Product Manual

Description

The SZ1009 is a microprocessor-based programmable
thermostats designed for conventional heating and cool-
ing applications with optional heat pump mode. The
SZ1009 features a 7-day time clock.

Features

• Stand-alone or network operation
• Adjustable delay on power-up and start-up for soft
starts
• P+I control option
• Smart Recovery
• No battery backup required
• Built-in HVAC equipment protection
• 32 character LCD display
• 6 status LEDs
• Remote room sensing capability
• User setpoint adjustment limits
• Local and remote override capability
• System and fan switching with access lockouts
• Equipment monitoring inputs and indication
• External time clock input
• Access to programming or schedule may be locked
out or limited with the use of an access code
• Fahrenheit or Celsius temperature display
• Convertible to heat pump mode in programming
2800 LAURA LANE • MIDDLETON, WI 53562 • (800) 288-9383 • FAX (608) 836-9044 • www.tcsbasys.com
SZ1009
Conventional Heating & Cooling
Thermostats with Heat Pump Mode
Contents
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Mounting. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Schedule. . . . . . . . . . . . . . . . . . . . . . . 6
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Guide. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

Mounting

The SZ1009 is designed for wall mounting using two
#6-32 machine screws sheet metal screws, either over
a horizontally installed 2" x 4" junction box, or directly to
block or drywall.
For best results, the thermostat should be mounted on
an interior wall which reflects normal room environment,
at a height of approximately five feet from the floor.
Avoid areas exposed to direct sunlight, unusual heat
or cool sources, open doors and windows, unventilated
locations and hot or cold air from diffusers.
If using a remote room sensor, it should be mounted in
the manner described above. The thermostat may then
be mounted in an area which is accessible for adjusting
its settings.
Caution: Remove power from thermostat
prior to mounting.
R
1
Communicating Thermostats
Communicating Thermostats
Features. . . . . . . . . . . . 7
. . . . . . . . . . . . . . . . . . . . 10

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SZ1009 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for TCS Basys Controls SZ1009

Summary of Contents for TCS Basys Controls SZ1009

  • Page 1: Table Of Contents

    • Built-in HVAC equipment protection Mounting • 32 character LCD display • 6 status LEDs The SZ1009 is designed for wall mounting using two • Remote room sensing capability #6-32 machine screws sheet metal screws, either over • User setpoint adjustment limits a horizontally installed 2”...

  • Page 2: Wiring

    Wiring POWERING THE SUPERSTAT Superstats are powered from 24 VAC +/- 20%. The SZ1009 uses standard terminal designations for wir- ing. See diagram below. If wiring for communications, dedicated power must be used to power the Superstat. Several “S” Series thermo-...

  • Page 3: Setup

    Setup Note: If using remote sensor(s), the calibra- tion may need to be adjusted. See “Checkout and Troubleshooting” section. TEMPERATURE SENSOR SELECTION The dipswitches in the cover (shown above) must be set when using remote room, discharge, and/or outdoor sensors. KEYPAD ACCESS Use the following guide to determine the dipswitch set- tings for your application.

  • Page 4: Programming

    Programming The SZ1009 may be programmed through the keypad on SET BAUD RATE: Communication Baud Rate Screen. If using a PC to do programming, all the face, or with a PC. 9.6k controllers on a network must be set to If programming with a PC, the following must be set via the same baud rate.
  • Page 5 OCCUPIED HEAT Occupied Heat Setpoint Screen. User Setpoint Limit Screen. Enter the LIMIT SETPOINT Set the heat setpoint for this occupied SETPOINT B: number of degrees you want the user to period. be allowed to change the preset occupied ADJUST +/-: setpoints up or down.

  • Page 6: Setting Clock & Schedule

    MONITOR Setting Clock & Schedule program setup The SZ1009 clock and schedule may be set through the keypad and display, or with a PC. For more information DI2 Shift Screen. Enter the setpoint SET DI2 SETPOINT on programming through the PC, consult your TCS soft- shift value.

  • Page 7: Program Options & Operating Features

    12:00AM Operation clock setup UNOCCUPIED SETBACK The SZ1009 operates in either an occupied or unoc- Access Code Entry Screen. May ENTER ACCESS appear if access code is required for cupied mode. During the occupied mode, the occupied setting clock and schedules. 248 is...
  • Page 8 FAN PROVING the face or with a remote momentary contact. The SZ1009 allows DI1 to be set for fan proving to pro- To allow a regular schedule, and also automatically tect equipment on fan failure. To utilize this function,...
  • Page 9 DELAY ON POWER UP vs. setpoint alone, as described above. By enabling this The SZ1009 has an adjustable delay on power up. When option, you allow a time factor to be added. This is use- several thermostats are used at one location, and the...

  • Page 10: Checkout & Troubleshooting

    Heating or Cooling Does Not Come On mode by making sure that the top LED is lit. If not, * SZ1009 * At least one stage of heating is on whenever the heating LED is on, and at least one stage of cooling is on when- TCS V2.0 (c)
  • Page 11 ature. The built-in sensor should read 108 to 109 ohms Main Monitoring Screen. Press the at room temperature. If any of the temperatures are still service button to access the following screens. 12:00AM reading slightly high or low, you can add in a tempera- ture offset (calibration) using Ubiquity or TCS Insight.

  • Page 12: Led Description

    LED Description PROGRAMMING The ability to program control parameters is allowed by Six LEDs on the face allow the occupant to view the current factory default. An access code may be required as set in operating status of the thermostat. programming step #38, or access may be denied altogether using dipswitches described in the setup section.
