Crystal Vision Vision System SYNNER-VF User Manual

3g/hd/sd video synchroniser, tracking audio delay and embedder/de-embedder

Advertisement

Quick Links

SYNNER-VF
3G/HD/SD video synchroniser,
tracking audio delay and
embedder/de-embedder
Crystal Vision Ltd., Lion Technology Park, Station Road East, Whittlesford, Cambridge, CB22 4WL, England.
Tel: +44(0) 1223 497049 Fax: +44(0) 1223 497059 sales@crystalvision.tv www.crystalvision.tv

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Vision System SYNNER-VF and is the answer not in the manual?

Questions and answers

Summary of Contents for Crystal Vision Vision System SYNNER-VF

  • Page 1 SYNNER-VF 3G/HD/SD video synchroniser, tracking audio delay and embedder/de-embedder Crystal Vision Ltd., Lion Technology Park, Station Road East, Whittlesford, Cambridge, CB22 4WL, England. Tel: +44(0) 1223 497049 Fax: +44(0) 1223 497059 sales@crystalvision.tv www.crystalvision.tv...
  • Page 2: Table Of Contents

    Crystal Vision SYNNER-VF User Manual Contents Introduction Video and audio delays in SYNNER-VF Hardware installation Piggyback boards 3G-AIP2 Analogue Input 3G-AOP2 Analogue Output DIOP4 AES I/O Legal combinations Fitting the I/O piggybacks onto the main board Rear modules and signal I/O...
  • Page 3 Crystal Vision SYNNER-VF User Manual Discrete inputs Audio gain DeEmbedded input delay Discrete input delay User delay AES I/O configure Audio Router Embedded output router Discrete output router Mute & group enable Presets, default, alarms Presets Card default Alarm delays ‘Live’...
  • Page 4: Introduction

    SYNNER-VF is a synchronising audio embedder/de-embedder for use in the Vision 3 rack frames from Crystal Vision. It provides a versatile solution for audio embedding and de- embedding with built-in video delay and synchronising. The SDI video signal passes through a de-embedder and an embedder which allows the extraction and insertion of up to 16 channels (four groups) of audio.
  • Page 5 VANC blanking option. EDH insertion. Supports the following Vision Rear Modules: VR02, VR12 and VR13. Compatible with ‘Vision’ frames from Crystal Vision. Passes all timecode, AFD and subtitling information. SYNNER-VF functional block diagram Block Diagram Description SDI video is cable-equalised, re-clocked and passed through a de-embedder block where up to 16 channels of audio are extracted.
  • Page 6: Video And Audio Delays In Synner-Vf

    Crystal Vision Introduction Audio processing blocks where gain and fixed delay and/or automatic tracking delay for non- Dolby encoded signals, or alignment delay for Dolby E signals are made after resampling. The outputs of the audio processing block are input to two independent 32 x 16 routers which feed the optional plug-in output piggybacks and the embedding block.
  • Page 7 Crystal Vision Introduction to 1 frame. If the reference signal is not locked to the input video, the synchroniser delay will increase or reduce to follow the reference. When the delay goes beyond its minimum or maximum range it will jump instantaneously to the opposite end of its range, either skipping or repeating a frame, possibly causing a motion disturbance for non-static pictures.
  • Page 8 Crystal Vision Introduction 9. This delay is after the frame synchroniser and TAD delays. If either reference is selected as the output timing reference source, the values set by the ‘0-42ms,0-100us and 0-1us’ Delay & output controls in the menu will delay the video and audio signals with respect to the reference.
  • Page 9: Hardware Installation

    All of the links and potentiometers on the card are factory set and should NOT be adjusted. SYNNER-VF cards are intended for use only in the Crystal Vision ‘Vision’ frame range and not in older style frames such as ‘Indigo’.
  • Page 10: Aip2 Analogue Input

    Crystal Vision Hardware installation 3G-AIP2 Analogue Input This analogue module has four balanced audio inputs. The links PL1-4 allow 0dBFS to be set to +18dBu (to the right, towards SK1) or +24dBu (to the left, towards SK2/3). The adjacent potentiometers RV1-4 are factory set and should NOT be adjusted.
  • Page 11: Diop4 Aes I/O

    Crystal Vision Hardware installation DIOP4 AES I/O This digital audio piggyback has four AES stereo pairs that are individually configured as inputs or outputs by software. There are no links or user- adjustments on this card. Legal combinations Not all combinations of piggyback boards are allowed. The following table shows the only...
  • Page 12: Rear Modules And Signal I/O

    Crystal Vision Rear modules and signal I/O 3 Rear modules and signal I/O The Vision 3 frame will house up to 20 single height cards and dual power supplies or ten double height modules. All modules can be plugged in and removed while the frame is powered without damage.
  • Page 13: Rear Module Connections With Vr12

    Crystal Vision Rear modules and signal I/O 3.2 Rear module connections with VR12 The VR12 single-slot rear module has one VR12 3G/HD/SD serial digital video input plus two 3G/HD/SD serial digital video outputs on BNC and eight AES stereo pairs or eight mono analogue channels as balanced I/O on the D-Type connector.
  • Page 14: Rear Module Connections With Vr13

    Crystal Vision Rear modules and signal I/O 3.3 Rear module connections with VR13 VR13 3G/HD/SD serial digital input 3G/HD/SD serial digital output Fibre video I/O. Correct fibre module must be fitted to card Unbalanced AES 3G/HD/SD serial digital outputs Unbalanced AES The VR13 double-slot module has BNC connectors for eight channels (stereo pairs) of unbalanced AES audio.
  • Page 15: Vr02 And Vr12 Audio Pin-Out

    Crystal Vision Rear modules and signal I/O 3.4 VR02 and VR12 audio pin-out The 26-way high-density audio ‘D’ connector on the VR02 and VR12 modules can be used for analogue or digital, inputs or outputs – or a mixture of both depending on the I/O piggybacks fitted.
  • Page 16 Crystal Vision Rear modules and signal I/O Piggyback Function Pin-out position Analogue audio 8/ AES8 19, 20, 23, 21, 22, 25, VR02 and VR12 audio I/O connector wiring - All audio balanced signals can be either input or output depending on I/O module fitted.
  • Page 17: Control And Status Monitoring

    SYNNER-VF Status Page 4.2 Control Descriptions Crystal Vision cards use an XML file to create a control database that is common to all controllers. Although the description of controls used in this manual is based on VisionWeb GUI screen grabs, the menu tree for VisionPanel and Vision frame front panel operation is the SYNNER-VF User Manual R1.1...
  • Page 18 Crystal Vision Control and Status monitoring same, although the appearance and labelling of some controls may vary according to the available space. See Menu Structure for a more detailed menu tree. VisionWeb GUI controls are accessed by tabs at the bottom of the page: Status, Video, Audio, Audio router and Presets, default, alarms.
  • Page 19: Status

    Crystal Vision Control and Status monitoring 4.3 Status Video Display presence, standard and status of incoming video signal. Present On when input video is present. Displays video standard of incoming video i.e. 1080i 50, Format 1080p 50, 720p 50, 625, 525 etc.
  • Page 20: Audio Status

    Crystal Vision Control and Status monitoring Audio status Displays presence of audio embedded in incoming and outgoing video signal. On when audio group detected in incoming Input audio groups - Present video. On when audio group detected in outgoing Output audio groups - Present video.
  • Page 21: Video

    Crystal Vision Control and Status monitoring 4.4 Video Delay & output Set up the synchroniser and frame, line and pixel delays. Select an additional 0.5 frame delay for the video path and PCM (non-Dolby E encoded) audio channels. Used in synchroniser mode to advance reference signal +0.5 frame with...
  • Page 22 Crystal Vision Control and Status monitoring Select a delay of between 0-10 video frames for the video path. As the audio path is not affected by this delay, this control will delay the video with respect to the audio. Audio channels will Frames be delayed by the same amount if ‘Match video frame delay’...
  • Page 23 Crystal Vision Control and Status monitoring When selected, the card will automatically relock when a lost Auto Relock reference is restored. This control is on by default. Enable Reference 1 & Select either analogue Black & Burst or tri- 2 filter level sync as the reference input type.
  • Page 24: Rgb Proc

    Crystal Vision Control and Status monitoring RGB proc Apply varying amounts of lift and gain to the Red, Green and Blue channels of the video path. Apply a positive or negative DC offset to the black level of Red/Green/Blue Lift the Red, Green and Blue components of the video path.
  • Page 25: Vanc & Dolby E Sequence

    Crystal Vision Control and Status monitoring VANC & Dolby E sequence Blank ancillary data and lock progressive HD video output to ATC, or invert sequence to help ensure that Dolby E has its guardband correctly positioned. Select to blank the vertical ancillary data in the video VANC blank signal vertical interval.
  • Page 26 Crystal Vision Control and Status monitoring Displays one of the following depending on the received power level: ‘OVERLOAD’, ‘HIGH’, ‘GOOD’, ‘LOW’, ‘TOO LOW’. ‘OVERLOAD’ or ‘HIGH’ may cause the receiver to saturate with poor or no video output. In extreme cases the receiver may even be damaged –...
  • Page 27: Audio

    Crystal Vision Control and Status monitoring 4.5 Audio DeEmbedded input Monitor de-embedder channel status, invert channels, detect Dolby E encoded channel pairs, mono and resample stereo pairs. Present On when embedded channel detected. On if the audio channel is silent i.e. consistently below the Silent threshold set by the ‘Audio silence level’...
  • Page 28: Discrete Inputs

    Crystal Vision Control and Status monitoring Select to enable resampling of the selected stereo pair output from the de-embedder. Resampling is used to seamlessly match the timing of audio signals when the user-controlled delay is altered and is the default condition. If resampling is deselected it is...
  • Page 29: Audio Gain

    Crystal Vision Control and Status monitoring Select to enable resampling of the selected stereo pair output from the de-embedder. Resampling is used to seamlessly match the timing of audio signals when the user-controlled delay is altered and is the default condition.
  • Page 30: Deembedded Input Delay

    Crystal Vision Control and Status monitoring DeEmbedded input delay These controls can be used to match the video 0 to 10 frame delay, or to delay the de-embedded audio with respect to the video and compensate for any delay between the incoming video and audio signals.
  • Page 31: Discrete Input Delay

    Crystal Vision Control and Status monitoring Discrete input delay These controls can be used to match the video 0 to 10 frame delay or to delay the de-embedded audio with respect to the video and compensate for any delay between the incoming video and audio signals. The number of inputs will depend on the type of piggyback(s) and sub-board fitted.
  • Page 32: User Delay

    Crystal Vision Control and Status monitoring User delay Set the delay value for de-embedded and external audio signals. Set the delay value between -20 to +400mS for all channel PCM audio pairs (de-embedded or discrete) with the ‘User delay’ control (mS) selected.
  • Page 33: Audio Router

    Crystal Vision Control and Status monitoring 4.6 Audio Router Embedded output router Select the channels that will be embedded into the output video. In addition to the already embedded audio channels, additional or alternative audio sources are available for selection depending on the optional piggyback boards fitted.
  • Page 34: Discrete Output Router

    Crystal Vision Control and Status monitoring Present On if audio channel is present. Discrete output router Select the channels that will be output as AES or analogue signals. This menu is only available when a DIOP4 or 3G-AOP2 piggyback is fitted. The number of output channels available for routing will depend on the number and type of piggybacks fitted.
  • Page 35: Mute & Group Enable

    Crystal Vision Control and Status monitoring Mute & group enable Mute embedder output and AES and analogue outputs; enable embedder groups and select embedder encoding mode. The screen grab below shows a DIOP4 configured as outputs and a 3G-AOP2, giving a total of 12 audio outputs.
  • Page 36: Presets, Default, Alarms

    Crystal Vision Control and Status monitoring 4.7 Presets, default, alarms Presets Up to 16 user-defined configurations may be stored and recalled remotely by VisionWeb. Presets store the card setup data including operating mode card status. The presets are numbered 1-16.
  • Page 37: Alarm Delays

    Crystal Vision Control and Status monitoring Alarm delays Set the time that an alarm condition should be present before indicating a fault. Set the audio level that indicates a ‘silent’ condition. Video black Set the time that the alarm condition must be present before a (seconds), fault indication.
  • Page 38: Live' Button

    Crystal Vision Control and Status monitoring 4.8 ‘Live’ button In the top right hand corner of the VisionWeb GUI there is an icon labelled ‘Live’. Clicking on this button will display the following menu: With the ‘Live’ option selected, any changes to any of the controls will affect the output of SYNNER-VF as normal.
  • Page 39: Troubleshooting

    Crystal Vision Troubleshooting 5 Troubleshooting 5.1 Card edge monitoring The green LED on the front edge of the card provides power rail monitoring. The red LED, if fitted, currently has no function. 5.2 Basic fault finding guide Power OK LED not illuminated: Check that the frame PSU is functioning –...
  • Page 40: Specification

    Crystal Vision Specification 6 Specification General Dimensions 96mm x 325mm card with connector. Weight 180g with no piggybacks fitted; 220g with two piggybacks fitted. Power SYNNER-VF 10 Watts. consumption 3G-AIP2 – 2 Watts; 3G-AOP2 – 2 Watts; DIOP4 – 1 Watt.
  • Page 41 Crystal Vision Specification plus 110 ohm balanced audio I/O on a high density D-Type. VR13 One BNC video input, three BNC video outputs and dual LC optical I/O, plus eight 75 ohm unbalanced AES audio I/O on BNC. Delays Audio Delay Adjustable audio delay from -20 to 400ms on each PCM channel and from -14 to 36 samples for Dolby E channels.
  • Page 42: Appendix

    Crystal Vision Appendix 7 Appendix 1 7.1 Menu Structure Operators of a Vision frame active front panel can use the following tree to help negotiate the SYNNER-VF menus. Items shown in red are tabs in VisionWeb and panels in VisionPanel, and items shown in grey are menus in both.
  • Page 43 Crystal Vision Appendix select Frames 0->10 0-42ms 0->42 0-100us 0->100 0-1us 0->1 Line Pixel Apply to all formats Output timing Reference source select Active source Force relock Active Relock Enbl. select Ref 1 filter Ref 2 filter Tri-Level BlackBurst Input loss...
  • Page 44 Crystal Vision Appendix Lock to ATC input Fibre enable Inv. Op sequence Input Source Received power Power level Output Enable Level warning Bias warning Audio DeEmbedded input Input Group 1 C1 (for all 16 Channels) Group 4 C16 Present Silent...
  • Page 45 Crystal Vision Appendix Present Match video frame delay User delay Tracking audio delay Group1 C1+C2 Group4 C15+C16 DolbyE DolbyE align Group1 C1+C2 Discrete input Group4 C15+C16 delay Frame & user Front C1+C2 (for all available Input channels) Rear C15+C16 Present...
  • Page 46 Crystal Vision Appendix Audio Router Embedded output router Embedded chans Grp1 C1 (For all embedded outputs) Grp4 C16 Grp1 C1 (for all embedded Inputs) Grp4 C16 Front C1 (for all available Inputs) Rear C16 Present Grp1 C1 (for all embedded...
  • Page 47 Crystal Vision Appendix Mute Output enable Group1 Group2 Group3 Group4 Embedder mode SMPTE Sony Presets Default, alarms Presets Store/Recall Store Recall Preset select Card defaults 1->16 Card defaults Default exc preset Default inc preset Alarm delays Alarm delays Video black(secs) 2->60...
