BIN WAREHOUSE 12-TOTE COMPACT Assembly Instructions

Download this manual

12-TOTE COMPACT MODEL ASSEMBLY INSTRUCTIONS

TOOLS REQUIRED

1. Powered Screwdriver with

#2 Phillips-Head Tip

PARTS LIST

1. (8) Horizontal Crossbars

2. (4) Center Verticals

3. (2) Left & Right Rear Corner Verticals

4. (1) Left Front Corner Vertical

5. (1) Right Front Corner Vertical

6. (4) Wall Mount Flanges

7. (4) Wall Mount Extension Tubes

8. (12) Horizontal Sliderails

FASTENER LIST

1. (60) #06 x 1/2" Fastening Screws

2. (08) #08 x 3/4" Wall Mount

Extension Tube Fastening Screws

3. (12) #10 x 1-1/2" Wall Mount

Flange Screws

4. (12) Plastic Wall Anchors

TIP

Separate All Parts into Groups

(as shown) and Familiarize.

Read All Instructions Before

Beginning Assembly.

Solutions Murales PROSLAT inc.

225 Industriel blvd

Chateauguay (QC) J6J 4Z2

1 888 691-2944

Need help?

Do you have a question about the 12-TOTE COMPACT and is the answer not in the manual?

Page 1 Solutions Murales PROSLAT inc. 225 Industriel blvd Chateauguay (QC) J6J 4Z2 1 888 691-2944 12-TOTE COMPACT MODEL ASSEMBLY INSTRUCTIONS TOOLS REQUIRED 1. Powered Screwdriver with #2 Phillips-Head Tip PARTS LIST 1. (8) Horizontal Crossbars 2. (4) Center Verticals 3. (2) Left & Right Rear Corner Verticals 4.
Page 2 IMPORTANT: Do not install any fasteners until instructed! Numbers in BOLD indicate item number from Parts/Fastener Lists. FRONT GRID ASSEMBLY Step 1 Step 2 Step 3 Alignment Dimples Alignment Dimples Down Holes down Warning Labels Short side down Holes down Parts Needed: 4 Horizontal Crossbars (#1) inserted through 1 Left Front Corner Vertical (#4) and 1 Right Front...
Page 3 Flanges (#6) and fasten with 4 - #06 x 1/2" Fastening from tipping over! Wall Anchors (#4) if needed. Screws (#1). Note: If mounted into Masonry or Drywall, drill Note: 1 Screw per Flange three 1/4" holes to accept Plastic Wall Anchors. Congratulations! We Hope You Enjoy Your Bin Warehouse!
