- Page 1 Smart Frost Fridge Freezer P65555MSFX INSTRUCTIONS: Please read and keep safe for future use. Serial No. You created this PDF from an application that is not licensed to print to novaPDF printer (http://www.novapdf.com)
-
Page 2: Table Of Contents
INSTALLATION AND USER INSTRUCTIONS Features………………………………………………………………………………………………….. 3 Transportation instructions................. 4 Introduction & safety warnings..............5 Electrical Requirements/Installation ………………… ........6 Food Storage …………………………………………………………………….…………………….. 7 Defrosting/Arrangement of Food ..............9 Temperature Control ………………………………………………………………………………..10 Cleaning and Care………………................ 11 Top Tips ……………..................12 Problem solving ................... 14 Technical data/Health &... -
Page 3: Features
Features Description Thermostat Refrigerator Glass Shelf Crisper Cover Crisper Frozen Upper Drawer Frozen drawer Adjusting foot Upper bottle frame You created this PDF from an application that is not licensed to print to novaPDF printer (http://www.novapdf.com) - Page 4 Middle bottle frame Lower bottle frame Transportation of your Appliance When transporting, never tilt to more than 45 degrees The appliance should be transported only in a vertical upright position The packaging as supplied must be intact during transportation ...
- Page 5 manufacturer will not be held responsible if these instructions are disregarded. The appliance must be protected against rain and moisture When positioning your appliance take care not to damage your flooring, kitchen furniture, related parts and doors, pipes, wall coverings etc.
- Page 6 switched off at any time, wait 30 minutes before switching back on to allow the coolant fluid to settle If you are discarding an old refrigerator with a lock or latch fitted to the door, disable the lock/latch, ensure that it is left in a safe condition to prevent the entrapment of young children This fridge/freezer must only be used for its intended purpose i.e.
-
Page 7: Electrical Requirements/Installation
If the Fridge/Freezer is not level, the door and magnetic seal alignment will be affected and may cause you Fridge/Freezer to work incorrectly. Once the Fridge/Freezer is placed in its final location, adjust the levelling feet at the front by turning them. Electrical Requirements Before you insert the plug into the wall socket make sure that the voltage and The frequency shown in the rating plate inside the appliance corresponds to... -
Page 8: Food Storage
4. Minimum space in the room where the refrigerator is being installed is 10 cubic metres. 5. Choose a location where there is no heat source. Keep the refrigerator away from direct sunlight, oven etc. 6. Do not place the appliance near cookers, radiators or in direct sunlight as this will cause your appliance to work harder. - Page 9 Eggs and Bottle’s should be stored on the shelves provided in the door Meat and fish should be covered to prevent loss of moisture and odours, wrap such foods in aluminium foil or polythene or store in an airtight container It is advisable to store cooked food on top shelves and fresh food on ...
- Page 10 frozen solid. This can temporarily lead to excessive cooling of the refrigeration compartment. Defrosting Defrosting After a period of time frost will build up in certain areas in the Freezer compartment. As a temporary measure, this frost should be scraped away using the plastic scraper included with the appliance.
-
Page 11: Temperature Control
The following guidelines and recommendations are suggested to obtain the Best results: 1. The fridge compartment is for the short term storage of fresh food and drinks. 2. The freezer compartment is rated and suitable for the freezing and storage of pre frozen food. The recommendation for storage as stated on the food packaging should be observed at all times. -
Page 12: Cleaning And Care
Adjusting the temperature. Temp Controller The temperature inside the refrigerator is controlled by a temperature gauge installed in the fridge freezer. The temperature inside the refrigerator varies depending on the opening and closing of the appliance doors, the ambient temperature of the room, and the location of the appliance. Under normal working conditions (spring and autumn), it is suggested that the gear should be set at 5 degrees in the middle gear. -
Page 13: Top Tips
The grille of the condenser at the back the adjacent components can be vacuumed using a soft brush attachment. If the appliance is not going to be used for a long period of time unplug the appliance, remove all food, clean it and leave the door ajar Check door seals regularly to ensure they are clean and free from food ... - Page 14 Wrap frozen food when you buy it and put it in to the freezer as soon as possible Prepare fresh food for freezing in small portions to ensure rapid freezing Don't store bananas or melon in your fridge compartment ...
-
Page 15: Problem Solving
Ensure the time between buying chilled/frozen food and placing them in your appliance is kept at minimum, particularly in summer Do not leave the door of your appliance open longer than necessary and ensure they are closed properly after each opening Problem Solving Check the following: That the plug is inserted properly in the socket and that the power... -
Page 16: Technical Data/Health & Safety
Cause: The appliance has not been properly levelled. The refrigerator may be in contact with the wall or the accessories in the refrigerator may be placed in the wrong position. Symptom: Appliance does not cool sufficiently. Cause: Door has been opened too often, or for too long a time There may be too much food in the refrigerator, possible incorrect temperature selection Symptom:... - Page 17 Health & Safety The use of any electrical appliance requires the following common sense safety rules. There is danger of injury or death and damage to the appliance. Location This appliance is intended to be used in household and residential ...
- Page 18 Do not let the cable run across a cooker or hot area which may damage the cable The mains cable should reach from the socket to the base unit without straining the connections The power cord cannot be replaced ...
-
Page 19: Disposal/Warranty Information
If the appliance is dropped or damaged in any manner, return the appliance to the nearest authorized dealer or after-sales service centre for examination, repair, electrical or mechanical adjustment Disposal Dispose of used electrical appliances in an environmentally friendly manner. This product should not be disposed with other household wastes throughout the EU. - Page 20 This guarantee is valid in Ireland and the UK only. PowerPoint products are intended for household use only. See usage limitations in “safety instructions”.Shomar Ltd has a policy of continuous improvement in product quality and design. The company, therefore reserves the right to change the specification of its models at any time.
- Page 21 The After Sales Division for PowerPoint Appliances is located at the offices of the Brand owner and Distributor – Shomar Ltd, Unit 9 Western Industrial Estate, Dublin 12, Republic Of Ireland. Helplines (office hours) & Spare Parts contact number is 01-4505327 or email anytimeservice@shomar.ie...
