertisement
Table of Contents
Related Manuals for HAMPTON BAY MADISON 13H-001-4DS
Summary of Contents for HAMPTON BAY MADISON 13H-001-4DS
- Page 1 THANK YOU We appreciate the trust and con dence you have placed in Hampton Bay through the purchase of this outdoor seating set. We Strive to continually create quality products designed to enhance your home. Visit us online to see our full line of products available...
- Page 2 Table of Contents Table of Contents............Hardware Included............. Safety Information............Package Contents ............. About Symbols ............Assembly ..............Warranty ..............Operation ..............5 Year Frame Limited Warranty, 1 Year Fabric Limited Warranty ............Pre-installation............Planning Installation ............ Tools required ............. Safety Information DANGER: Please keep children out of the assembly area during assembly.
- Page 3 Pre-installation PLANNING INSTALLATION It will take 2 people about 35 minutes to complete the installation process. TOOLS REQUIRED No tools needed. HARDWARE INCLUDED NOTE: Hardware not shown to actual size. Part Description Quantity Bolt (M6x30) Bolt (M6x45) Washer Bolt cap Wrench HOMEDEPOT.COM Please contact 1-877-527-0313 for further assistance.
- Page 4 Pre-installation (continued) PACKAGE CONTENTS Part Description Quantity Armrest Armrest Seat and back (Lounge Chairs) Love seat and back (Love Seat)
- Page 5 Assembly Attaching the Lounge Chair Armrest Leveling the Lounge Chair □ Place armrest (A) on at smooth surface. □ Turn over the chair. □ Assemble seat and back (C) to armrest (A). Make sure to use □ Twist the glides on the bottom of the Table legs the right hardware at the right assembly point.
- Page 6 Assembly (continued) Attaching the Love Seat Armrests Leveling the Love Seat □ Place armrest (A) on a at, smooth surface. □ Turn over the Loveseat. □ Assemble love seat and back (D) to armrest (A). Make sure □ Twist the glides on the bottom of the Table legs using the right hardware at the right assemble point.
- Page 7 Operation Using your Chairs Checking the Stability □ □ Always put the chairs on at ground. The chairs are for outdoor use. □ □ Put the 34” Coffee Table together with these 3 chairs. Level the chair with the glides at the bottom of chair legs.
- Page 8 Questions, problems, missing parts? Before returning to the store, call Hampton Bay Customer Service 8.00 a.m. – 6.00 p.m., EST, Monday-Friday 1-877-527-0313 HOMEDEPOT.COM Retain this manual for future use.
