- Page 1 Chest Freezer P11300MEC / P11400MEC INSTRUCTIONS: Please read and keep safe for future use.
- Page 2 Installation and User Instructions Features/ Transportation instructions …….…………….……………………………….. Introduction & safety warnings..............Electrical Requirements …………………............Installation ………………………………..............Food Storage…………………………………………………………………….…………………….. Defrosting…………………………………………………………………………….…………………… Arrangement of Food …………………………………………………………………………………. Freezer Control Panel……………………………………………………………………………….. Cleaning and Care………………................ Top Tips …………………………................Problem solving................... Health and Safety..................Warranty Information.................. Customer Care ………………………………………………………………………………………..
- Page 3 Features Chest freezer P11300MEC external handle , electronic control 2 x baskets Chest freezer P11400MEC external handle , electronic control 4 x baskets Transportation of your Appliance When transporting, never tilt the appliance to more than 45 degrees • •...
-
Page 4: Before First Use
• If during the course of transport the appliance has to be transported horizontally, it must only be laid on its left hand side when standing in front of the appliance. After bringing it to the upright position, it must Not be operated for at least 4 hours to allow the system to settle The appliance must be protected against rain and moisture •... -
Page 5: Electrical Requirements
• This appliance should not be used outdoors Ensure that the plug remains readily accessible • We recommend a separate switch be used to ensure easy switch on/off • Children should be supervised to ensure that they do not play with the •... -
Page 6: Installation Instructions
Incorporates a 13 A fuse. Should the fuse need to be changed a fuse of the same rating must be used. Ensure that the fuse cover is refitted. Installation Instructions 1. Install the Freezer on a flat surface in order to prevent vibration and noise. 2. -
Page 7: Food Storage
Before using the Freezer check that: 1. The interior is dry and air can circulate freely at the rear of the cabinet. 2. The interior is cleaned as recommended under "Cleaning and Care”. Food Storage Freezing Frozen Food: Pre-packed commercially frozen food should be stored in accordance •... - Page 8 conduit and place in a water container. 6 hours before defrosting set the thermostat knob to “ ” to ensure the Super FRZ food is at the lowest temperature when you take it out. Remove the freezer basket. Leave the lid open. Containers of warm water may be placed carefully in the freezer to speed up the defrosting.
- Page 9 Do not allow children to play with the appliance or tamper with the controls. Do not obstruct the freezer fan guard Arrangement of Food in the Freezer The following guidelines and recommendations are suggested to obtain the best results: Prepackaged commercially frozen food should be stored in accordance with the frozen food manufacturer’s instructions for a freezer compartment.
- Page 10 Freezer Control Panel FREEZER OPERATION Unlock Settings Under the lock mode, press both the “Up” and “Down” buttons at the same time for 1s, then operation buttons become unlocked. And setting are enabled, with • Press "Up" key once, the temperature increases by 1 ℃; Press "Down" key the current temperature setting flickering.
-
Page 11: Cleaning And Care
Temperature alarm function The sensor temperature will be detected after the freezer is energized for 3 hours. If the sensor temperature is higher than -12℃, the alarm indicator lights on, and the buzzer sounds at the frequency of 2Hz, which can be stopped by pressing any key under the key unlock state. - Page 12 • Wipe the inside and outside of the freezer with a damp soft cloth, a soft cloth with a mild detergent may also be used if required • Excess deposits of ice should be removed on a regular basis with the handle of a spoon.
- Page 13 • Don't put liquid-filled bottles or sealed cans containing carbonated Liquids into the freezer as they may burst Don't give children ice-cream and water ices direct from the freezer. • The low temperature may cause 'freezer burns' on lips Don't freeze fizzy drinks •...
-
Page 14: Problem Solving
Problem Solving Check the following: • That the plug is inserted properly in the socket and that the power supply is on That the fuse has blown/circuit breaker has tripped/main distribution • switch has been turned off • That the temperature control has been set correctly That the plug is wired correctly if you have changed the fitted plug •... -
Page 15: Health And Safety
Symptom: Smell inside the appliance. Cause: Some of the food is not properly wrapped or covered. The inside of the refrigerator needs cleaning The following are normal: • Refrigerant running in pipes gives a gentle sound of water running in pipes •... - Page 16 • This appliance should not be used in an unheated, cold room i.e. Garage, conservatory, annex, shed, out-house etc. Mains Cable Do not let the lead run across an open space • • Do not let the cable run across a cooker or hot area which may damage the cable •...
-
Page 17: Warranty
• Do not use the appliance for anything other than its intended purpose Unplug from the outlet when not in use or unattended and before • assembling, disassembling and cleaning • Make sure the appliance is switched off before connecting to or disconnecting from the mains supply •... - Page 18 To qualify for the 1 year guarantee, the appliance must have been used according to the instructions supplied. Exclusions Shomar Ltd shall not be liable to replace or repair the goods under the terms of the guarantee where: 1. The fault has been caused or is attributable to accidental use, misuse, negligent use or used contrary to the manufacturer’s recommendations or where the fault has been caused by power surges or damage caused in transit.
-
Page 19: Contact Details
Contact Details The After Sales Division for PowerPoint Appliances is located at the offices of the Brand owner and Distributor – Shomar Ltd, Unit 9 Western Industrial Estate, Dublin 12, Republic Of Ireland. Helplines (office hours) & Spare Parts contact number is 01-450 5327 or email...
