Preface; Revision History - mycom SCV Series Instruction Manual

Thank you for purchasing the
"this product").
This instruction manual (hereinafter referred to as "this manual") describes safety information,
operational and detailed maintenance procedures for safe and effective use of this product、It is
applicable to the following compressor types
160VSD, 160VMD, 160VLD, 200VSD, 200VMD, 200VLD, 250VSD, 250VMD, 250VLD, 250VLLD,
320VSD, 320VMD, 320VLD
160VSG, 160VMG, 160VLG, 200VSG, 200VMG, 200VLG, 250VSG, 250VMG, 250VLG, 250VLLG
Before installing or using this product, make sure you read this manual.
Keep this manual in a safe place near this product for quick reference whenever needed.
Title of Instruction Manual
SCV-series Instruction Manual
Issue Date
Rev. No.
00 Feb. 17, 2015
01 June 12, 2015
02 Feb.28.2018
03 Mar.11.2019
04 Jun.11.2019
05 Jan.07.2020
SCV-series Screw Compressors

Preface

SCV-series/screw compressor (hereinafter referred to as

Revision History

2205Q2JE-HO-S6-N_2020.01.
Revision Details
Complete revision and reissue as an electronic manual.
Corrected errors in writing (e.g., footer in Chapter 2)
Corrected Table 2-1, 2-5, 3-1, 4-2, 7.Parts Configuration
Table, 7.5.1 List of O-rings Used, Corrected other errors.
Deleted Contact Information
7.Parts Configuration Table of 250V** models
Correction of the outer dimension.
Revision of lock nut tightening angle.
Correction of errors and sentences. Revision of parts list Takita,Takenouchi / Muta
Document No.
i
2205Q2JE-HO-S6-N_2020.01.
Preface
Date of Initial Issue
February 17, 2015
Prepared/Approved by
Ikehara/ Muta
Ikehara/ Muta
Takenouchi・Ito / Kato
Takenouchi / Kato
Muta / Kato
