- Page 1 INSTALLATION AND OPERATION USER MANUAL WWW.UNICORECOMM.COM UB482 GPS/BDS/GLONASS/Galileo All-constellation Multi-frequency High Precision and Heading Board Copyright© 2009-2021, Unicore Communications, Inc. Data subject to change without notice.
- Page 2 Revision History Version Revision History Date Ver. 1.0 First release Aug. 2017 R3.1 Add the related description to clarify the VCC restrictions 2019-08-28 Chapter 2.1: revise the mechanical dimensions of fields and the R3.2 RF connector 2019-10-14 Chapter 2.2: pin 12 and pin 24 are reserved R3.3 Update product diagram and Copyright time 2020-04-08...
- Page 3 Foreword This <User Manual> provides information in the features of the hardware, the installation, specification and use of UNICORECOMM UB482 product. For the generic version of this manual, please refer to the appropriate part of the manual according to your purchased product configuration, concerning CORS, RTK and Heading.
-
Page 4: Table Of Contents
......................... 8 PERATION ONDITION ....................... 9 HYSICAL PECIFICATIONS 3 HARDWARE DESIGN ........9 ......................9 ESIGN IN ONSIDERATIONS UB482 R ......................10 EFERENCE ESIGN ............................10 ..........................11 NTENNA 4 INSTALLATION AND CONFIGURATION ...... 12 ESD H ...................... 12 ANDLING RECAUTIONS ........................ -
Page 5: Overview
By employing a single UC4C0 (432 channel tracking) baseband chip and a single RF chip, using single-sided SMD packaging, UB482 has achieved very small size (30x40mm). It can simultaneously track GPS L1/L2 + BDS B1I/B2I + GLONASS L1/L2+Galileo E1/E5b+QZSS. -
Page 6: Key Features
UB482 User Manual 1.1 Key Features ➢ All-constellation multi-frequency high-precision RTK and heading board, support BDS B1I/B2I + GPSL1/L2+GLONASS L1/L2+Galileo E1/E5b+QZSS L1/L2 ➢ 46x71mm classic compact board ➢ Precise RTK positioning and heading ➢ Fast RTK Initialization time < 5s ➢... -
Page 7: Technical Specifications
1.2 Technical Specifications Table 1-1 Performance Specifications 432 channels, based on ＜25s Channels Cold Start NebulasII SoC chip GPS L1/L2 BDS B1I/B2I Initialization ＜5s (Typical) Frequency GLONASS L1/L2 Time Galileo E1/E5b QZSS L1/L2 Single Point Horizontal: 1.5m Initialization ＞99.9% Positioning Vertical: 2.5m Reliability (RMS) -
Page 8: Board Overview
12 navigation signals with 432 channels. ⚫ 1PPS UB482 outputs 1 Pulse-per-second time strobe with corresponding time and positioning tag. The pulse width/polarity is configurable. ⚫ Event UB482 provides 1 Event Mark Input with adjustable pulse width and polarity. -
Page 9: Hardware
2.1 Dimensions Table 2-1 Dimensions Parameter Value Tolerance Length 71.1mm -0.2mm +0.5mm Width 45.7mm ±0.2mm Height (PCB) 1.6mm ±10% RF Connector 4.5mm ±0.2mm Shield 2.0mm ±0.2mm Pin Distance 5.9mm ±0.2mm Pin 1 Pin 28 ANT2 ANT1 Figure 2-1 UB482 Profile... -
Page 10: Connector And Pin Definition
(starting from ANT1, ending at ANT2) and True North. 2.2 Connector and Pin Definition There are two dual rows of pin headers on UB482: 2x14 dual row, 2.0mm pitch Figure 2-3 UB482 Pins Definition _______________________________________________________________________________... -
Page 11: Pins Function Description
LVTTL /or I2C SCL Power High effective (RTK fix is effective when UB482 works as the rover; When UB482 works as the base station, successful set up of the base Position valid station and GPGGA status bit at “7” will make the pin effective). -
Page 12: Electrical Specifications
UB482 User Manual Signal Description Notes Pulse per second Reserved Positive electrode of Ethernet TPO+ Connect to TD+ sending data, Differential pair. Positive electrode of Ethernet TPI+ receiving data, Differential Connect to RD+ pair Negative electrode of TPO- Ethernet sending data,... -
Page 13: Physical Specifications
Item Typical Unit Condition LOW Level Output Voltage Vout_low 0.45 Iout= 4 mA High Level Output Voltage Vout_high 2.85 Iout =4 mA Antenna Gain Gant Power Consumption 2.6 Physical Specifications Table 2-5 Physical Specifications Operating: -40℃～+85℃ Temperature Storage: -55℃～+95℃ Humidity 95% No condensation Vibration GJB150.16-2009, MIL-STD-810... -
Page 14: Ub482 Reference Design
⚫ Antenna interface: Make sure the antenna impedance matches, and the cable is short without any kinks, try to avoid acute angles ⚫ Try to avoid designing in any circuits underneath UB482 ⚫ Keep the board away from any high temperature air flow as far as possible 3.2 UB482 Reference Design... -
Page 15: Antenna
30~100 mA in room temperature, the voltage is DC 4.6V±0.2V. Fifty (50) ohm impedance matching for ANT1 and ANT2 is strongly recommended when the active antenna is connected. ANT1 UB482 Figure 3-2 UB482 Antenna Connection Diagram... -
Page 16: Installation And Configuration
UB482 User Manual 4 Installation and Configuration 4.1 ESD Handling Precautions UB482 Board is an ESD sensitive device and special precautions when handling are required. ⚫ Electrostatic discharge may cause damages to the device. All operations mentioned in this chapter should be carried out on an antistatic workbench, wearing an antistatic wrist strap and using a conductive foam pad ⚫... - Page 17 Follow the steps below to install: ➢ Step 1: Fix UB482 board on the EVK with the holes and pins accurately. ➢ Step 2: Choose the correct location for the antenna—this is critical for a high- quality installation. Poor or incorrect placement of the antenna can influence accuracy and reliability and may result in damage during normal operation.
-
Page 18: Power On
➢ Step 6: Configure the receiver through UPrecise software to send commands or to log data. 4.3 Power On UB482 power supply voltage is 3.3V. After power-on, the receiver starts and can establish communication quickly. 4.4 Configuration and Output UNICORECOMM UPrecise software provides a graphical interface to control and display the operation of the receiver. -
Page 19: Operation Steps
Figure 4-4 UPrecise Views 4.4.1 Operation Steps 1) Turn on the EVK. Click “file - > connect”. Set the baud rate: the default baud rate is 115200 bps Figure 4-5 Connect the Serial Port 2) Click the “receiver settings” button to configure the NMEA message output 3) Click “send”... -
Page 20: Led Indicators
UB482 User Manual Figure 4-6 NMEA Data Output 5 LED Indicators LED indicators are installed on UB482 board to indicate the basic working status of the board, which includes: Color Status Instruction Remark Power on Power off Valid of RTK fix when UB482 works as the rover... -
Page 21: Configuration Commands
Figure 5-1 LED Indicators 6 Configuration Commands UB482 supports abbreviated ASCII format. All commands are composed of a log heading and configuration parameters. Common instructions are shown in the following table: Table 6-1 Common Instructions Command Description freset Reset to factory settings. Note: the factory set baud rate is 115200 bps. - Page 22 UB482 User Manual Command Description When restarting after power off, the calculations will repeat and a new coordinate will be generated. Mode base lat Lon height: Manually configure the coordinate: lat, lon, height Example: lat=40.07898324818, mode base lat lon=116.23660197714, Lon height height=60.4265...
-
Page 23: Reference Station Configuration
6.1 Reference Station Configuration The RTK base station should be static with a fixed and known position. The common instructions to set up an RTK base station configuration are: 1) If the precise coordinates are known, the precise coordinates could be set as in this example: Table 6-2 Base Station Mode Command... -
Page 24: Moving Base Configurations
Save configuration 6.4 Heading Configuration This command is used for dual-antenna receivers (UB482, UM482, and UM442). The heading result is the angle from True North to the baseline of the ANT1 to ANT2 in a clockwise direction. The heading function is enabled by default settings. See Figure 6- 1 Heading Schematic for the schematic. -
Page 25: Heading2 Configuration
6.5 Heading2 Configuration The heading2 result is the angle from True North to the baseline of the base to rover in a clockwise direction. Dual-antenna heading receiver (UB482, UM482, UM442) supports heading2. The heading2 for the dual-antenna receiver is the angle from True North to the baseline of the base to ANT1 in a clockwise direction. - Page 26 UB482 User Manual firmware upgrading process (don’t select “Reset” checkbox): Figure 7-1 Update Interface In general, the upgrade time is within 5minutes. Note: Please use COM1 for firmware upgrade Figure 7-2 Update Complete...
-
Page 27: Packaging
8 Packaging There are 100pcs UB482 boards inside the package box. Description 10 inner boxes/cartons 10 pieces of anti-static plastic bags/inner boxes (1 UB482 board/ anti-static plastic bag) - Page 28 和芯星通科技（北京）有限公司 Unicore Communications, Inc. 北京市海淀区丰贤东路7号北斗星通大厦三层 F3, No.7, Fengxian East Road, Haidian, Beijing, P.R.China, 100094 www.unicorecomm.com Phone: 86-10-69939800 Fax: 86-10-69939888 info@unicorecomm.com www.unicorecomm.com...
