- Page 1 Caution: You must read this before you proceed LEFT ARMCHAIR Label Picture Description Left Armrest Back Seat Side Plate Foot Seat Cushion Back Cushion Noble house Home Furnishings LLC 1 OF 6...
- Page 2 Label Picture Description ① Allen Key (M6) ② Bolt (M6*45mm) ③ Washer ④ Allen Key (M4) ⑤ Bolt (M6*45mm) ⑥ Washer Ring Before Beginning Assembly: Noble house Home Furnishings LLC 2 OF 6...
- Page 3 This Left Armchair has multiple parts and may require up to 30 minutes to assemble. To give you an overview of the Left Armchair parts, the above picture is to help you put the various parts into perspective. Please read through the instructions below to familiarise yourself with the parts and steps before assembly.
- Page 4 Attach Side Plate(D) between the Back(I) and Seat(J) using Bolt(②) and Washer(③) with Allen Key(①) as shown above. Do not fully tigthen. Step 4 Attach the Foot(E) to the Chair using Bolts(⑤) and Washer Rings(⑥) with Allen Key(④). Noble house Home Furnishings LLC 4 OF 6...
- Page 5 Gently and gracefully, sit into to the Left Armchair. This would help to align all the parts at all the joint areas. Then get off the Left Armchair, and in a sequential manner, proceed to tighten all bolts. When tightening the Bolts, tighten sequentially.
- Page 6 Proposition 65 warnings have become so common in California that it is hard to take a trip to a local bank, grocery store, or restaurant without finding at least one warning. In fact, even the Disney Land Resort has a Proposition 65 warning: Noble house Home Furnishings LLC 6 OF 6...
- Page 7 Caution: You must read this before you proceed RIGHT ARMREST Label Picture Description Right Armrest Back Seat Side Plate Foot Seat Cushion Back Cushion Noble house Home Furnishings LLC 1 OF 6...
- Page 8 Label Picture Description ① Allen Key (M6) ② Bolt (M6*45mm) ③ Washer ④ Allen Key (M4) ⑤ Bolt (M6*45mm) ⑥ Washer Ring Before Beginning Assembly: Noble house Home Furnishings LLC 2 OF 6...
- Page 9 ATTENTION: There may be some PE wicker that may have covered the Mounting Points. To ease assembly, guide and slide the PE wicker away from these Mounting Points. DO NOT CUT AWAY ANY PE WICKER as this would cause the wicker to unravel! Noble house Home Furnishings LLC 3 OF 6...
- Page 10 Attach Side Plate(D) between the Back(B) and Seat(C) using Bolt(②) and Washer(③) with Allen Key(①) as shown above. Do not fully tigthen. Step 4 Attach the Foot(E) to the Chair using Bolts(⑤) and Washer Rings(⑥) with Allen Key(④). Noble house Home Furnishings LLC 4 OF 6...
- Page 11 Step 6 Place the Back Cushion(G)and Seat Cushion(F) onto the Right Armchair as shown. Your Right Armchair is ready for use. Caution:This Right Armrest can only be used on a flat, level surface. Noble house Home Furnishings LLC 5 OF 6...
- Page 12 Proposition 65 warnings have become so common in California that it is hard to take a trip to a local bank, grocery store, or restaurant without finding at least one warning. In fact, even the Disney Land Resort has a Proposition 65 warning: Noble house Home Furnishings LLC 6 OF 6...
