Assembly Instructions
Caution: You must read this before you proceed
LOVESEAT
Caution: This Loveseat is NOT a TOY.
Keep your child / children at bay in the process of assembly.
Whenever moving or lifting the Loveseat and to prevent damage to the Loveseat, two adults may be
needed to execute these actions
Noble House Home Furnishings LLS
1 of 7
Advertisement
Table of Contents
Related Manuals for Noble House Home Furnishings LOVESEAT
Summary of Contents for Noble House Home Furnishings LOVESEAT
- Page 1 Caution: This Loveseat is NOT a TOY. Keep your child / children at bay in the process of assembly. Whenever moving or lifting the Loveseat and to prevent damage to the Loveseat, two adults may be needed to execute these actions...
- Page 2 Label Picture Description Seat Panel Backrest Panel Decorative Corner Block Seat Cushion Back Cushion Hardware Picture Description ①-L Bolt (M8x60mm) ②-L Washer (M8xD2mm) Screw ③-L (M6x80mm) Screw ④-L (M6x50mm) ⑤-L Allen Key Noble House Home Furnishings LLS 2 of 7...
- Page 3 Seat Panel (B-L) FRONT FACING This Loveseat has multiple parts and may require up to 30 minutes to assemble. To give you an overview of the Loveseat, the above picture is to help you put the various parts into perspective.
- Page 4 2.1) With assistace frorm your adult partners, turn the Seat Panel(B-L) facedown as pictured above. 2.2) Attach Legs(A-L) to Seat Panel(B-L) using Bolts(①-L), and Washers (②-L) with Allen Key(⑤- L) as shown above. Do not fully tighten the Bolts. Noble House Home Furnishings LLS 4 of 7...
- Page 5 Do not fully tighten the Screws. Step 4 Align the Decorative Corner Blocks (D-L) to the mounting position on the Loveseat. Attach Decorative Corner Blocks (D-L) to Loveseat using Screws(④-L) through the vertical and horizontal mounting positions with Allen Key (⑤-L) as shown above.
- Page 6 Gently and gracefully, sit into to the Loveseat. This will help to align all the parts at all joint areas. Then get off the Loveseat and proceed to tighten the Bolts and Screws in a sequential manner. When tightening the Bolts and Screws tighten sequentially.
- Page 7 Noble House Home Furnishings LLS 7 of 7...
