Kohler VERDERA K-29853T Installation Instructions

BEFORE YOU BEGIN
•
Please read these instructions carefully to familiarize yourself
with the required tools, materials, and installation sequences.
Follow the sections that pertain to your particular installation.
This will help you avoid costly mistakes. In addition to proper
installation, read all operating and safety instructions.
•
All information in these instructions is based upon the latest
product information available at the time of publication. Kohler
China. reserves the right to make changes in product
characteristics, packaging, or availability at any time without notice.
•
These instructions contain important care, cleaning, and warranty
information-please leave instructions for the consumer.
•
Before installation carefully inspect the new fixture for any signs
of damage.
•
The product complies with GB/T10357.4-2013,
GB/T10357.5-2013, GB24977-2010 and GB9254-2008.
WARNING: Risk of electrical shock. A licensed
electrician should make all electrical connections.
WARNING: Risk of electrical shock. Connect only to a
circuit protected by a typical two-pole circuit breaker.
WARNING: Risk of electrical shock. Disconnect power
before servicing.
TOOLS REQUIRED
ACCESSORIS LIST
1PCS
ROUGHING-IN
Reference Value
参考值
ZHONGSHAN KOHLER SHOWER CO., LTD. ZHONGSHAN KOHLER SHOWER CO., LTD.
DEVELOPMENT ZONE, ZHONGSHAN, GUANGDONG, CHINA DEVELOPMENT ZONE, ZHONGSHAN, GUANGDONG, CHINA
中山科勒卫浴有限公司 广东省中山市中山火炬开发区兴业路 13-1 号 邮编： 528437 中山科勒卫浴有限公司 广东省中山市中山火炬开发区兴业路 13-1 号 邮编： 528437
1461645-T01-A
3PCS 2PCS
900
499 399
K-29855T
VERDERA DISPLAY 新维乐智讯
K-29853T/K-29854T/K-29855T/K-29856T
安装之前
请仔细阅读本指引，以便熟悉所需工具、物料及安装程序。请遵照
•
适用的章节来安装本产品，以免安装失当导致不必要的损失。除了
有关正确的安装方法之外，还务请详阅所有操作及安全指引。
本指引所载之一切资料，均以印刷时所有之最新产品情况为基础，
•
科勒中国保留权利随时更改产品特性、包装或供应情况，恕不另行
通知。
说明书包括重要的安装、清洁及保养方面的内容，请把这些资料交
•
给用户阅读，保管。
安装之前，仔细检查产品是否有损伤。
•
本产品符合 GB/T10357.4-2013, GB/T10357.5-2013，
•
GB24977-2010 和 GB9254-2008。
警告：有触电的危险。
请找合格的电工来进行所有的线路连接。
警告：有触电的危险。
仅能和双极型断路器保护的电路连接。
警告：有触电的危险。
工作之前先切断电源。
所需工具
附件清单
1PCS 14PCS
尺寸图
600
NO13-1, XINGYE ROAD, ZHONGSHAN TORCH NO13-1, XINGYE ROAD, ZHONGSHAN TORCH
© Copyright Kohler China Investment Co., Ltd. 2020 © Copyright Kohler China Investment Co., Ltd. 2020
© 版权为科勒 （中国） 投资有限公司所有 2020 © 版权为科勒 （中国） 投资有限公司所有 2020
-1- -1-
INSTALLATION INSTRUCTIONS
MIRRORED CABINET
φ 6
5PCS 5PCS
125
K-29856T
POST CODE: 528437 POST CODE: 528437
安装说明书
镜柜
5PCS
UNIT: mm
单位 : 毫米
