Summary of Contents for Akces-Med ASTRIDE
- Page 1 STATIC STANDING FRAME A S T R I D E USER MANUAL...
- Page 2 Akces-MED Ltd. employee or at specialized medical store! Akces-MED Ltd. reserve the right to introduce technical and trading changes in the content of the instruction without warning. Product marked with the CE sign is Class I medical device, of rule 1, consistent with the ...
-
Page 3: Table Of Contents
6.1 The preparation of user....................6.2 The preparation of standing frame................. 6.3 Upright position......................... 7. Safety rules..........................8. Terms of warranty........................9. Maintenance and cleaning..................... 10. Labelling..........................10.1 Symbols..........................10.2 Sample data plate......................www.akces-med.com +48 17 864 04 77 export@akces-med.com... - Page 4 If you have any questions or remarks, do not hesitate to contact with us: Medical consultant: mobile +48 516 183 883 Akces-MED Ltd: ph. +48 17 864 04 70 e-mail: export@akces-med.com Before using the stander, read this user manual which is essential for proper and safe usage of the stander.
-
Page 5: The Purpose Of User Manual
, and for both doctors as well as physiotherapists who operate the device. Before using the ASTRIDE standing frame, user is obliged to familiarize himself / herself with user manual. 2. INDICATIONS AND CONTRINDICATIONS FOR USE... - Page 6 200/110 mmHg, pulmonary hypertension, cardiac arrythmias, moderate heart valve disease); respiratory system (unstable asthma) and unstable metabolic disorders, it is necessary to monitor the user while standing in order to prevent serious complications. www.akces-med.com +48 17 864 04 77 export@akces-med.com...
-
Page 7: General Characteristic
1. Frame with wheels equipped with STOP brakes 2. Platform with feet stabilizers and abduction function 3. Independently adjustable knee supports 4. Pelvic belt with pelvic rotation function 5. Chest belt with independent adjustment of chest rotation 6. Tray www.akces-med.com +48 17 864 04 77 export@akces-med.com... -
Page 8: Size Table
Unit Size 1 [cm] width [cm] 67,2 length height [cm] 80,7 weight [kg] 18,5 Note: Measurement tolerance range is +/- 1 cm / ½ in. Note: Approximate values, depending on the product configuration www.akces-med.com +48 17 864 04 77 export@akces-med.com... -
Page 9: Description How To Use Standing Frame
3. Tighten the knobs. Please note that when you change the height of the column of the standing frame, the height of the tray, the hip belt and the chest belt also change. www.akces-med.com +48 17 864 04 77 export@akces-med.com... -
Page 10: Knee Supports Adjustment
5.2.2 KNEE SUPPORTS DEPTH ADJUSTMENT The depth of the knee supports is adjusted with the one knob for each of the supports (fig. 5, 6). www.akces-med.com +48 17 864 04 77 export@akces-med.com... -
Page 11: Knee Supports Spacing Adjustment
5.3 PELVIC / CHEST BELT ADJUSTMENT 5.3.1 ADJUSTMENT OF THE HEIGHT OF THE PELVIC / CHEST BELT The height of the pelvic / chest belt is adjusted with one knob for each belt (fig. 8, 9). www.akces-med.com +48 17 864 04 77 export@akces-med.com... -
Page 12: Adjustment Of The Width Of The Pelvic / Chest Belt
The adjustment is done independently on the right and left side of the belts, allowing for lateral positioning and rotation of the user in the standing frame. The belts are additionally secured with a buckle. www.akces-med.com +48 17 864 04 77 export@akces-med.com... -
Page 13: Tray Adjustment
5.5.1 FEET SPACING ADJUSTMENT Each feet stabilizer is blocked with two knobs. By loosening the knobs, you can set the user's feet in the proper position, including the abduction. Make sure to tighten the knobs properly. www.akces-med.com +48 17 864 04 77 export@akces-med.com... -
Page 14: Adjustment Of The Front And Back Movement And Rotation Of The Feet
OF THE FEET Each feet stabilizer has a front - back and rotation adjustment. The adjustment is possible after loosening the knobs located under the stabilizers. Make sure to tighten the knobs properly. www.akces-med.com +48 17 864 04 77 export@akces-med.com... -
Page 15: The Use Of Standing Frame
THE USE OF STANDER Before using the ASTRIDE stander, read this user manual. Before each use, prepare the user and the device! 6.1 PREPARATION OF THE USER Before using the product, it is essential to make sure that: § user's outfit is light and comfortable sporty clothes are advisable, §... -
Page 16: The Preparation Of Standing Frame
4. Move the user and place him in a standing frame. We ought to make sure that all alignments are preserved. Implement corrections if necessary. 5. Fasten belts stabilizing chest, hips and foot. 6. Make sure that all belts and precautions were correctly adjusted and fastened. www.akces-med.com +48 17 864 04 77 export@akces-med.com... - Page 17 4. Unfasten belts which stabilize foot, hips and chest. 5. Make sure that all belts and precautions do not block the user. 6. Move the user and place him on a prepared device. www.akces-med.com +48 17 864 04 77 export@akces-med.com...
-
Page 18: Safety Rules
It is highly important to consult either doctor or physiotherapist in order to make right decision concerning the choice of ASTRIDE and its size. It is also essential to familiarize with the guidelines described in user manual before using the device. - Page 19 If the symptoms have disappeared, inform the attending physician about this fact in order to make a decision about the further rehabilitation process. Serious incidents involving this device should be reported both to manufacturer and to the competent authority in your country. www.akces-med.com +48 17 864 04 77 export@akces-med.com...
-
Page 20: Terms Of Warranty
Next, manufacturer determines again how long the product can be used and, moreover, the date of the next service will be determined. If product is damaged, please contact our dealer or Akces-MED Ltd. customer § service (ph. +48 17 864 04 77, e-mail: export@akces-med.com). -
Page 21: Maintenance And Cleaning
Remember that upholstery has to be always dry before using! The manufacturer of the standing frame, Akces-MED Ltd., is not responsible for any damages caused by using unsuitable cleaners. www.akces-med.com +48 17 864 04 77 export@akces-med.com... - Page 22 Manufacturer takes responsibility only for hidden faults or damages which appeared despite the fact that user complied with the guidelines. In case of any damages, it is essential to contact the person who sold you the product. www.akces-med.com +48 17 864 04 77 export@akces-med.com...
- Page 23 Before using the Remove dirt (e.g. hair, food remains, etc.) product, check if the upholstery is dry. from the moving parts of the product. www.akces-med.com +48 17 864 04 77 export@akces-med.com...
- Page 24 After that, the manufacturer will re-define the life time of the product and the date of the next check. The list of all spare parts is available for download after selecting a product on www.akces-med.com. www.akces-med.com +48 17 864 04 77 export@akces-med.com...
-
Page 25: Labelling
PRODUCT NAME EN directs you to the product's website MAX LOAD: 55 kg MAXIMUM PERMISSIBLE LOAD MANUFACTURER ON THE PRODUCT ADDRESS LABELLING DATE OF PRODUCTION look up SERIAL NUMBER IN BARCODE FORM SERIAL NUMBER www.akces-med.com +48 17 864 04 77 export@akces-med.com... - Page 26 MANUFACTURER Akces-MED Ltd. Jasionka 955B 36-002 Jasionka Poland ph. +48 17 864 04 70 e-mail: export@akces-med.com BDO: 000031619 Authorised Dealer Date of issue: 19.07.2021 The last update: 19.07.2021 © Sławomir Wroński 2021...
