- Page 1 USER MANUAL MODEL: BLX-100W Single Manual BootScrubber (Wet) English (Original Instructions) Updated: 02/11/21...
-
Page 2: Specifications
Height - 44 in. brush and four removable vertical side brushes, each of which require no tools. Being a manual based, wet unit the BLX-100W requires no electrical and is pre- Water Requirements configured for easy plumbing of water and sanitizer. -
Page 3: Installation
5. Dosing of sanitizing chemicals into water supply can be accomplished via the included venturi injector. NOTE: The unit is compatible with most common sanitizers. For further plumbing recommendations please contact Clean Logix. Fig. 3.2: Front mounting brackets BLX-100W Manual Page 3 of 9 Updated: 02/11/21... - Page 4 2. Using 3/8" OD polyethylene tubing (or similar) in the water line for this unit. Check local connect the sanitizer solution to be used to the codes to ensure proper installation. Venturi's hose barb, as shown below: BLX-100W Manual Page 4 of 9 Updated: 02/11/21...
- Page 5 [Figure 5.2]. 2. Once unlocked, the brushes can be removed for cleaning, by slipping them out from their holders. Fig. 5.2: Brush clip rotation for brush removal BLX-100W Manual Page 5 of 9 Updated: 02/11/21...
-
Page 6: Operation
• Inspect structure for cracked welds or bent 2. Brushes and Foot Plate can be washed, components. individually, in a COP tank or wash machine 3. The frame can be washed down by conventional means. BLX-100W Manual Page 6 of 9 Updated: 02/11/21... - Page 7 USER MANUAL: BLX-100W READ ALL INSTRUCTIONS BEFORE OPERATING EQUIPMENT Notes: BLX-100W Manual Page 7 of 9 Updated: 02/11/21...
-
Page 8: Appendix A - Parts Callout
PIPE NIPPLE 1/4 X 3 SS P1338 METERING TIP, LOW FLOW 100-15KU P1355 VALVE PUSHBUTTON SS P1358 PIPE BUSHING 1/2 X 3/8 SS P1398 PRESSURE REGULATOR WATER 1/2" SS P1599 METERING TIP, CAPILLARY TUBE BLX-100W Manual Page 8 of 9 Updated: 02/11/21... -
Page 9: Appendix B - Dimensions
USER MANUAL: BLX-100W READ ALL INSTRUCTIONS BEFORE OPERATING EQUIPMENT Appendix B - Dimensions BLX-100W Manual Page 9 of 9 Updated: 02/11/21...
