User's Manual（Preliminary） IECUBE2 main (QB-V850E2)
Readers
Purpose
Organization
How to Read This Manual
Conventions

INTRODUCTION

This manual is intended for users who wish to perform debugging using the
QB-V850E2 (generic name: IECUBE2). The readers of this manual are assumed to
be familiar with the device functions and usage, and to have knowledge of
debuggers.
This manual is intended to give users an understanding of the basic specifications
and correct usage of the IECUBE2.
This manual is divided into the following sections.
 General
 Names and functions of Hardware
 Optional function
 Notes
It is assumed that the readers of this manual have general knowledge in the fields of
electrical engineering, logic circuits, and microcontrollers.
This manual describes the basic setup procedures and how to set switches.
To understand the overall functions and usages of the IECUBE2
 Read this manual in the order of the CONTENTS.
To know the manipulations, command functions, and other software-related settings
of the IECUBE2
 See the user's manual of the debugger to be used.
Note:
Caution:
Remark:
Numeric representation:
Prefix indicating power of 2
(address space, memory
capacity):
ZUD-CD-10-0092
Footnote for item marked with Note in the text
Information requiring particular attention
Supplementary information
Binary ... xxxx or xxxxB
Decimal ... xxxx
Hexadecimal ... xxxxH
10
K (kilo): 2 = 1,024
20 2
M (mega): 2 = 1,024
