- Page 1 DESCRIPTION: CURVE 1000 MEDIA UNIT FLOOR AREA 1.0 hr 2.0M X2.0M 1 PERSON ASSEMBLY APPROXIMATE ASSEMBLY TIME REQUIRED ASSEMBLY SPACE ASSEMBLED DIMENSIONS 1000mm 460mm 340mm ISSUE A 120712 MDACURVE1000AI002...
-
Page 2: Parts List
DESCRIPTION: CURVE CURVE 1000 MEDIA UNIT PARTS LIST PART LIST BASE PANEL FOOT LEFT HAND SIDE PANEL RIGHT HAND SIDE PANEL CENTRE PANEL TOP PANEL REAR COVER PANEL FRONT DOOR ASSEMBLY GLASS TOP PANEL GLASS SHELF (10) -
Page 3: Hardware List
DESCRIPTION: CURVE CURVE 1000 MEDIA UNIT HARDWARE LIST M4 x 65mm M6 x 30mm M6 x 38mm M3 x 10mm M3 x 14mm M4 x 10mm M3.5 x 14mm 4mm ALLEN SCREW SCREW SCREW SCREW BOLT CAM PIN 12 x 10mm... - Page 4 DESCRIPTION: CURVE CURVE 1000 MEDIA UNIT Top Tips before you start! 1. Please check that all parts are present before you start the assembly of your furniture. 2. For ease and speed of assembly, we recommend that before you commence each step of the assembly, that you identify all the parts required for that step.
- Page 5 DESCRIPTION: CURVE CURVE 1000 MEDIA UNIT STEP 1 STEP 2...
- Page 6 DESCRIPTION: CURVE CURVE 1000 MEDIA UNIT STEP 3 ENSURE THESE HOLES ARE IN CORRECT POSITION WHEN FITTING CAMS ENSURE STARTING POSITION IS CORRECT BEFORE YOU INSERT CONNECTING BOLT TURN CLOCKWISE UNTIL SECURE WRONG CORRECT STEP 4...
- Page 7 DESCRIPTION: CURVE CURVE 1000 MEDIA UNIT STEP 5 WHEN FITTING CAMS ENSURE STARTING POSITION IS CORRECT BEFORE YOU INSERT CONNECTING BOLT TURN CLOCKWISE UNTIL SECURE WRONG CORRECT STEP 6...
- Page 8 DESCRIPTION: CURVE CURVE 1000 MEDIA UNIT STEP 7 STEP 8...
- Page 9 DESCRIPTION: CURVE CURVE 1000 MEDIA UNIT STEP 9 THE ACTION OF THE DOOR DAMPER CAN BE ADJUSTED WITH THE ALLEN KEY SUPPLIED. TURN CLOCKWISE TO INCREASE TENSION FLAT BLADE SCREWDRIVER (SUPPLIED) DOOR PANEL STEP 10...
