- Page 1 USER MANUAL MODEL: BLX-200D Dual Manual BootScrubber (Dry) English (Original Instructions) Updated: 02/11/21...
-
Page 2: Specifications
Height - 42 in. removable sole brushes and eight removable vertical side brushes, each of which require no tools. Being a manual based, dry unit the BLX-200D requires no electrical or water connections. CAUTION: 1. Always follow plant and OSHA guidelines about the use of hygiene equipment. -
Page 3: Installation
[Figure 3.2] WARNING If not properly secured to floor the unit may tip over and has the potential to cause personal injury. Fig. 3.2: Mounting bracket locations BLX-200D Manual Page 3 of 9 Updated: 02/11/21... - Page 4 [Figure 4.2]. 3. Repeat for remaining bolts to secure the handrail (8 bolts total). Fig. 4.1: Installing Handrail Fig. 4.2: Handrail stablization bolts BLX-200D Manual Page 4 of 9 Updated: 02/11/21...
- Page 5 [Figure 5.2]. 3. Once unlocked, the brushes can be removed for cleaning, by slipping them out from their holders. Fig. 5.2: Brush clip rotation for brush removal BLX-200D Manual Page 5 of 9 Updated: 02/11/21...
-
Page 6: Operation
1. Remove the Foot Plates and brushes from the unit. 2. Brushes and Foot Plates can be washed, individually, in a COP tank, or wash machine. 3. The frame can be washed down by conventional means. BLX-200D Manual Page 6 of 9 Updated: 02/11/21... - Page 7 USER MANUAL: BLX-200D READ ALL INSTRUCTIONS BEFORE OPERATING EQUIPMENT Notes: BLX-200D Manual Page 7 of 9 Updated: 02/11/21...
-
Page 8: Appendix A - Parts Callout
HANDRAIL BLX-200 M1262 BRUSH FIXED 10-1/2 X 3 M1398 REAR PLATE BLX-200 M1388 BRUSH BOX WLDMNT M1407 SPACER BLX-200 M1392 BRUSH CLIP M1416 DEBRIS TRAY M1393 FIXED SIDE BRUSH P1248 LABEL SLIP HAZARD BLX-200D Manual Page 8 of 9 Updated: 02/11/21... -
Page 9: Appendix B - Dimensions
USER MANUAL: BLX-200D READ ALL INSTRUCTIONS BEFORE OPERATING EQUIPMENT Appendix B - Dimensions BLX-200D Manual Page 9 of 9 Updated: 02/11/21...
