90000 – Encase 40" Forte Elite Mantel
90001 - Encase 50" Sideline® Elite Mantel
Read and understand this entire owner's manual, including all safety
information, before assembling or using this product. Failure to do so could
WARNING
result in serious personal injury.
Keep this owner's manual for future reference. If you sell or give this
CAUTION
product away, make sure this manual accompanies this product.
ENCASE FIREPLACE MANTEL
Model # : 90000, 90001
ASSEMBLY INSTRUCTIONS
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Touchstone ENCASE FORTE ELITE 90000
Summary of Contents for Touchstone ENCASE FORTE ELITE 90000
- Page 1 ENCASE FIREPLACE MANTEL Model # : 90000, 90001 ASSEMBLY INSTRUCTIONS 90000 – Encase 40” Forte Elite Mantel 90001 - Encase 50” Sideline® Elite Mantel Read and understand this entire owner’s manual, including all safety information, before assembling or using this product. Failure to do so could WARNING result in serious personal injury.
- Page 2 Encase Fireplace Mantel www.touchstonehomeproducts.com 800.215.1990 rev. 20220401...
-
Page 3: Table Of Contents
Unpacking Your Mantel ............................... 7 Parts and Hardware ..............................7 Assembly Instructions ..............................8 Securing Mantel to Wall ............................. 12 Parts ..................................12 Instructions ................................12 Warranty ..................................14 Touchstone Home Products Limited Warranty....................... 14 Conditions and Limitations ............................. 14 www.touchstonehomeproducts.com 800.215.1990 rev. 20220401... - Page 4 Encase Fireplace Mantel IMPORTANT SAFETY INFORMATION WARNING! • Before assembly, carefully use scissors or utility knife to cut and unwrap all parts. DO NOT DISCARD ANY HARDWARE! • Use care assembling your new mantel. Take your time and use the hardware provided. Never overtighten bolts.
-
Page 5: Dimensional Drawings
Encase Fireplace Mantel Dimensional Drawings 90000 - Encase 40” Forte Elite Mantel www.touchstonehomeproducts.com 800.215.1990 rev. 20220401... -
Page 6: 90001 - Encase 50" Sideline® Elite Mantel
Encase Fireplace Mantel 90001 - Encase 50” Sideline® Elite Mantel www.touchstonehomeproducts.com 800.215.1990 rev. 20220401... -
Page 7: Unpacking Your Mantel
If any parts are missing or damaged, do not attempt to assemble, install, or operate this product. Contact Touchstone Home Products Customer Service at 800-215-1990 for replacement parts. NOTE: Dispose of plastic bag, as it may cause choking hazard with young children. Do not let children play with plastic bag. -
Page 8: Assembly Instructions
Encase Fireplace Mantel Assembly Instructions Exploded view of all cabinet pieces 1. Locate long panels D (top of mantel) and E (bottom of mantel), and set down on a scratch free surface. Insert and tighten screw A into the holes on panel D and panel E. There will be 6 of screw A inserted into each panel as shown. - Page 9 Encase Fireplace Mantel Assembly Instructions – cont. 2. Mount end pieces F and G on the 3 screws on each side of base piece E. The screws in base E will fit into the holes in end pieces F and G. Hardware used: Front View 3.
- Page 10 Encase Fireplace Mantel Assembly Instructions – cont. 4. Fasten flat piece J in each corner of the mantel as shown to the right. Use 3 screws for each flat piece J to fasten the flat piece to the upright pieces on the mantel. Hardware used: Rear View 5.
- Page 11 Encase Fireplace Mantel Assembly Instructions – cont. 7. Fasten vertical pieces K as shown with 2 screws C. Hardware used: Rear View 8. The mantel is now assembled are ready to mount the fireplace to the mantel. www.touchstonehomeproducts.com 800.215.1990 rev. 20220401...
-
Page 12: Securing Mantel To Wall
Encase Fireplace Mantel Securing Mantel to Wall WARNING – Please read before completing installation • Serious or fatal crushing injuries can occur from furniture tip-over. Always secure this furniture to the wall using the tip-over restraints provided. • DO NOT place TV or other HEAVY objects on top of this product. •... - Page 13 Encase Fireplace Mantel Securing Mantel to Wall – cont 2. Place fireplace and mantel in final location and secure to wall. Mark and drill 2 10mm holes in wall to line up with wall brackets on fireplace. Once holes are made, install dry wall anchor N in holes.
-
Page 14: Warranty
Touchstone Home Products Limited Warranty Touchstone Home Products®, Inc offers a one (1) year limited warranty on all our electric fireplaces. The one (1) year warranty starts on the date of purchase and expires 1 calendar year from the original date of purchase. - Page 15 Encase Fireplace Mantel www.touchstonehomeproducts.com 800.215.1990 rev. 20220401...
- Page 16 Encase Fireplace Mantel Affix Serial Number Label Here www.touchstonehomeproducts.com 800.215.1990 rev. 20220401...
