Next 866903 Assembly Instructions Manual

Ashton cubby wide

Advertisement

Quick Links

IMPORTANT - RETAIN FOR FUTURE REFERENCE - READ CAREFULLY.

Tools Needed

Helpline

If you have any problems with this product or require
any replacement fittings please contact Customer
Services Tel: 0844 844 8999
Regrettably self assembly items cannot be returned once assembly is part or fully completed unless the item is found
to be faulty. Should you need to return the unassembled product, please repack in the original packaging.

IMPORTANT

• We suggest you spend a short time reading through this leaflet and then follow the simple step-by-step instructions.
• Carefully check that you have all parts before beginning assembly.
• Keep fittings out of children's reach and keep children well away from the construction area.
• We recommend that the packaging is used to protect the surfaces during assembly.
• A minimum of two persons is required to assemble this product.
• Maximum weight this product can hold is 10 kg

PRODUCT INFORMATION

• Made from MDF.
• Made in China.

CARE INSTRUCTIONS

this item correctly.
• For general cleaning, periodically dust with a soft cloth.
• Do not rub or scrub the surface when cleaning.
• Do not use furniture polish.
• Any spills should be removed immediately with a soft clean damp cloth and dried immediately.
• Ensure the product is protected with mats and coasters when items are placed on the surfaces, to prevent
scratching or damage.
• Do not put hot dishes directly on the surfaces of the item.
• Avoid keeping furniture in direct sunlight or close to any heat sources as this can cause cracking, discolouration or
warping.
• Never drag pieces of furniture across the floor as this will cause damage to the joints.
• All assembly fixings should always be tightened properly and periodically check all fixings and tighten if necessary.
866903 ASHTON CUBBY WIDE
ASSEMBLY INSTRUCTIONS.
Page 1 of 6

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 866903 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Next 866903

  • Page 1 866903 ASHTON CUBBY WIDE ASSEMBLY INSTRUCTIONS. IMPORTANT - RETAIN FOR FUTURE REFERENCE - READ CAREFULLY. Tools Needed Helpline If you have any problems with this product or require any replacement fittings please contact Customer Services Tel: 0844 844 8999 Regrettably self assembly items cannot be returned once assembly is part or fully completed unless the item is found to be faulty.
  • Page 2 FITTINGS PARTS Page 2 of 6...
  • Page 3 STEP ONE 1. Insert 7 x dowels C into panel (1), and insert 11 x cambolts A into panel (1) with a screwdriver. 2. Insert 5 x dowels C into side panel (2), and insert 7 x camblots A into side panel (2) with a screwdriver. 3.
  • Page 4 STEP THREE 1. Attach 4 x panels (6), shelf (3) and shelf (4) together using 4 x cam-locks B with a screwdriver I. Ensure the arrow indicators are pointing to the panel edges and ensure the cambolts locate properly into the cam- locks before tightening with a screwdriver.
  • Page 5 STEP FIVE 1. Fasten back panel to the unit using 6 x screws E with a screwdriver, and attach side panel (2) to the unit using 4 x cam-locks B. Please note the cam- locks are towards different faces. Ensure the arrow indicators are pointing to the panel edges and ensure the cambolts locate properly into the cam-locks before tightening with a screwdriver.
  • Page 6 If in doubt please consult a qualified trades person. 3. Drill into the wall, insert raw plugs into wall 4. Insert Screws from the front through the unit into the wall Next Retail Ltd, Desford Road, Leicester, LE19 4AT Page 6 of 6...
