COMPONENTS AND PARTS LIST
FT-206A
29.5" x 18.5" x 10.25"
97 Lbs
FT-206E
47.5" x 23.5" x 9"
239 Lbs
FT-206 Austin Fountain
(5 pieces)
FT-206B
12.75" x 8.5" x 16"
105 Lbs
FT-206C
14" x 10" x 8"
41 Lbs
FT-206D
5.75" x 1.75" x 4.75"
4 Lbs
Revised August 23, 2013
This fountain
uses cover
FTNCOV-MED
NOTE: Component photos are not to scale
Pump Kit Parts List
PK500 Pump (1)
Approx. 30" of ½" Non-Kink Black Tubing (1)
Approx. 2" of ⅝" Clear Vinyl Tubing (1)
Copper Sleeve (⅝" i.d.) (1)
4 ½" length of ½" i.d/ ⅝" o.d. Copper Pipe (1)
Copper Spiller (2)
4mm Allen wrench (1)
Wedges (3)
Hose Clamps (2)
#10 Compression Stopper (1)
Note – Hose clamps may be used for flow restrictor
Tools you will need
Level
4mm Allen wrench (included)
Fountain holds
approximately 17
gallons of water
