Code 3 ARCH Beacon Installation & Operation Manual page 8

Flash Patterns (including for those beacons with task light option):
PATTERN NO.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
26
37
38
39
40
41
42
43
PATTERNS
NFPA Quad Phase 0
Cycle Flash 75fpm Phase 0
Quad 75fpm Phase 0
Triple 75fpm Phase 0
Double 75fpm Phase 0
Single 75fpm Phase 0
Variable Single Flash Phase 0
Rotate 75rpm
NFPA Quad Phase 1
Cycle Flash 75fpm Phase 1
Quad 75fpm Phase 1
Triple 75fpm Phase 1
Double 75fpm Phase 1
Single 75fpm Phase 1
Variable Single Flash Phase 1
Cycle Flash 150fpm Phase 0
Quad 150fpm Phase 0
Triple 150fpm Phase 0
Double 150fpm Phase 0
Single 150fpm Phase 0
Single 250fpm Phase 0
Single 375fpm Phase 0
Rotate 150rpm
Cycle Flash 150fpm Phase 1
Quad 150fpm Phase 1
Triple 150fpm Phase 1
Double 150fpm Phase 1
Single 150fpm Phase 1
Single 250fpm Phase 1
Single 375fpm Phase 1
NFPA Quad Alternating
Cycle Flash 75fpm Alternating
Quad 75fpm Alternating
Triple 75fpm Alternating
Double 75fpm Alternating
Single 75fpm Alternating
Cycle Flash 150fpm Alternating
Quad 150fpm Alternating
Triple 150fpm Alternating
Double 150fpm Alternating
Single 150fpm Alternating
Single 250fpm Alternating
Single 375fpm Alternating
SYNCHRONIZE
YES
YES
YES
YES
YES
YES
YES
Simultaneous Only
YES
YES
YES
YES
YES
YES
YES
YES
YES
YES
YES
YES
YES
YES
Simultaneous Only
YES
YES
YES
YES
YES
YES
YES
Simultaneous Only
Simultaneous Only
Simultaneous Only
Simultaneous Only
Simultaneous Only
Simultaneous Only
Simultaneous Only
Simultaneous Only
Simultaneous Only
Simultaneous Only
Simultaneous Only
Simultaneous Only
Simultaneous Only
8
