Xilinx MultiLINX Getting Started page 11

Getting Started With the MultiLINX™ Cable
MultiLINX
Operating
Characteristics
Table 5: Reliability Characteristics
Parameter
Relative Humidity
Vibration
Shock
Bench Drop
Notes:
Each of MultiLINX Cable's Flying wires is capable of driving a total capacitive load of 100 pF; Each of MultiLINX Cable's Flying
wires is capable of driving a total pull-up resistance of 500 ohms; Each of MultiLINX Cable's Flying wires is capable of driving
a total pull-down resistance of 5000 ohms.
Revision
History
XAPP168 (v1.1) February 8, 2000
Table 4: Recommended Operating Conditions
Parameter
DC Voltage
Maximum Applied DC
Signal Voltage per
Flying Wire
Typical Current
Requirements
Power Req.
Temp. Range
Altitude
Operating
5% to 90% (non-condensing at 40° C )
0.5mm (pp), 5 - 55 Hz
5.0G, 11 ms, 1/2 sine
Three foot drop onto a solid surface with no
physical damage
Date Version
10/6/99 1.0
2/8/00 1.1
Operating
2.5V to 5.0V
–0.5V to 5.5V
300mA @ 5.0V,
500mA @ 3.3V,
750mA @ 2.5V
2 Watts Max.
0°C to 55°C
–100 to 15000 ft
5% to 95% (noncondensing at 65° C )
1.5mm (pp), 5 - 55 Hz
30G, 11 ms, 1/2 sine
Three foot drop onto a solid surface with no physical
damage
Initial Xilinx release.
Updated format and Figure 1.
www.xilinx.com
1-800-255-7778
Non-Operating
N/A
N/A
N/A
N/A
– 40° C to 85°C
–1000 to 50000 ft
Non-Operating
Revision
R
11
