Product Manual
Description
The SZ1022, SZ1031, and SZ1035, are microprocessor-
based programmable thermostats designed for conven-
tional heating and cooling applications. The SZ1022
features a 7-day time clock, while the SZ1031 and
SZ1035 feature a 365-day time clock.
Features
• Stand-alone or network operation
• Adjustable delay on power-up and start-up for soft
starts
• P+I control option
• Smart Recovery
• No battery backup required
• Built-in HVAC equipment protection
• 32 character LCD display
• 6 status LEDs
• Remote room sensing capability
• User setpoint adjustment limits
• Local and remote override capability
• System and fan switching with access lockouts
• Auxiliary time clock output (economizers)
• Equipment monitoring inputs and indication
• External time clock input
• Access to programming or schedule may be locked
out or limited with the use of an access code
• Fahrenheit or Celsius temperature display
• Uses ZigBee protocol, IEEE 802.15.4 compliant*
• Self-healing, "plug & play" mesh network*
• 100mW output at 2.4 GHz*
• 150 to 500 feet typical in building range*
* wireless devices only
2800 LAURA LANE • MIDDLETON, WI 53562 • (800) 288-9383 • FAX (608) 836-9044 • www.tcsbasys.com
SZ1022/SZ1031/SZ1035/
Conventional Heating & Cooling
Thermostats
Contents
Description
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Features
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Mounting. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Schedule. . . . . . . . . . . . . . . . . . . . . . . 7
Program Options & Operating
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Guide. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Mounting
The SZ1022, SZ1031, and SZ1035 are designed for wall
mounting using two #6-32 machine screws sheet metal
screws, either over a horizontally installed 2" x 4" junc-
tion box, or directly to block or drywall.
For best results, the thermostat should be mounted on
an interior wall which reflects normal room environment,
at a height of approximately five feet from the floor.
Avoid areas exposed to direct sunlight, unusual heat
or cool sources, open doors and windows, unventilated
locations and hot or cold air from diffusers.
If using a remote room sensor, it should be mounted in
the manner described above. The thermostat may then
be mounted in an area which is accessible for adjusting
its settings.
Caution: Remove power from thermostat prior to
mounting.
R
1
Communicating Thermostats
Communicating Thermostats
Features. . . . . . . . . . . . 8
. . . . . . . . . . . . . . . . . . . . 10

Advertisement

loading
Need help?

Need help?

Do you have a question about the SUPERSTAT SZ1022 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for TCS Basys Controls SUPERSTAT SZ1022

  • Page 1: Table Of Contents

    Product Manual SZ1022/SZ1031/SZ1035/ Conventional Heating & Cooling Thermostats Communicating Thermostats Communicating Thermostats Description Contents The SZ1022, SZ1031, and SZ1035, are microprocessor- Description ........1 based programmable thermostats designed for conven- Features .
  • Page 2: Wiring

    Wiring POWERING THE SUPERSTAT Superstats are powered from 24 VAC +/- 20%. The SZ1022, SZ1031, and SZ1035 use standard terminal designations for wiring. See diagram below. If wiring for communications, dedicated power must be used to power the Superstat. Several “S” Series thermo- REMOTE TEMPERATURE SENSOR WIRING stats may be powered from the same transformer, provid- ed that the transformer has sufficient power.
  • Page 3: Setup

    Setup Note: If using remote sensor(s), the calibra- tion may need to be adjusted. See “Checkout and Troubleshooting” section. TEMPERATURE SENSOR SELECTION The dipswitches in the cover (shown above) must be set when using remote room, discharge, and/or outdoor sensors. KEYPAD ACCESS Use the following guide to determine the dipswitch set- The dipswitches in the thermostat cover (shown above)
  • Page 4: Programming

    Programming The SZ1022, SZ1031, and SZ1035 may be programmed SET BAUD RATE: Communication Baud Rate Screen. If using a PC to do programming, all through the keypad on the face, or with a PC. 9.6k controllers on a network must be set to If programming with a PC, the following must be set via the same baud rate.
  • Page 5 Override Time Screen. Enter the SET OVERRIDE number of minutes (0 to 255) that Occupied Heat Setpoint Screen. the Superstat will maintain occu- TIME: 180 MINUTES OCCUPIED HEAT Set the heat setpoint for this occu- pied setpoints when overridden. sz1022, pied period.
  • Page 6 Heat Stage 2 Differential Screen. HEAT STAGE 2 SET CONTROL Control Mode Screen. Enter if you Enter a differential value for heat stage want to control by temperature only (P) 2. This screen only appears if stage 2 DIFF: MODE: or add a time factor (P+I).
  • Page 7: Setting Clock & Schedule

    Setting Clock & Schedule DI2 Choice Screen. Choose DI2 as SERVICE, COOL LOCKOUT, The SZ1022, SZ1031, and SZ1035 clock and schedule DI2 USED FOR: or MONITOR. Select MONITOR if may be set through the keypad and display, or with a MONITOR unused.
  • Page 8 Holiday Announcement Screen. Schedule Announcement Screen. SET OCCUPIED ENTER DATES FOR Announces the next screen. (Not Announces the next screen. available on SZ1022.) TIMES MONDAY: HOLIDAY #2: program program setup setup Occupied Times Screen. Set hours Holidays #2 Screen. Set holiday and minutes of start and end times periods 1 through 12, month, date, and A:08:00 TO 12:00...
  • Page 9 OVERRIDE DISCHARGE AIR TEMPERATURE SENSING The SZ1022, SZ1031, and SZ1035 accept a remote dis- A timed override is available using the button on the charge air sensor for monitoring purposes. (See setup face of the thermostat or through momentary contacts instructions for dipswitch placement for this option.) wired into the OVR terminal.
  • Page 10 ment cycling. If the equipment is small compared to the DI2 SETPOINT SHIFT load, or if tight control is desired, you may want to make The SZ1022, SZ1031, and SZ1035 allow DI2 to be set this value as low as 1. for setpoint shift for energy demand setback.
  • Page 11: Checkout & Troubleshooting

    P + I OPTION DELAY ON POWER UP The SZ1022, SZ1031, and SZ1035 also have a P+I The SZ1022, SZ1031, and SZ1035 have an adjustable option. Without enabling this option, stages turn on delay on power up. When several thermostats are used and off based on temperature vs.
  • Page 12 setpoint adjustment limits. Change this to +/-20 °F (SYSTEM SWITCH button), and the unoccupied fan (11.1 °C). Press the PROGRAM SETUP button once mode in programming. If the fan is off but the fan LED more to store the change. Then press the SERVICE is on, check wiring.
  • Page 13: Led Description

    Service LED is On COOL STAGE 1 If the service LED is on, it may be for monitoring purpos- COOL STAGE 2 es or it may indicate a critical problem. The first moni- Cool Stages Status Screen. sz1035 Shows the status of the first and toring screen, which is used to indicate why the light is service status...
  • Page 14: User's Guide

    User’s Guide Limiting Occupant Access Inside the hinged door of the thermostat is the Superstat ™ SETPOINT ADJUSTMENT User’s Guide. This guide is designed to assist the installer The occupant may temporarily change the occupied heat- in explaining to the user how to operate their new thermo- ing and cooling setpoints +/- 5’F by factory default.
