Table 1: Features and Functions of the VP-200Dxl XGA Differential Amplifier / DA
#
Feature
1
12V DC
2
OUTPUT 1 HD15F Connector
3
OUTPUT 2 HD15F Connector
4
ON LED
5
INPUT HD15F Connector
6
ID Bit Button
7
EQ. Control Knob
8
LEVEL Control Knob
4.1 Connecting the
To connect the VP-200Dxl, as the example in Figure 2 illustrates, do the
following:
1.
Connect a XGA source (for example, a PC graphics card) to the INPUT
HD15F connector.
2.
Release the ID Bit button
3.
Connect the OUTPUT (HD15F connectors) to up to 2 acceptors, as
follows:
Connect the OUTPUT 1 (HD15F connector) to the acceptor 1 (for
example, a PC monitor)
Connect the OUTPUT 2 (HD15F connector) to the acceptor 2 (for
example, a projector)
4.
Connect the 12V DC power adapter to the power socket and connect the
adapter to the mains electricity.
5.
Adjust the video EQ. (equalization) compensation and/or the video signal
level, if required.
1 Sometimes notebook computers refuse to output a VGA signal to an external VGA monitor if they do not detect the ID Bit
as ON (pin # 4 on the VGA connector). Set the ID Bit to ON using this button so that the notebook will output to an external
VGA monitor
2 However, if the source is a notebook (instead of a PC graphics card), push in the ID Bit button
Your XGA Differential Amplifier / DA
Function
+12V DC connector for powering the unit
Connect to the VGA/XGA acceptor 1
Connect to the VGA/XGA acceptor 2
Illuminates when receiving power
Connect to the VGA/XGA source
Pushing in selects the ID BIT, releasing deactivates the ID BIT
(when outputting the input signal from a notebook connected to an
external VGA monitor
Adjusts the video EQ. (equalization) compensation potentiometer
Adjusts the video signal level potentiometer
XGA Differential Amplifier / DA
2
.
1
)
3
