  • Page 1 TANDEM10-VF 3G/HD/SD audio embedder/de- embedder Crystal Vision Ltd., Lion Technology Park, Station Road East, Whittlesford, Cambridge, CB22 4WL, England. Tel: +44(0) 1223 497049 Fax: +44(0) 1223 497059 sales@crystalvision.tv www.crystalvision.tv...
  • Page 2: Table Of Contents

    Crystal Vision TANDEM10-VF User Manual Contents Introduction Hardware installation Piggyback boards 3G-AIP2 Analogue Input 3G-AOP2 Analogue Output DIOP4 AES I/O Legal combinations Fitting the I/O piggybacks onto the main board Rear modules and signal I/O Rear module connections with VR02...
  • Page 3 Crystal Vision TANDEM10-VF User Manual DeEmbedded input delay Discrete input delay User delay AES I/O configure Audio Router Embedded output router Discrete output router Mute & group enable Presets, default, alarms Presets Card default Alarm delays ‘Live’ button Troubleshooting Card edge monitoring...
  • Page 4: Introduction

    TANDEM10-VF provides a versatile solution for audio embedding and de-embedding for use with Vision rack frames from Crystal Vision. It has a single SDI video path with a de- embedder and an embedder which allow the extraction and insertion of up to 16 channels (four groups) of audio.
  • Page 5 Crystal Vision Introduction TANDEM10-VF functional block diagram Block Diagram Description SDI video is cable-equalised, re-clocked and passed through a de-embedder block where up to 16 channels of audio are extracted. The video signal is then processed allowing for adjustment of video gain, black level and independent RGB and YUV gains. This is followed by up to ten video frames of delay before the video is then passed to the embedder block where up to 16 audio channels are inserted.
  • Page 6: Hardware Installation

    All of the links and potentiometers on the card are factory set and should NOT be adjusted. TANDEM10-VF cards are intended for use only in the Crystal Vision ‘Vision’ frame range and not in older style frames such as ‘Indigo’.
  • Page 7: Aip2 Analogue Input

    Crystal Vision Hardware installation 3G-AIP2 Analogue Input This analogue module has four balanced audio inputs. The links PL1-4 allow 0dBFS to be set to +18dBu (to the right, towards SK1) or +24dBu (to the left, towards SK2/3). The adjacent potentiometers RV1-4 are factory set and should NOT be adjusted.
  • Page 8: Diop4 Aes I/O

    Crystal Vision Hardware installation DIOP4 AES I/O This digital audio piggyback has four AES stereo pairs that are individually configured as inputs or outputs by software. There are no links or user-adjustments on this card. Legal combinations Not all combinations of piggyback boards are allowed. The following table shows the only...
  • Page 9: Rear Modules And Signal I/O

    Crystal Vision Rear modules and signal I/O 3 Rear modules and signal I/O The Vision 3 frame will house up to 20 single height modules and dual power supplies or ten double height modules. All modules can be plugged in and removed while the frame is powered without damage.
  • Page 10: Rear Module Connections With Vr12

    Crystal Vision Rear modules and signal I/O 3.2 Rear module connections with VR12 The VR12 single-slot rear module has one VR12 3G/HD/SD serial digital video input plus two 3G/HD/SD serial digital video outputs on BNC and eight AES stereo pairs or eight mono analogue channels as balanced I/O on the D-Type connector.
  • Page 11: Rear Module Connections With Vr13

    Crystal Vision Rear modules and signal I/O 3.3 Rear module connections with VR13 VR13 3G/HD/SD serial digital input 3G/HD/SD serial digital output Fibre video I/O. Correct fibre module must be fitted to card Unbalanced AES I/O 3G/HD/SD serial digital outputs...
  • Page 12: Vr02 And Vr12 Audio Pin-Out

    Crystal Vision Rear modules and signal I/O 3.4 VR02 and VR12 audio pin-out The 26-way high-density audio ‘D’ connector on the VR02 and VR12 modules can be used for analogue or digital, inputs or outputs – or a mixture of both depending on the I/O piggybacks fitted.
  • Page 13: Control And Status Monitoring

    TANDEM10-VF Status Page 4.2 Control Descriptions Crystal Vision cards use an XML file to create a control database that is common to all controllers. Although the description of controls used in this manual is based on VisionWeb GUI screen grabs, the menu tree for VisionPanel and Vision frame front panel operation is the TANDEM10-VF User Manual R1.0...
  • Page 14: Status

    Crystal Vision Control and Status monitoring same, although the appearance and labelling of some controls may vary according to the available space. See Menu Structure for a more detailed menu tree. VisionWeb GUI controls are accessed by tabs at the bottom of the page: Status, Video, Audio, Audio router and Presets, default, alarms.
  • Page 15: Audio Status

    Crystal Vision Control and Status monitoring Audio status Displays presence of audio embedded in incoming and outgoing video signal. On when audio group detected in incoming Input audio groups - Present video. On when audio group enabled in outgoing Output audio groups - Present video.
  • Page 16: Video

    Crystal Vision Control and Status monitoring 4.4 Video Delay & output Set up frame delay and loss of input output. Select to which input standard the fixed delay should only be applied to. Other input standards are unaffected. Format to modify Select a delay of between 0-10 video frames for the video path.
  • Page 17: Rgb Proc

    Crystal Vision Control and Status monitoring RGB proc Apply varying amounts of lift and gain to the Red, Green and Blue channels of the video path. Apply a positive or negative DC offset to the black Red/Green/Blue Lift level of the Red, Green and Blue components of the video path.
  • Page 18: Vanc

    Crystal Vision Control and Status monitoring VANC Blank ancillary data. Select to blank the vertical ancillary data in the video VANC blank signal vertical interval. Fibre enable Select optical or BNC as the video source. Enable fibre output and display laser fail warnings.
  • Page 19: Audio

    Crystal Vision Control and Status monitoring Enable Enable fibre optic output if FOP-VF or FIO-VF module fitted. Level On if the laser is producing low output power. This indicates that warning the laser has failed and should be replaced immediately.
  • Page 20: Discrete Inputs

    Crystal Vision Control and Status monitoring Dolby E On if the channel pair has Dolby E encoding. Select to mono the channel pair. N.B. Only the first channel of the stereo pair is converted to mono, the second channel is Mono unchanged.
  • Page 21: Audio Gain

    Crystal Vision Control and Status monitoring Select to mono the channel pair. N.B. Only the first channel of the stereo pair is converted to mono, the Mono second channel is unchanged. The mono output is gain corrected to maintain unity gain.
  • Page 22: Deembedded Input Delay

    Crystal Vision Control and Status monitoring DeEmbedded input delay These controls can be used to match the video 0 to 10 frame delay, or to delay the de-embedded audio with respect to the video and compensate for any delay between the incoming video and audio signals.
  • Page 23: Discrete Input Delay

    Crystal Vision Control and Status monitoring Discrete input delay These controls can be used to match the video 0 to 10 frame delay or to delay the de-embedded audio with respect to the video and compensate for any delay between the incoming video and audio signals. The number of inputs will depend on the type of piggyback(s) and sub-board fitted.
  • Page 24: User Delay

    Crystal Vision Control and Status monitoring User delay Set the delay value for de-embedded and external audio signals. Set the delay value between -20 to +400mS for all channel PCM audio pairs (de-embedded or discrete) with the ‘User delay’ control (mS) selected.
  • Page 25: Audio Router

    Crystal Vision Control and Status monitoring 4.6 Audio Router Embedded output router Select the channels that will be embedded into the output video. In addition to the already embedded audio channels, additional or alternative audio sources are available for selection depending on the optional piggyback boards fitted.
  • Page 26: Discrete Output Router

    Crystal Vision Control and Status monitoring Take Make all pre-selected crosspoints in one go. Present On if audio channel is present. Discrete output router Select the channels that will be output as AES or analogue signals. This menu is only available when a DIOP4 or 3G-AOP2 piggyback is fitted. The number of output channels available for routing will depend on the number and type of piggybacks fitted.
  • Page 27: Mute & Group Enable

    Crystal Vision Control and Status monitoring Take Switch all pre-selected crosspoints in one go. Mute & group enable Mute embedder output and AES and analogue outputs; enable embedder groups and select embedder encoding mode. The screen grab below shows a DIOP4 configured as outputs and a 3G-AOP2, giving a total of 12 audio outputs.
  • Page 28: Presets, Default, Alarms

    Crystal Vision Control and Status monitoring 4.7 Presets, default, alarms Presets Up to 16 user-defined configurations may be stored and recalled remotely by VisionWeb. Presets store the board setup data including operating mode card status. The presets are numbered 1-16.
  • Page 29: Alarm Delays

    Crystal Vision Control and Status monitoring Alarm delays Set the time that an alarm condition should be present before indicating a fault. Set the audio level that indicates a ‘silent’ condition. Video black Set the time that the alarm condition must be present before a (seconds), fault indication.
  • Page 30: Live' Button

    Crystal Vision Control and Status monitoring 4.8 ‘Live’ button In the top right hand corner of the VisionWeb GUI there is an icon labelled ‘Live’. Clicking on this button will display the following menu: With the ‘Live’ option selected, any changes to any of the controls will affect the output of TANDEM10-VF as normal.
  • Page 31: Troubleshooting

    Crystal Vision Troubleshooting 5 Troubleshooting 5.1 Card edge monitoring The green LED on the front edge of the card provides power rail monitoring. The red LED, if fitted, currently has no function. 5.2 Basic fault finding guide Power OK LED not illuminated: Check that the frame PSU is functioning –...
  • Page 32: Specification

    Crystal Vision Specification 6 Specification General Dimensions 96mm x 325mm card with connector. Weight 180g with no piggybacks fitted; 220g with two piggybacks fitted. Power TANDEM10-VF – 10 Watts. consumption 3G-AIP2 – 2 Watts; 3G-AOP2 – 2 Watts; DIOP4 – 1 Watt.
  • Page 33 Crystal Vision Specification Rear Module I/O VR02 One BNC video input and three BNC video outputs, plus 110 ohm balanced audio I/O on a high density D-Type. VR12 One BNC video input, two BNC video outputs and dual LC optical I/O, plus 110 ohm balanced audio I/O on a high density D-Type.
  • Page 34: Appendix

    Crystal Vision Appendix 1 7 Appendix 1 7.1 Menu Structure Operators of a ‘Vision’ frame active front panel can use the following tree to help negotiate the TANDEM10-VF menus. Items shown in red are tabs in VisionWeb and panels in VisionPanel, and items shown in grey are menus in both.
  • Page 35 Crystal Vision Appendix 1 Apply to all formats Input loss On loss of input show No output Output blue Output black RGB Proc Green Blue Lift -10 -> +10 Gain 80 -> 120 RGB default Default YUV Proc Lift -10 -> +10 Gain 0->200...
  • Page 36 Crystal Vision Appendix 1 Present Silent Invert Dolby E Mono Discrete Resample Inputs Discrete inputs Front C1 (for all available Input channels) Rear C16 Present Silent Invert Dolby E Mono Audio gain Resample Channel gain Select channels select Gain 1(dB)
  • Page 37 Crystal Vision Appendix 1 Front C7+C8 Input Output Rear Rear C9+C10 Rear C15+C16 Input Output Termination Balanced Unbalanced Audio Router Embedded output router Embedded chans Grp1 C1 (For all embedded outputs) Grp4 C16 Grp1 C1 (for all embedded Inputs) Grp4 C16...
  • Page 38 Crystal Vision Appendix 1 Mute & group enable Mute Group1 C1 (all embedded output channels) Group4 C16 Embed mute Output mutes (all possible output channels) Mute Output enable Group1 Group2 Group3 Group4 Embedder mode SMPTE Sony Presets, Default, Alarms Presets...
