VERSION # 20-09- 30
1 / 9
MODEL #
CM3325PT-5PK
Questions?
GIVE US CALL: 1-888-980-5122
MON-FRI 8:30AM - 5:30PM (PST)
Allen Wrench
(Included)
Allen Wrench
(Included)
Philips Screwdriver
(Not Included)
2 - People
Recommended
EASY
The Assembly Rating is a
5-point system showing the
level of effort needed to
assemble a specific product.
DIFFICULT
Advertisement
Related Manuals for Furniture of America Bridgette CM3325PT-5PK
Summary of Contents for Furniture of America Bridgette CM3325PT-5PK
- Page 1 MODEL # CM3325PT-5PK Questions? GIVE US CALL: 1-888-980-5122 MON-FRI 8:30AM - 5:30PM (PST) Allen Wrench (Included) Allen Wrench (Included) Philips Screwdriver (Not Included) 2 - People Recommended EASY DIFFICULT The Assembly Rating is a 5-point system showing the level of effort needed to assemble a specific product.
- Page 2 America Furniture FOA Intro Thank you for your purchase! We hope you enjoy this new addition to your home for many years to come. Our commitment to providing quality products does not simply end when you purchase our product. We fully stand behind our products from start to finish. Our customer service department is available Monday –...
- Page 3 PRE ASSEMBLY INTRODUCTION We understand building ready-to-assemble furniture can be a challenging experience for some. To help avoid confusion, we have provided some helpful tips that may speed up the process. Teamwork ALWAYS have at least two people to help with transporting and assembling the product to avoid potential injury and/or damage.
- Page 4 4 / X X X X X X X 9...
- Page 5 Table CM3325PT-5PK #2 4pcs #1 1pc Table Top #C 8pcs #B 8pcs #D 1pc #A 8pcs Wrench 12 x 90mm Lock Washer Ø5/16" Flat Washer Ø5/16" Bolt Ø 5/16" x 2-1/2'' 5 / 9...
- Page 6 ASSEMBLY INSTRUCTIONS Align legs (#2) to the top (#1), then Part #1 x1pc secure by using bolts (#A) with washers Part #2 x4pcs (#B,C). Hardware #A x8pcs Hardware #B x8pcs Hardware #A x8pcs 6 / 9...
- Page 7 Chair CM3325PT-5PK #4 2pcs x4 #5 1pc x4 #3 2pcs x4 #1 1pc x4 #2 1pc x4 Front Leg Front stretcher Seat Side stretcher Backrest w/Legs (L/R) #A 4pcs x4 #D 10pcs x4 #B 4pcs x4 #C 2pcs x4 Bolt Ø1/4" x 2-1/2'' Bolt Ø1/4"...
- Page 8 ASSEMBLY INSTRUCTIONS Align seat (#2) to the chair back Part #1 x1pc (#1), then secure by using bolts Part #2 x1pc (#C) with washers (#D,E). Hardware #C x2pcs Hardware #D x2pcs Hardware #E x2pcs Hardware #A x4pcs Secure corner holes to the seat Hardware #D x4pcs (#2) to chair back (#1) by using Hardware #E x4pcs...
- Page 9 ASSEMBLY INSTRUCTIONS Align legs (#3R/L) with Part #3 x2pcs stretchers (#4R/L,5) to the chair, then secure by using Part #4 x2pcs bolts (#B) with washers Part #5 x1pcs (#D,E). Hardware #B x4pcs Hardware #D x4pcs Hardware #E x4pcs Hardware #G x6pcs Secure stretchers by using screws (#G).
