- Page 1 UM960L User Manual INSTALLATION AND OPERATION USER MANUAL WWW.UNICORECOMM.COM UM960L GPS/BDS/GLONASS/Galileo/QZSS All-constellation Multi-frequency Module High Precision Positioning Copyright© 2009-2022, Unicore Communications, Inc. Data subject to change without notice.
- Page 2 UM960L User Manual (Raw Data) Revision History Version Revision History Date First release R1.0 Aug., 2022...
- Page 3 Unicore holds the trademarks of “和芯星通”,“UNICORECOMM” and other trade name, trademark, icon, logo, brand name and/or service mark of Unicore products or their product serial referred to in this manual (collectively “Unicore Trademarks”).
- Page 4 UM960L User Manual (Raw Data) Foreword This document describes the information of the hardware, package, specification and the use of Unicore UM960L modules. Target Readers This document applies to technicians who possess the expertise on GNSS receivers.
-
Page 5: Table Of Contents
Contents INTRODUCTION ..................1 1.1 Key Features ........................2 1.2 Key Specifications ......................2 1.3 Interfaces ......................... 4 HARDWARE .................... 5 2.1 Dimensions ........................5 2.2 Pin Definition ........................7 2.3 Electrical Specifications ....................9 2.3.1 Absolute Maximum Ratings ..................9 2.3.2 Operational Conditions .................... -
Page 6: Introduction
UM960L User Manual (Raw Data) 1 Introduction UM960L is a new generation of GNSS high precision positioning module from Unicore. It supports all constellations and multiple frequencies, and can simultaneously track GPS L1/L2/L5 + BDS B1I/B2I/B3I/B1C/B2a + GLONASS L1/L2+Galileo E1/E5a/E5b + QZSS L1/L2/L5. -
Page 7: Key Features
Key Features High precision, compact size and low power consumption Based on the new generation GNSS SoC -NebulasIV , with RF-baseband and high precision algorithms integrated 16.0 mm × 12.2 mm × 2.4 mm, surface-mount device Supports GPS L1/L2/L5 + BDS B1I/B2I/B3I/B1C/B2a + GLONASS L1/L2 + Galileo ... - Page 8 UM960L User Manual (Raw Data) < Initialization Time 5 s (Typical) > Initialization Reliability 99.9% Data Update Rate 5 Hz Positioning RTCM 3.0, 3.2, 3.3 Differential Data Data Format NMEA-0183; Unicore Physical Specifications Package 24 pin LGA Dimensions 16.0 mm × 12.2 mm × 2.4 mm Environmental Specifications °...
-
Page 9: Interfaces
UM960L outputs 1 PPS with adjustable pulse width and polarity. Event UM960L provides 1 Event Mark Input with adjustable frequency and polarity. Reset (RESET_N) Active LOW, and the active time should be no less than 5 ms. -
Page 10: Hardware
UM960L User Manual (Raw Data) 2 Hardware Dimensions Table 2-1 Dimensions Symbol Min. (mm) Typ. (mm) Max. (mm) 15.80 16.00 16.50 12.00 12.20 12.70 2.20 2.40 2.60 0.90 1.00 1.10 0.20 0.30 0.40 1.40 1.50 1.60 1.00 1.10 1.20 0.70 0.80... - Page 11 Figure 2-1 UM960L Mechanical Dimensions Hardware UC-00-M47 EN R1.0...
-
Page 12: Pin Definition
UM960L User Manual (Raw Data) Pin Definition Figure 2-2 UM960L Pin Definition Table 2-2 Pin Definition Description Reserved, must be floating; cannot connect — ground or power supply or peripheral I/O Reserved, must be floating; cannot connect — ground or power supply or peripheral I/O... - Page 13 Description System reset RESET_N Active Low VCC_RF External LNA power supply — Ground ANT_IN GNSS antenna signal input — Ground — Ground Reserved, must be floating; cannot connect — ground or power supply or peripheral I/O RXD3 UART3 receiving data TXD3 UART3 transmitting data Built-in function;...
-
Page 14: Electrical Specifications
UM960L User Manual (Raw Data) Electrical Specifications 2.3.1 Absolute Maximum Ratings Table 2-3 Absolute Maximum Ratings Parameter Symbol Min. Max. Unit Power Supply (VCC) -0.3 Voltage Input -0.3 GNSS Antenna Signal Input ANT_IN -0.3 RF Input Power ANT_IN input Consumption of Antenna... -
Page 15: Operational Conditions
2.3.2 Operational Conditions Table 2-4 Operational Conditions Parameter Symbol Min. Typ. Max. Unit Condition Power Supply (VCC) Maximum Ripple Voltage Working Current VCC = 3.3 V VCC_RF Output Voltage VCC_RF VCC-0.1 VCC_RF Output Current ICC_RF Operating Temperature ° C Power Consumption 2.3.3 IO Threshold Table 2-5 IO Threshold Parameter... -
Page 16: Hardware Design
3 Hardware Design Antenna Feed Design UM960L just supports feeding the antennal from the outside of the module rather than the inside. It is recommended to use devices with high power and that can withstand high voltage. Gas discharge tube, varistor, TVS tube and other high-power protective devices may also be used in the power supply circuit to further protect the module from lighting strike and surge. -
Page 17: Grounding And Heat Dissipation
Grounding and Heat Dissipation Grounding and heat dissipation pad Figure 3-2 Grounding and Heat Dissipation Pad The 55 pads in the rectangle in Figure 3-2 are for grounding and heat dissipation. In the PCB design, they must connect to a large sized ground to strengthen the heat dissipation. -
Page 18: Production Requirement
UM960L User Manual (Raw Data) 4 Production Requirement Recommended soldering temperature curve is as follows: Figure 4-1 Soldering Temperature (Lead-free) Temperature Rising Stage Rising slope: Max. 3 ° C/s Rising temperature range: 50 ° C to 150 ° C ... - Page 19 In order to prevent falling off during soldering of the module, do not solder it on the back of the board during design, that is, better not go through soldering cycle twice. The setting of soldering temperature depends on many factors of the factory, ...
-
Page 20: Packaging
Figure 5-1 Label Description Product Packaging The UM960L module uses carrier tape and reel (suitable for mainstream surface mount devices), packaged in vacuum-sealed aluminum foil antistatic bags, with a desiccant inside to prevent moisture. When using reflow soldering process to solder modules, please strictly comply with IPC standard to conduct humidity control. - Page 21 Thickness: 2.0 mm Carrier Tape Space between (center-to-center distance): 20 mm The UM960L is rated at MSL level 3. Refer to the relevant IPC/JEDEC J-STD-033 standards for the package and operation requirements. You may access to the website www.jedec.org to get more information.
- Page 22 和芯星通科技（北京）有限公司 Unicore Communications, Inc. 北京市海淀区丰贤东路 7 号北斗星通大厦三层 F3, No.7, Fengxian East Road, Haidian, Beijing, P.R.China, 100094 www.unicorecomm.com Phone: 86-10-69939800 Fax: 86-10-69939888 info@unicorecomm.com...
