DISASSEMBLY AND ASSEMBLY
8. To remove wind guide assembly.
1) Rem ove a screw for earthing.
2) Rem ove the noise filter from the wind guide.
3) Rem ove a screw which secure the wind guide assem bly.
4) Draw forward the wind guide assem bly.
5) Pull the fan from the m otor shaft.
6) Rem ove two screws which secure the m otor shaded pole.
7) Rem ove the m otor shaded pole.
8) Reverse the above steps for reassem bly.
9. To remove H.V.transformer.
1) Rem ove four screws holding the H.V.transform er.
2) Rem ove the H.V.transform er.
3) Reverse the above steps for reassem bly.
