TITAN DK 3700C
English
O
'
M
PERATOR
S
ANUAL
MICHEL VAN DE WIELE N.V.
Avenue Sleeckx 41C
B-1030 BRUSSELS -BELGIUM
Phone : ++32/2 216 31 40
Fax : ++32/2 242 41 89
E-mail :
info@titansew.com
Web :
www.titansew.com

Advertisement

loading
Need help?

Need help?

Do you have a question about the DK 3700C and is the answer not in the manual?

Questions and answers

Related Manuals for Titan DK 3700C

Summary of Contents for Titan DK 3700C

  • Page 1 TITAN DK 3700C English PERATOR ANUAL MICHEL VAN DE WIELE N.V. Avenue Sleeckx 41C B-1030 BRUSSELS -BELGIUM Phone : ++32/2 216 31 40 Fax : ++32/2 242 41 89 E-mail : info@titansew.com Web : www.titansew.com...
  • Page 2 4. Upper and Lower Transport 5. Driving Belt CHAPTER 5 : FOLDERS 1. Dimensions CHAPTER 6 : HOW TO SEW CORNERS WITH LARGE RIBBONS CHAPTER 7 : HOW TO SEW THE LAST CORNER CHAPTER 8 : SPARE PARTS LIST Instruction Manual TITAN DK3700C...
  • Page 3 (200-300 rpm) for a few minutes in order to allow the oil to reach the needle bar. B. Head only The TITAN sewing head requires a drive motor with following specifications :  Motor rating : ¾ HP (Horse Power)  Motor speed : 2800 rpm ...
  • Page 4 ITEM2. ANTI VIBRATION ISOLATOR BLOCS Instruction Manual TITAN DK3700C...
  • Page 5 ITEM5. FILLER PLUG TO PUT THE OIL IN. Instruction Manual TITAN DK3700C...
  • Page 6 ITEM12. THIS IS THE SENSOR ON THE MACHINE. Instruction Manual TITAN DK3700C...
  • Page 7 Instruction Manual TITAN DK3700C...
  • Page 8 INSTALLATION ELECTRONIC MOTOR SWITCH ON/OFF ON MOTOR - 1 - Instruction Manual TITAN DK3700C...
  • Page 9 IS THE CONNECTION TO THE POSITIONER RED MARK - 2 - Instruction Manual TITAN DK3700C...
  • Page 10 IS THE CONNECTION TO THE SENSOR YELLOW MARK USE THE BELT TO CONNECT THE MOTOR - 3 - Instruction Manual TITAN DK3700C...
  • Page 11 PNEUMATIC TUBES MARKED TUBE TO THE MARKED TUBE BROWN BROWN - 4 - Instruction Manual TITAN DK3700C...
  • Page 12 MARKED TUBE TO THE MARKED TUBE ORANGE ORANGE - 5 - Instruction Manual TITAN DK3700C...
  • Page 13 -3A - Instruction Manual TITAN DK3700C...
  • Page 14 Conversely, high viscosity oil will cause clogging of the oil lines, which in turn will cause poor lubrication and abnormal wearing out of the internal parts, resulting in break down of the machine. - 3 - Instruction Manual TITAN DK3700C...
  • Page 15 Instruction Manual TITAN DK3700C...

  • Page 16: Chapter 2 : Threading

     It is not advised to use monofilament yarn for the looper yarn, as this will cause false stitches and thread breakage. 2. THREADING DIAGRAM Thread the needle and looper yarns as seen on Fig 3. Instruction Manual TITAN DK3700C...
  • Page 17 Instruction Manual TITAN DK3700C...

  • Page 18: Needle Yarn

    A is placed lower. The optimal distance between the threader B and the yarn guide A is +/- 38 mm when the needle is its lowest dead point. - 5 - Instruction Manual TITAN DK3700C...
  • Page 19 Fig 6 - 6A- Needle in his higher point Instruction Manual TITAN DK3700C...
  • Page 20 Correct needle position Put the needle in its highest dead point and measure the distance between the point of the needle and the needle plate. This should be exactly 19 mm .(Fig 6) - 6 - Instruction Manual TITAN DK3700C...
  • Page 21 Instruction Manual TITAN DK3700C...
  • Page 22  Turn the flying wheel further and check also if : when the looper is coming back , it crosses the needle exactly in the center of the flat side of the needle (as seen in FIG 8). - 7 - Instruction Manual TITAN DK3700C...
  • Page 23 Fig 9 - 8A – Instruction Manual TITAN DK3700C...

  • Page 24: Advanced Settings

    7. Check if the distance from the point of the speader doesn’t exceed 0.1mm above the back of the looper. Turn the flying wheel and check that the spreader and the looper don’t touch each other or other parts when moving. - 8 - Instruction Manual TITAN DK3700C...
  • Page 25 - 9A – Instruction Manual TITAN DK3700C...

  • Page 26: Driving Belt

    Fig 2 page.. 9. Fix the screws C and reassemble the parts in the opposite sequence as described in the beginning of this paragraph. (Step 3 then 2 then 1). - 9 – Instruction Manual TITAN DK3700C...
  • Page 27 FOLDERS 1. DIMENSIONS IMPORTANT INFORMATION ABOUT FOLDERS FOR DK3700C Facts to consider when ordering a machine : TITAN DK3700C The sewing machine can handle the most difficult carpet qualities. There is no mechanical limit due to the sewing head. REMARK : a good test is to sew some carpet WITHOUT ribbon, to see if the stitch formation is done correctly.
  • Page 28 12 – 5 mm = 7 mm /2 = 3.5 mm of ribbon left over between the edge of the carpet and the edge of the ribbon. Loosely folded ribbon around carpets are not selling well to the final customers. - 11 - Instruction Manual TITAN DK3700C...
  • Page 29 19. Fold the loose part of the ribbon in a corner and glue the folded ribbon onto the carpet. It is also possible to sew this last corner by hand. 20. The three other corners are also often glued are sewed by hand to give to them their final finished look. - 12- Instruction Manual TITAN DK3700C...
  • Page 30 HOW TO MAKE CORNERS WITH TITAN DK 3700C A) 1 Cut an point at the beginning of the ribbon to make it easier to introduce the ribbon in the folder B) INTRODUCE THE RIBBON IN THE FOLDER BY HAND C) INTRODUCE THE CARPET IN THE FOLDER.(make sure that...
  • Page 31 E) TURN THE HANDLE TO THE RIGHT TO OPEN THE FOLDER F) TURN THE BUTTON TWICE SITUATED IN THE MIDDLE OF THE MACHINE HEAD to give extra length of thread G) PULL THE CARPET BACKWARDS UNTIL THE THREAD IS STRETCHED or UNTIL THE EDGE OF THE CARPET IS PARALLEL TO THE END OF THE...
  • Page 32 H) TURN THE MAT FOR ABOUT 90° with your left hand. Pull and push the mat to position the carpet and the folded corner well inside the folder. I) Pull and push the mat to position the carpet and the folded corner well inside the folder J) CLOSE THE FOLDER by...
  • Page 33 K) MAKE THE FIRST STITCH BY HAND BY TURNING THE FLYING WHEEL L) SEW THE SECOND SIDE OF THE CARPETTHE MACHINE WILL AGAIN STOP EXACTLY AT THE END OF THE CARPET DUE TO THE ELECTRONIC EYE. M) REPEAT STEP 1 TILL8 FOR THE 2 AND 3rd CORNERS...
  • Page 34 O) Open the folder with the handle.Lift the pressure foot by pushing on the pedal. Give more thread by pulling by hand the upper threads. Pull the carpet out of the folder at the back. P) Cut the ribbon. Leave about 2 cm extra ribbon Q) Turn the carpet and fix the last stich by making a knot.
  • Page 35 CHAPTER 7 : HOW TO SEW THE LAST CORNER ? 1. THIS IS THE LAST SEWING PROCEDURE BEFORE MAKING THE LAST CORNER.
  • Page 36 2. GLUE-ING THE FIRST CORNER, (WHERE YOU STARTED) IN ORDER TO AVOID THAT THE TAPE IS STANDING OPEN...
  • Page 37 3. YOU START SEWING TO THE LAST CORNER UNTIL THE STITCH ON THE PREVIOUS SIDE. THIS IS THE LAST STITCH YOU HAVE TO STOP SEWING NOW AND CUT THE TAPE.
  • Page 38 4. YOU CLOSE THE LAST STITCHES WITH A KNOB.
  • Page 39 5. CUT THE TAPE INTO THE DIRECTION OF THE CORNER...
  • Page 40 6. THIS IS THE RESULT...
  • Page 41 7. YOU MANUALY FOLD THE TAPE IN A CORNER.
  • Page 42 8. YOU GLUE THIS CORNER WITH A HOTGLUE GUN...
  • Page 43 9. PUT SOME PRESSURE ON THIS CORNER TO MAKE IT FLAT...
  • Page 44 10. YOU CUT THE REST OF THE TAPE OUTSIDE THE CORNER...
  • Page 45 11. YOU PUT THE REST OF THE CORNER WITH A PAIR OF TWEEZERS INSIDE THE CORNER.
  • Page 46 12. GLUE THIS LAST CORNER WITH A HOTGLUE GUN.
