ASSEMBLY INSTRUCTIONS
PLEASE KEEP THIS FOR FUTURE REFERENCE
MODEL : CUBIC HYBRID
MEDIA UNIT
FLOOR AREA
1.0 hr
2.0M X2.0M
APPROXIMATE ASSEMBLY TIME
1 PERSON ASSEMBLY
REQUIRED ASSEMBLY SPACE
TOOLS REQUIRED
ASSEMBLED DIMENSIONS
CROSS-HEAD SCREWDRIVER
1000mm
400mm
355mm
www.mda-designs.co.uk
ISSUE 1 110814
MDACUBIC-HYB1000AI002
Advertisement
Related Manuals for MDA DESIGNS CUBIC HYBRID 507945045257
Summary of Contents for MDA DESIGNS CUBIC HYBRID 507945045257
- Page 1 ASSEMBLY INSTRUCTIONS PLEASE KEEP THIS FOR FUTURE REFERENCE MODEL : CUBIC HYBRID MEDIA UNIT FLOOR AREA 1.0 hr 2.0M X2.0M APPROXIMATE ASSEMBLY TIME 1 PERSON ASSEMBLY REQUIRED ASSEMBLY SPACE TOOLS REQUIRED ASSEMBLED DIMENSIONS CROSS-HEAD SCREWDRIVER 1000mm 400mm 355mm www.mda-designs.co.uk ISSUE 1 110814 MDACUBIC-HYB1000AI002...
- Page 2 MODEL : CUBIC HYBRID MEDIA UNIT PARTS LIST PART LIST BASE PANEL FOOT LEFT HAND SIDE PANEL RIGHT HAND SIDE PANEL CENTRE PANEL TOP PANEL REAR COVER PANEL FRONT DOOR ASSEMBLY GLASS SHELF...
-
Page 3: Hardware List
MODEL : CUBIC HYBRID MEDIA UNIT HARDWARE LIST M4 x 65mm M6 x 30mm M3 x 10mm M6 x 38mm M3.5 x 14mm M3 x 14mm 4mm ALLEN SCREW SCREW SCREW BOLT CAM PIN 12 x 10mm 25 x 40mm 15 x 40mm CAM LOCK MAG CATCH... - Page 4 MODEL : CUBIC HYBRID MEDIA UNIT Top Tips before you start! 1. Please check that all parts are present before you start the assembly of your furniture. 2. For ease and speed of assembly, we recommend that before you commence each step of the assembly, that you identify all the parts required for that step.
- Page 5 MODEL : CUBIC HYBRID MEDIA UNIT STEP 1 STEP 2...
- Page 6 MODEL : CUBIC HYBRID MEDIA UNIT STEP 3 ENSURE THESE HOLES ARE IN CORRECT POSITION WHEN FITTING CAMS ENSURE STARTING POSITION IS CORRECT BEFORE YOU INSERT CONNECTING BOLT TURN CLOCKWISE UNTIL SECURE WRONG CORRECT STEP 4...
- Page 7 MODEL : CUBIC HYBRID MEDIA UNIT STEP 5 WHEN FITTING CAMS ENSURE STARTING POSITION IS CORRECT BEFORE YOU INSERT CONNECTING BOLT TURN CLOCKWISE UNTIL SECURE WRONG CORRECT STEP 6...
- Page 8 MODEL : CUBIC HYBRID MEDIA UNIT STEP 7 STEP 8...
- Page 9 MODEL : CUBIC HYBRID MEDIA UNIT STEP 9 THE ACTION OF THE DOOR DAMPER CAN BE ADJUSTED WITH THE ALLEN KEY SUPPLIED. TURN CLOCKWISE TO INCREASE TENSION PRESS TO CLICK SECURE WITH HINGE TO PLATE SCREW To support the front door whilst fitting the hinges onto the main unit it is reccomended to use the packing box underneath the door.
- Page 10 MODEL : CUBIC HYBRID MEDIA UNIT THE HIGH GLOSS SURFACE ON THE PANELS STEP 10 HAS A PROTECTIVE FILM COVERING. CAREFULLY PEEL THIS OFF BEFORE USE. IT MAY BE NECCESSARY TO REMOVE ANY RESIDUE WITH A SOFT LINT FREE CLOTH. Peel away protective covering STEP 11...
- Page 11 MODEL : CUBIC HYBRID MEDIA UNIT STEP 12 PARTS SUPPLIED WITH HYBRID SCREEN MOUNTING SYSTEM PLEASE REFER TO THE ASSEMBLY INSTRUCTIONS SUPPLIED WITH THE HYBRID MOUNTING SYSTEM FOR FURTHER DETAILS OF ASSEMBLY & TV SCREEN FITMENT.
