Summary of Contents for PowerPoint P125FMDW
- Page 1 Free Standing Under the Counter Freezer P125FMDW INSTRUCTIONS: Please read and keep safe for future use.
- Page 2 Product Overview……………………………………………………………………………….. Transportation instructions................. Introduction & safety warnings..............Electrical Requirements/Installation …………………........Using your Freezer ……………………..…………………………………….…………………….. Defrosting....................Temperature Control/Cleaning and Care………………........Top Tips …....................Problem Solving..................Health and Safety..................Warranty Information................Contact Details …………………………………………………………………………………………...
-
Page 3: Product Overview
PRODUCT OVERVIEW... -
Page 4: Transportation Instructions
TRANSPORTATION INSTRUCTIONS When transporting, never tilt appliance to more than 45 degrees The appliance should be transported only in a vertical upright position The packaging as supplied must be intact during transportation If during the course of transport the appliance has to be transported horizontally, it must only be laid on its left hand side when standing in front of the appliance. - Page 5 Leave to stand for at least 4 hours before switching on to allow compressor oil to settle if transported horizontally Wipe the inside of freezer with a weak solution of bicarbonate of soda Then rinse with warm water using a damp sponge or cloth. Wash the shelves in warm soapy water and dry completely ...
-
Page 6: Electrical Requirements
the back of the appliance as you may injure your fingers and hands. Make sure that mains cable is not caught under the appliance during and after carrying/moving the appliance, to avoid the mains cable becoming cut or damaged. ELECTRICAL REQUIREMENTS Before inserting the plug into the wall socket make sure that the voltage and frequency shown in the rating plate inside the appliance corresponds to your electricity supply. -
Page 7: Using Your Freezer
If inserting into a cabinet there must be clearance of 9 cm at the back of the Freezer and 2cm at the side. The minimum distance between the top of the cabinet and the wall unit must be at least 100 mm . ... - Page 8 How to Use the Freezer Compartment: Food can be frozen in the top compartment of the appliance by placing it here for a period of 24 hours; frozen food should then be moved from the top compartment into the other two storing compartments ...
- Page 9 DEFROSTING Frost will build up in certain areas of the Freezer compartment. As a temporary measure, this frost should be scraped away using a plastic scraper. NEVER use a metal or sharp instrument. Complete defrosting will however become necessary approximately once per year, or if the frost layer exceeds 5mm to maintain the efficiency of the Freezer.
-
Page 10: Cleaning And Care
TEMPERTURE CONTROL 1. The thermostat located centre of the freezer compartment controls the temperature of the freezer 2. Turn the thermostat knob to the right to increase the temperature. 3. Set the temperature selector to “3” . “Dot Symbol” is “OFF” AND “4” represents the lowest temperature When the appliance is switched on for the first time, the setting knob should be adjusted so that after 24 hours, the average freezer temperature is no higher than... - Page 11 To remove a freezer drawer, pull it as far as possible, then tilt it upwards and pull it out completely If you are going away on holiday or for any other reason, wish to leave the freezer idle for any period of time, proceed as follows: ...
- Page 12 Don't exceed the maximum freezing loads (4 kg in any 24 hours) when freezing fresh food Don't give children ice-cream and water ices direct from the freezer. The low temperature may cause 'freezer burns' on lips Don't freeze fizzy drinks ...
-
Page 13: Problem Solving
PROBLEM SOLVING Check the following: That the plug is inserted properly in the socket and that the power supply is on That the fuse has blown/circuit breaker has tripped/main distribution switch has been turned off That the temperature control has been set correctly ... -
Page 14: Health And Safety
Symptom: Appliance does not cool sufficiently. Cause: Door has been opened too often, or for too long a time There may be too much food in the freezer, incorrect temperature selection The following are normal: Refrigerant gives a gentle sound of water running in pipes ... - Page 15 Do not let the cable run across a cooker or hot area which may damage the cable The mains cable should reach from the socket to the base unit without straining the connections The power cord cannot be replaced Personal Safety ...
-
Page 16: Warranty Information
Unplug from the outlet when not in use or unattended and before assembling, disassembling and cleaning Make sure the appliance is switched off before connecting to or disconnecting from the mains supply If the appliance is dropped or damaged in any manner, return the appliance to the nearest authorized dealer or after-sales service centre for examination, repair, electrical or mechanical adjustment WARRANTY INFORMATION... - Page 17 This guarantee is valid in Ireland and the UK only. PowerPoint products are intended for household use only. See usage limitations in “safety instructions”. Shomar Ltd has a policy of continuous improvement in product quality and design.
-
Page 18: Contact Details
CONTACT DETAILS The After Sales Division for PowerPoint Appliances is located at the offices of the Brand owner and Distributor – Shomar Ltd, Unit 9 Western Industrial Estate, Dublin 12, Republic Of Ireland. Helplines (office hours) & Spare Parts contact number is 01-450 5327 or email...
