- Page 1 USER MANUAL MODEL: BLX-100D Single Manual BootScrubber (Dry) English (Original Instructions) Updated: 02/11/21...
- Page 2 Height - 44 in. brush and four removable vertical side brushes, each of which require no tools. Being a manual based, dry unit the BLX-100D requires no electrical or water connections. CAUTION: 1. Always follow plant and OSHA guidelines about the use of hygiene equipment.
- Page 3 [Figures 3.1 and 3.2] WARNING If not properly secured to floor the unit may tip over and has the potential to cause personal injury. Fig. 3.2: Front mounting brackets BLX-100D Manual Page 3 of 7 Updated: 02/11/21...
- Page 4 [Figure 4.3]. 3. Once unlocked, the brushes can be removed for cleaning, by slipping them out from their holders. Fig. 4.3: Brush clip rotation for brush removal BLX-100D Manual Page 4 of 7 Updated: 02/11/21...
- Page 5 1. Remove the Debris Tray and brushes from the unit. 2. Brushes and Debris Tray can be washed, individually, in a COP tank or wash machine 3. The frame can be washed down by conventional means. BLX-100D Manual Page 5 of 7 Updated: 02/11/21...
- Page 6 BRUSH FIXED 10-1/2 X 3 M1396 FRONT PLATE BLX MANUAL M1388 BRUSH BOX WLDMNT M1739 DEBRIS TRAY BLX-100D M1391 HANDLE WLDMNT BLX-100 M1740 DEBRIS SHIELD BLX-100D M1392 BRUSH CLIP P1248 LABEL SLIP HAZARD BLX-100D Manual Page 6 of 7 Updated: 02/11/21...
- Page 7 USER MANUAL: BLX-100D READ ALL INSTRUCTIONS BEFORE OPERATING EQUIPMENT Appendix B - Dimensions BLX-100D Manual Page 7 of 7 Updated: 02/11/21...
