ASSEMBLY INSTRUCTIONS

PLEASE KEEP THIS FOR FUTURE REFERENCE

MODEL : NOVA 1140

MEDIA UNIT

FLOOR AREA

0.5 hr

2.0M X2.0M

APPROXIMATE ASSEMBLY TIME

1 PERSON ASSEMBLY

REQUIRED ASSEMBLY SPACE

ASSEMBLED DIMENSIONS

460 mm

1140 mm

AFTER SALES SERVICE

In the unlikely event of any problems with assembly, faulty or damaged parts

PLEASE DO NOT RETURN THE PRODUCT TO THE RETAILER

email us below for a prompt service.

service@mda-designs.co.uk

www.mda-designs.co.uk

ISSUE 1 120416

MDANOVA1140-1000AI002

Table of Contents

Need help?

Do you have a question about the NOVA 1140 and is the answer not in the manual?

Page 1 ASSEMBLY INSTRUCTIONS PLEASE KEEP THIS FOR FUTURE REFERENCE MODEL : NOVA 1140 MEDIA UNIT FLOOR AREA 0.5 hr 2.0M X2.0M APPROXIMATE ASSEMBLY TIME 1 PERSON ASSEMBLY REQUIRED ASSEMBLY SPACE ASSEMBLED DIMENSIONS 460 mm 1140 mm AFTER SALES SERVICE In the unlikely event of any problems with assembly, faulty or damaged parts PLEASE DO NOT RETURN THE PRODUCT TO THE RETAILER email us below for a prompt service.
Page 2 MODEL : NOVA 1140 MEDIA UNIT PARTS LIST PART LIST CABINET ASSEMBLY GLASS SHELF HARDWARE LIST M6 x 15mm M6 x 65mm 6mm ALLEN BOLT SCREWDRIVER SHELF PEG...
Page 3 MODEL : NOVA 1140 MEDIA UNIT Top Tips before you start! 1. Please check that all parts are present before you start the assembly of your furniture. 2. For ease and speed of assembly, we recommend that before you commence each step of the assembly, that you identify all the parts required for that step.
Page 4 MODEL : NOVA 1140 MEDIA UNIT STEP 1 NOTE : PLEASE ENSURE LEGS ARE IN CORRECT POSITION - WITH LEGS POINTING OUTWARDS TOWARDS THE 4 CORNERS OF THE CABINET...
Page 5 MODEL : NOVA 1140 MEDIA UNIT STEP 2 STEP 3 ENSURE CUT OUT ON GLASS SHELF IS HERE...
Page 6 MODEL : NOVA 1140 MEDIA UNIT STEP 4 PUSH DOOR TO RELEASE CATCH & OPEN ADJUSTING THE DOOR : Although the door is pre-assembled it may be neccesarry to make some slight adjustments for your complete satisfaction. The door can be both adjusted horizontally & the opening operation (damping) adjusted as shown below.
