- Page 1 Assembly Instructions Caution: You must read this before you proceed Left 3 Seater Noble House Home Furnishings LLC Page 1 OF 12...
-
Page 2: Part List
Part List Label Picture Description Backrest Left Armrest Seat Seat Cushion Sofa Leg Middle Support Leg Noble House Home Furnishings LLC Page 2 OF 12... -
Page 3: Assembly Preparation
Hardware Label Picture Description ① Bolt (M8*70MM) ② Washer ③ Gasket ④ Allen Key ⑤ Spring Washer Assembly Preparation Before Beginning Assembly: Noble House Home Furnishings LLC Page 3 OF 12... -
Page 4: Assembly Steps
Note: It is recommended that you have an adult partner to assist during the entire assembly process. Noble House Home Furnishings LLC Page 4 OF 12... - Page 5 During this assembly process you may need to use your hand to press down and or pave away the padded surface to facilitate the 'slip and slide' assembly. Caution: Ensure that your fingers do not get caught or pinched in the assembly process. Noble House Home Furnishings LLC Page 5 OF 12...
- Page 6 Push the Seat(C) downwards until it is fully slotted and locked into position in the Armrests. Fully locked postion: Check that the base of the Armrest(B) and the Seat(C) are aligned and level. Noble House Home Furnishings LLC Page 6 OF 12...
- Page 7 Note: Make sure the Tapered Connectors on the Backrest(A) lock into the Tapered Connectors on the Armrest(B) Fully locked postion: Check and assess that the base of the Backrest(A) and the Seat(C) are aligned and level. Noble House Home Furnishings LLC Page 7 OF 12...
- Page 8 This methodology will ensure maximum evenness once all Bolts are fully tightened. Note: If you can not insert the Bolts into position, please go back to Step 3 to "push Backrest downwards". Noble House Home Furnishings LLC Page 8 OF 12...
- Page 9 Tighten by turning the Leg clockwise. Note: The use of Gaskets are OPTIONAL and are especially useful to help alleviate slight wobbles. Some Legs may need more than one whilst some Legs may not need any. Noble House Home Furnishings LLC Page 9 OF 12...
- Page 10 Step 6 Seat Cushion (D) Place the Seat Cushions(D) onto the Sofa. Your Sofa is ready for use. This Sofa can only be used on a flat, level surface. Noble House Home Furnishings LLC Page 10 OF 12...
-
Page 11: Additional Steps
Make sure all parts are connected and securely locked into position. Step 2 Your Sofa Set is ready for use. This Sofa Set can only be used on a flat level surface. Noble House Home Furnishings LLC Page 11 OF 12... - Page 12 Noble House Home Furnishings LLC Page 12 OF 12...
