mycom SCV Series Instruction Manual page 140

P/N
82 V-ring
83 Spring
84 Retainer, Indicator Cam Spring
91 Shaft Key
92 Suction Flange
Gasket, Suction Flange
93
94 Hexagon Head Bolt
95 Discharge Flange with hole
95 Discharge Flange without hole
95 Discharge Flange without hole
Gasket, Discharge Flange (for the case V*G
96
model or V*D model used No.235)
Hexagon Head Bolt (for the case that is not
97
using No.235 Discharge flange spacer)
Hexagon Head Bolt
97
No.235 Discharge flange spacer)
100 Mechanical Seal Assembly
100 Mechanical Seal Assembly
100 Mechanical Seal Assembly
100 Mechanical Seal Assembly
120 Unloader Indicator Assembly
125 Micro-Switch
127 Micro-Switch Cam
129 Wire wound type Potentiometer
129 Conductive Plastic type Potentiometer
137 Indicator Dial
Flange, Lubricating Oil inlet (Journal)
215
with hole
216 Gasket, Lubricating Oil inlet Flange
217 Hexagon Head Bolt
Spacer, Discharge Flange
235
(This spacer is not necessary for CD flange.)
236 Gasket, Discharge Flange Spacer
237 Torsional Slip Washer
250 Thrust Washer
251 Electromizer (Economizer) Flange with hole
252 Gasket. Electromizer (Economizer) Flange
253 Hexagon Head Bolt
254 Liquid Injection (Aquamizer) Flange
255 Gasket, Liquid Injection Flange
256 Hexagon Head Bolt
Special Spring Washer, Hexagon Socket Head
267
Cap Screw
289 Variable Vi auxiliary Slide Valve
289 Variable Vi auxiliary Slide Valve
289 Variable Vi auxiliary Slide Valve
325 O-ring
326 O-ring Gland
420 Spacer, Unloader Positioning
420 Spacer, Unloader Positioning
421 O-ring
SCV-series Screw Compressor
Part Name
with hole
(for the case using
7-12
2205Q2JE-HO-S6-N_2020.01.
Chapter 7 Related Documents
Code No.
CS08200-200B 20X10X12
CS08300-200 200V**
CS08400-200 200***
CS09100-200 200***
CS71400-P150MK MYK150A(6")
CR72000-150N MYK150A
NB12120-055 M22X55
CS74100-125MK MYK125A Female
CS74100-P125MK MYK125A(5")
CS74100-125CDMK MYK125CD
CR72000-125N MYK125A
NB12020-055 M20X55
NB12120-080 M20X80
CS10002-200EBS 200BBSE
CS10001-200BBS 200*** BBS3
CS10000-200BE 200*** BOS TYPE
CS10009-200-F70 200*** UV-4
CS120-IND063WP-
V-series 0-100%
VP
CS12501-INDO6P 200*** Z15GW
CS1279-200V 200VS\L
CS12900-INDO6P with wires
CS12900-INDO6P with wires
CS13700-200VD 200V** L,M,H-port
MM(MYK)
CR74000-020
20A(3/4")
CR72000-020N MYK20A
NB111012-035 M12 X35
FX101-200 200V**
CS23600-200N 200V**
CS23700-200 200***
CS25000-200 200***
MM(MYK)
CR74000-032
32A(l"1/4)
CR72000-032N MYK32A
NB111012-040 M12X40
CR74000-025 MM(MYK) 25A(1")
CR72000-025N MYK25A
NB15512-035 M12X35
ND330-08 M8
CS28900-200VSD 200VS*
CS28900-200VMD 200VM*
CS28900-200VLD 200VL*
PA11-040 JIS B 2401 P40
CS32600-200VD 200V**
CS42000-200VSD 200VS*
CS42000-200VMD 200VM*
PA11-040 JIS B 2401 P40
7.2 Parts Configuration Table 200V**
Remarks Q'ty.
1
1
1
1
1
1
8
1
1
1
1
8
8
1
-
-
-
1
2
1
1
-
1
1
1
2
1 (V*D)
1 (V*D)
2
2
1
1
4
1
1
4
5
1 (VS*)
1 (VM*)
1 (VL*)
2
1
1 (VS*)
1 (VM*)
2 (VS*)
