World-Class Auto Security
TM
intelliguard
800
Owner's Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the intelliguard 800 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Clifford intelliguard 800

Summary of Contents for Clifford intelliguard 800

  • Page 1 World-Class Auto Security intelliguard Owner's Manual...

  • Page 2: Table Of Contents

    Table of Contents Standard Features of the IntelliGuard 8OO ....3 Welcome ....... . 7 Your 4-button/12-channel remote controls .
  • Page 3 How to erase the codes of lost or stolen remote controls ..23 All IntelliGuard Series systems are covered by one or more of the following Clifford Electronics patents: 4,158,874; 4,233,642; 4,327,444; 4,383,242; 4,430,685; 4,845,464;...

  • Page 4: Standard Features Of The Intelliguard 8Oo

    IntelliGuard systems on up to eight of your vehicles. Patented Remote Control Code Learning and MultiRemote™ Recognition — Add or delete, with a few flicks of a switch, up to four Clifford Anti-CodeGrabbing remote controls. Patent-Pending UltraSecure Coded Valet Mode turn off your IntelliGuard 800 like they can all other alarm brands.
  • Page 5 Remote Window and Sunroof Closure Capability BMW, Volkswagen and Jaguar, the IntelliGuard 800’s integrated timer can remotely close all the power windows and sunroof without the need for any optional modules.
  • Page 6 Deluxe Remote Keyless Entry in Valet Mode door locking/unlocking with visual parking light confirmations and interior light illumination even while the IntelliGuard 800 is in valet mode. — Automatically tests all system sensors Patented Smart AutoTesting™...
  • Page 7 Optional Tamper-Proof Ignition Immobilization optional relay, your vehicle’s ignition and fuel system are electronically disconnected while your IntelliGuard 800 is armed. Even if a thief were to find and remove the system control unit, he still would not be able to start the engine.

  • Page 8: Welcome

    Clifford’s unique PlainView Coded Valet Switch ensures that no thief, carjacker or joy-rider can turn off your IntelliGuard 800 like they can with all other car alarm brands. For total freedom from incorrectly adjusted sensors, there’s remote controlled adjustment of the system’s dual-zone Proximity...

  • Page 9: Your 4-Button/12-Channel Remote Controls

    ElectroLoop Antenna). Obstructions, electrical interference, weather conditions or a weak battery will reduce range. Your 4-button/12-channel remote control is the key to your IntelliGuard 800. It incorporates Clifford’s proprietary Anti-CodeGrabbing™ (ACG) technology with Random Code Generation for the ultimate in protection against “code-grabbing”...

  • Page 10: What Each Button/Channel Does

    What each button/channel does Your IntelliGuard 800 remote controls come pre-programmed so that certain channels command certain functions. If you wish, you can actually assign any channel (except 9 through 12) to any function (see pages 20–22). The following chart indicates what each remote control channel number does, and how to transmit each channel number.

  • Page 11: Antiscan

    14 for details. AntiScan™ Thieves can disarm some other brands of car alarms with a “scanner” than rapidly transmits one remote control code after another. Clifford’s AntiScan will detect any scanner and block the codes it generates.

  • Page 12: Ultrasecure™ Coded Valet Mode

    Within seconds, thieves can disable all other alarm brands by hot-wiring the ignition and flicking an easy to find “hidden” valet switch. Your IntelliGuard 800 has safeguards that absolutely ensure that a thief cannot enable the valet mode as a way of “turning off” your system.

  • Page 13: To Enable Valet Mode

    To enable valet mode 1. Turn the ignition switch to its “ON” position or start the engine. 2. Enter your secret valet code on the PlainView switch, then return the switch to its center position. 3. You now have 3 seconds to press the latched position (valet mode). Once you have entered valet mode, the system’s LED will glow continually for on-going visual confirmation of valet mode.

  • Page 14: Anti-Codegrabbing™ (Acg) With Random Code Encryption

    ACG with Random Code Encryption. Enhanced AutoArming™ If this feature is enabled and you forget to remotely arm your IntelliGuard 800, the system will arm itself automatically (“passively”) 30 seconds after the vehicle doors are closed. For your convenience, if you re-open any door(s) within the 30-second countdown, AutoArming will restart from the beginning once all doors are closed.

  • Page 15: Electronically Programmable Dual-Zone Proximity Sensor

    Electronically Programmable Dual-Zone Proximity Sensor™ Your IntelliGuard 800’s Dual-Zone Proximity Sensor has both an outer and an interior zone. The outer “warning” zone can detect potential vandals and thieves lurking near your vehicle before they even have a chance to touch your automobile. Anyone lingering too near your vehicle will bee warned away with a distinctive one-second warning tone.

  • Page 16: Fact - False Alarm Control And Test

    Other, non-Clifford alarms may leave you stranded. Optional tamper-proof ignition immobilization If your IntelliGuard 800 is equipped with the ignition immobilization option, while armed, the system ensures that your vehicle is completely immobilized by automatically locking out the ignition system.

  • Page 17: Smart Autotesting

    Automatic malfunction bypass To provide the utmost protection even if a system component malfunctions, your IntelliGuard 800 will automatically bypass any faulty point and arm all other triggers and sensors until you can have the system serviced by your local Authorized Dealer.

  • Page 18: Multiple-Event Totalrecall

    If your vehicle already has a similar warning feature, you may turn off your IntelliGuard 800’s Headlight Reminder feature. See the User-selectable features section on pages 20–22.

  • Page 19: Smart Trunk Release Capability

    See the User-selectable features section on pages 20–22. High-output MultiSound Medallion™ Siren All the electronics for the siren are built into the IntelliGuard 800’s control unit rather than the siren itself. This protects the circuitry from engine heat, dirt and exposure to the elements (in contrast, the electronics of other alarm companies’...

  • Page 20: Long-Term Chirp Silencing

    Whenever you wish, you may silence your Long-term chirp silencing: IntelliGuard 800’s arm and disarm chirps until you decide to restore them. The parking light flashes will continue to provide visual confirmation of remote controlled arming and disarming. See User-selectable features on pages 20–22.

  • Page 21: User-Selectable Features

    User-selectable features Your IntelliGuard 800 allows you to set many of its features to your own personal preferences. Although the system’s programming capabilities are very extensive, we have made the programming procedures very simple: to make a change, you just flick the PlainView switch a few times.

  • Page 22: Matrix Of User-Selectable Features

    8–9 NOTE 6 info on page 12 NOTE 9 Gray cells indicate features that require programming by trained Clifford installers. DO NOT change any of these settings. NOTE 7: Turn off the ignition, leave the driver’s window open and exit the vehicle. To test the current sensitivity, lean into the passenger compartment through the window.

  • Page 23: Example 1: Turn Off Siren Sound Number 2

    Clifford Dealer (or call our 24-hour Customer Service Department at 800-824-3208) and program them into the system yourself. Each IntelliGuard 800 will respond to as many as four 12-channel remote controls. To add a new remote control to the system, use the procedures noted in the User-selectable features section on pages 20–22.
