September 14, 2020
2021 TLX: TQI of the Navigation System
AFFECTED VEHICLES
Year
2021
INTRODUCTION
This bulletin covers the total quality inspection (TQI), including testing, of the 2021 TLX navigation system. It includes
these topics:
1. Navigation System Controls
2. Navigation Voice Portal System
3. Navigation System Setup at the TQI
4. Rearview Camera
5. Surround View Camera (Advance Trim Level Only)
6. Map Coverage Areas
7. HD FM Traffic Information
®
8. AcuraLink
For more information about this system, see these resources:
•
Owner's Guide – You will find this guide in the Owner Information Kit in the glove box.
•
Navigation Manual – This manual is only available online. Select Search by Vehicle, select the vehicle, then enter
keywords NAVI MANUAL.
•
Owner's Manual – This manual is only available online. Select Search by Vehicle, select the vehicle, then enter
keywords OWN MANUAL.
•
Online University – Log in and select SALES. Under Quick Links, select Course Catalog, then enter keyword
NAVI in the search box.
CLAIM INFORMATION
The reimbursement time for the TQI of the navigation system is included as part of the regular TQI of the vehicle.
CLIENT INFORMATION:The information in this bulletin is intended for use only by skilled technicians who have the proper tools, equipment, and
training to correctly and safely maintain your vehicle. These procedures should not be attempted by "do-it-yourselfers," and you should not assume
this bulletin applies to your vehicle, or that your vehicle has the condition described. To determine whether this information applies, contact an
authorized Acura automobile dealer.
©
2020 American Honda Motor Co., Inc. — All Rights Reserved
Model
TLX
Service Bulletin
Trim Level
ALL with Navigation
20-035
Version 1
Page 1 of 7

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TLX 2021 and is the answer not in the manual?

Questions and answers

Related Manuals for Acura TLX 2021

Summary of Contents for Acura TLX 2021

  • Page 1 These procedures should not be attempted by “do-it-yourselfers,” and you should not assume this bulletin applies to your vehicle, or that your vehicle has the condition described. To determine whether this information applies, contact an authorized Acura automobile dealer. ©...
  • Page 2 NAVIGATION SYSTEM CONTROLS Use the following controls to work the navigation system. For more information about them, see the Getting Started section in the online navigation manual. NAVIGATION VOICE PORTAL SYSTEM The navigation system features a voice portal system that lets you work the navigation, HVAC, and audio controls with just your voice.
  • Page 3 NAVIGATION SYSTEM SETUP AT THE TQI The navigation system is basically ready to use when the vehicle is delivered to the dealership. The system has features to reduce the potential for driver distraction. Some touch screen menus are limited or unavailable (grayed out) while driving to encourage the use of voice commands for the navigation and audio systems.
  • Page 4 3.4. When initialization is complete, this screen appears. Select OK. 3.5. If the GPS icon is crossed out in the top right of the display, make sure the vehicle is parked in an open area with a clear view of the southern sky. NOTE Do not enter a destination yet.
  • Page 5 3.10. After your command is accepted, wait for the beep and say “Acura dealer.” 3.11. After your command is accepted, wait for the beep and say the number of your dealership in the list of nearest dealers. 3.12. After your command is accepted, wait for the beep and say “Set as destination.”...
  • Page 6 MAP COVERAGE AREAS The map database covers the United States, Mexico, Puerto Rico, and Canada. The map coverage for the U.S. contains accurately mapped (verified) metropolitan areas and less accurate (unverified) rural coverage. You do not need to change the navigation settings when relocating to or from these locations. For a list of current detailed coverage areas by country and state/province, see the online navigation manual.
