- Page 1 USER MANUAL MODEL: BLX-200W Dual Manual BootScrubber (Wet) English (Original Instructions) Updated: 02/11/21...
-
Page 2: Specifications
Height - 42 in. brush and four removable vertical side brushes, each of which require no tools. Being a manual based, wet unit the BLX-200W requires no electrical and is pre- configured for easy plumbing of water and sanitizer. Water Requirements ▪... -
Page 3: Installation
5. Dosing of sanitizing chemicals into water supply can be accomplished via the included venturi injector. NOTE: The unit is compatible with most common sanitizers. For further plumbing recommendations please contact Clean Logix. Fig. 3.2: Mounting bracket locations BLX-200W Manual Page 3 of 9 Updated: 02/11/21... - Page 4 [Figure 4.2]. 3. Repeat for remaining bolts to secure the handrail (8 bolts total). Fig. 4.1: Installing Handrail Fig. 4.2: Handrail stablization bolts BLX-200W Manual Page 4 of 9 Updated: 02/11/21...
- Page 5 NOTE: A back flow preventer must be installed connect the sanitizer solution to be used to the in the water line for this unit. Check local Venturi's hose barb, as shown below: codes to ensure proper installation. BLX-200W Manual Page 5 of 9 Updated: 02/11/21...
- Page 6 4. Test the system by stepping on the footplate to engage the unit and begin spraying. 5. Adjust the solution output as necessary using the Fig. 6.1: Water line of BLX-200W included metering tips (instructions included). WARNING: DO NOT use flammable liquids (i.e. alcohol based solutions or similar) without dilution.
-
Page 7: Operation
2. Remove the Foot Plates and brushes from the unit. 3. Brushes and Foot Plates can be washed, individually, in a COP tank, or wash machine. 4. The frame can be washed down by conventional means. BLX-200W Manual Page 7 of 9 Updated: 02/11/21... -
Page 8: Appendix A - Parts Callout
VENTURI INJECTOR 3/8 SS P1358 PIPE BUSHING 1/2 X 3/8 SS P1100 PIPE HEX NIPPLE 3/8 SS P1398 PRESSURE REGULATOR WATER 1/2" SS P1102 PIPE NIPPLE 1/4 CLOSE SS P1599 METERING TIP, CAPILLARY TUBE BLX-200W Manual Page 8 of 9 Updated: 02/11/21... -
Page 9: Appendix B - Dimensions
USER MANUAL: BLX-200W READ ALL INSTRUCTIONS BEFORE OPERATING EQUIPMENT Appendix B - Dimensions BLX-200W Manual Page 9 of 9 Updated: 02/11/21...
