- Page 1 Plug-in Alarm Receiver User Manual...
- Page 2 HTZSAFE sensors. 2.If you want to add HTZSAFE sensors to the receiver,set up them according to part 3 of the manual or email us at contact@saferhomee.com if you have any questions. 2. System Components And Usage Plug-in Alarm Receiver...
- Page 3 Speaker Speaker:sound for several seconds when the sensor be activated 3. Operation Instructions (1)How to add sensors to the plug-in alarm receiver (Total 4 zones and up to 4 sensors can be added to the receiver) Step 1 Plug the receiver into an outlet Ring tone prompt and the zone number will light up one by one for 3 times meaning the receiver works properly.
- Page 4 Step 2 Press and hold the “Volume” button for 5 seconds, release the button when one of the zone number flashing and a beep prompt Zone 1 flashing All the Zone slowly numbers light up Volume Volume press and hold the Volume button release the button...
- Page 5 Step 4 Activate the sensor again to confirm the sensor has been added to the plug-in alarm receiver already. Step 5 Press “Melody” once to choose the melody for this sensor, total 35 melodies optional. Melody Step 6 Same steps to add more sensors to the plug-in receiver. (For example: add the 2nd sensor to the receiver) Press and hold the “Volume button”...
- Page 6 (2)How to delete the sensors of the receiver Step 1 Plug the receiver into an outlet Step 2 Press and hold both the “Volume” button and “Melody” button for 10 seconds and release the buttons when you heard a long beep prompt; Note: all the sensors will be deleted by this operation.
-
Page 7: Technical Parameters
Same steps for other sensors which have been added to the receiver already. 5. Technical Parameters Plug-in Alarm Receiver 34mm 88mm 88mm 48mm Technical parameters Item Technical Parameters Working Voltage AC 110V-220V Static Current 20mA; Alarming Current 300mA Working Current Wireless Frequency 433MHz FSK+FHSS After-sale Service E-mail:contact@saferhomee.com HB201911-806A(1.1)-01...
Need help?
Do you have a question about the HTZSAFE 806A and is the answer not in the manual?
Questions and answers
The unit that plugs in the wall no longer chimes. It won’t chime when plugged in or when the buttons are pushed.
If the Saferhomee HTZSAFE 806A unit does not chime when plugged in or when the buttons are pushed, possible issues include:
1. The receiver is not properly plugged into a working power outlet.
2. The unit may be defective or not receiving power (check outlet and try a different one).
3. The internal settings may have been reset—if sensors were deleted, re-pairing is needed.
4. The volume might be set to the lowest level—adjust the volume by pressing the “Volume” button.
5. The sensor may not be properly added or is out of range (should be within 30 feet during setup).
Try re-plugging the device, ensuring power is present, and re-adding the sensors if needed.
