- Page 1 MODEL # CM3886PC-2PK Questions? GIVE US A CALL: 1-888-980-5122 MON – FRI 8:30AM – 5:30PM (PST) TOOLS REQUIRED 2 - People Recommended ASSEMBLY RATING EASY DIFFICULT The Assembly Rating is a 5-point system showing the level of effort needed to assemble a specific product.
- Page 2 Furniture America FOA Intro Thank you for your purchase! We hope you enjoy this new addition to your home for many years to come. Our commitment to providing quality products does not simply end when you purchase our product. We fully stand behind our products from start to finish. Our customer service department is available Monday –...
- Page 3 PRE ASSEMBLY INTRODUCTION We understand building ready-to-assemble furniture can be a challenging experience for some. To help avoid confusion, we have provided some helpful tips that may speed up the process. Teamwork ALWAYS have at least two people to help with transporting and assembling the product to avoid potential injury and/or damage.
- Page 4 4 / 7...
- Page 5 CHAIR CM3866PC-2PK Seat Frame Front Leg(L&R) Back Left Stretcher Right Stretcher Front Stretcher Lock Washer Ø5/16" Flat Washer Ø5/16"x22mm Screw #8 x 1-3/4" Allen Wrench Bolt Ø5/16" x 2-1/4" Bolt Ø5/16" x 3-1/2" Bolt Ø5/16" x 2" 10*35MM 5 / 7...
- Page 6 Align front legs (#3R/L) to stretcher (#4) and seat (#2), then secure front legs (#3R/L) to seat (#2) by using bolts (#E) with washers (#C,D). Insert dowel (#H) onto the hole on the seat (#2). Part Part Part Hardware Hardware Hardware Hardware Hardware...
- Page 7 Align stretchers (#5,6) to the legs, then secure by using screws (#B). Part Part Hardware 7 / 7...
