Asus AAEON EPIC-ADS7-PUC Quick Start Manual

What's in your kit?
1 x EPIC-ADS7-PUC System
1 x 12V@12.5A (150W) Power Adapter
1 x EU Power Cord
1 x US Power Cord
1
Get Ready
• EPIC-ADS7-PUC includes active cooling, RTC battery, memory,
and storage inside.
• Please follow these steps carefully before connecting cables &
powering on the system.
• Preinstalled software includes Ubuntu 20.04 LTS, Intel(R)
Distribution of OpenVINO™ toolkit 2021.4.2 LTS and Intel(R)
Edge Insights for Vision 2021.4.2 LTE.
3
Setup Details
1.When power is supplied, the system turns on and boots into the operating
system. When the system is powered up properly, the blue LED will light up on
power button.
•If proxy settings are required in you network, you can set them from :
System Settings > Network > Network Proxy
2.Get started with Edge Insights for Vision:
•https://developer.intel.com/GetStartedDevKitVisionCore
w ww. aa e o n . c o m
Quick Start Guide
EPIC-ADS7-PUC Foundation Kit
Powered by 12th Gen Intel® Core™ Processor
USB3.2 Gen2x2 (Type C) x 1, USB3.2 Gen2 x 4, USB2.0 x 2
M.2 3052 B key x 1 , M.2 2280 M key x 1, M.2 2230 E key x 1
You will need to have the following :
• Monitor with HDMI or DisplayPort cable
• Keyboard and mouse
• Ethernet cable or Wi-Fi module (optional, to
be installed manually)
2
Connect Devices
Connect your Monitor (HDMI/DP)
12th Generation Intel® Core™ Processor
DDR5 SODIMM x 2 (up to 64GB, 4800 MT/s)
HDMI 2.0b x 1 , DP++ 1.4a x 2
SATA3 x 2 (2.5"SSD x 2 containable)
RJ45 (2.5GbE) x 1, RJ45 (GbE) x 3
COM Port x 2 , DIO 8 bit x 1, DC Jack 12V in
Connect Keyboard & Mouse
Power Button
Connect Ethernet
Connect Power Adapter
Connect Ethernet
TCC x 1 (optional)
