ASSEMBLY INSTRUCTIONS
PLEASE KEEP THIS FOR FUTURE REFERENCE
MODEL : SPACE 1600 HYBRID
MEDIA UNIT
FLOOR AREA
1.5 hr
2.0M X2.0M
1 PERSON ASSEMBLY
APPROXIMATE ASSEMBLY TIME
REQUIRED ASSEMBLY SPACE
TOOLS REQUIRED
ASSEMBLED DIMENSIONS
CROSS-HEAD SCREWDRIVER
AFTER SALES SERVICE
In the unlikely event of any problems with assembly, faulty or damaged parts
PLEASE DO NOT RETURN THE PRODUCT TO THE RETAILER
email us below for a prompt service.
service@mda-designs.co.uk
www.mda-designs.co.uk
ISSUE 1 100117
MDASPACE1600 - HYB-1000AI002
Advertisement
Related Manuals for MDA DESIGNS SPACE 1600 HYBRID
Summary of Contents for MDA DESIGNS SPACE 1600 HYBRID
- Page 1 ASSEMBLY INSTRUCTIONS PLEASE KEEP THIS FOR FUTURE REFERENCE MODEL : SPACE 1600 HYBRID MEDIA UNIT FLOOR AREA 1.5 hr 2.0M X2.0M 1 PERSON ASSEMBLY APPROXIMATE ASSEMBLY TIME REQUIRED ASSEMBLY SPACE TOOLS REQUIRED ASSEMBLED DIMENSIONS CROSS-HEAD SCREWDRIVER AFTER SALES SERVICE In the unlikely event of any problems with assembly, faulty or damaged parts PLEASE DO NOT RETURN THE PRODUCT TO THE RETAILER email us below for a prompt service.
- Page 2 MODEL : TUCANA 1200 HYBRID MEDIA UNIT PARTS LIST PART LIST PART LIST (11) BASE PANEL LEFT HAND OUTER TOP PANEL (12) LEFT HAND SIDE PANEL RIGHT HAND OUTER TOP PANEL INNER SIDE PANEL (13) LEFT HAND OUTER BASE PANEL (14) RIGHT HAND SIDE PANEL RIGHT HAND OUTER BASE PANEL...
-
Page 3: Hardware List
MODEL : SPACE 1600 HYBRID MEDIA UNIT HARDWARE LIST M6 x 30mm M6 x 38mm 15 x 12mm M5 x 10mm M3.5 x 14mm BOLT CAM LOCK SHELF PEG MAG CATCH SCREW CAM PIN (1 spare) M4 x 6mm M3 x 14mm... - Page 4 MODEL : SPACE 1600 HYBRID MEDIA UNIT Top Tips before you start! 1. Please check that all parts are present before you start the assembly of your furniture. 2. For ease and speed of assembly, we recommend that before you commence each step of the assembly, that you identify all the parts required for that step.
- Page 5 MODEL : SPACE 1600 HYBRID MEDIA UNIT STEP 1 STEP 2 WHEN FITTING CAMS ENSURE STARTING POSITION IS CORRECT BEFORE YOU INSERT CONNECTING BOLT TURN CLOCKWISE UNTIL SECURE WRONG CORRECT...
- Page 6 MODEL : SPACE 1600 HYBRID MEDIA UNIT STEP 3 STEP 4 WHEN FITTING CAMS ENSURE STARTING POSITION IS CORRECT BEFORE YOU INSERT CONNECTING BOLT TURN CLOCKWISE UNTIL SECURE WRONG CORRECT...
- Page 7 MODEL : SPACE 1600 HYBRID MEDIA UNIT STEP 5 STEP 6...
- Page 8 MODEL : SPACE 1600 HYBRID MEDIA UNIT STEP 7 LEFT HAND OUTER COMPARTMENT RIGHT HAND OUTER COMPARTMENT...
- Page 9 MODEL : SPACE 1600 HYBRID MEDIA UNIT STEP 8 LEFT HAND OUTER COMPARTMENT ENSURE THE CLEAR ACRYLIC PANELS ARE ALIGNED BEFORE INSERTING THE BOLTS (A) & LOCATING INTO THE THREADED INSERTS ON THE LEFT & RIGHT PANELS (PARTS 2 & 4)
- Page 10 MODEL : SPACE 1600 HYBRID MEDIA UNIT STEP 9 STEP 10...
- Page 11 MODEL : SPACE 1600 HYBRID MEDIA UNIT STEP 11a FITTING RIGHT HAND GLASS DOOR LOCATE DOOR HINGE PLATES INTO PIVOT CUPS IN TOP & BASE PANELS LOCATE GLASS DOOR INTO DOOR HINGE PLATES & FIT SCREWS. NOTE : DOOR ALIGNMENT CAN BE ADJUSTED BY LOOSENING SCREWS (I) & RE-POSITIONING BEFORE TIGHTENING SCREWS...
- Page 12 MODEL : SPACE 1600 HYBRID MEDIA UNIT STEP 12a FITTING LEFT HAND OUTER GLASS DOOR LOCATE DOOR HINGE PLATES INTO PIVOT CUPS LOCATE GLASS DOOR IN TOP & BASE PANELS INTO DOOR HINGE PLATES & FIT SCREWS. NOTE : DOOR ALIGNMENT CAN BE ADJUSTED BY LOOSENING SCREWS (I) & RE-POSITIONING BEFORE TIGHTENING SCREWS...
- Page 13 MODEL : SPACE 1600 HYBRID MEDIA UNIT FITTING THE HYBRID SCREEN MOUNTING SYSTEM (SOLD / SUPPLIED SEPERATELY) REMOVE INNER PART OF CABLE COVER BEFORE FITTING HYBRID SCREEN MOUNT WASHERS SUPPLIED IN HYBRID SCREEN MOUNT FIXINGS PACK PLEASE REFER TO THE ASSEMBLY INSTRUCTIONS SUPPLIED WITH THE HYBRID MOUNTING SYSTEM...
