CHEESE GRATER HP. 1,5 – HP.3 CLEANABLE
INSTRUCTION HANDBOOK AND MANUAL
CE

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HP.1,5 CLEANABLE and is the answer not in the manual?

Questions and answers

Related Manuals for Berkel HP.1,5 CLEANABLE

Summary of Contents for Berkel HP.1,5 CLEANABLE

  • Page 1 CHEESE GRATER HP. 1,5 – HP.3 CLEANABLE INSTRUCTION HANDBOOK AND MANUAL...

  • Page 2: Technical Characteristics

    The slicer can be subject a improvement and can set up different particulars from this represent, but don’t compromise the explanation report in the manual. Our cheese grater is: TECHNICAL CHARACTERISTICS HP.1,5 HP. 3 CLEANABLE HP.1,5 CLEANABLE HP. 3 CLEANABLE TYPE LENGHT CM. 51 CM.

  • Page 3: Installation

    CHEESE GRATER HP.1,5 HP.3 CLEANABLE GENERALITY page. 4 1.1. tecnichal assistance page. 2 1.2. responsability page. 2 1.3. warranty conditions page. 4 1.4. descriptions and features page. 5 1.5. main components page. 5 1.6. tecnichal and dimensional data page. 6 PUT IN ACTION page.

  • Page 4: Warranty Certificate

    CHEESE GRATER HP.1,5 HP.3 CLEANABLE Warranty certificate page. 14 Declaration of conformity page. 15 drawing 1 Topographical with billboards page. 16 drawing 3 Topographical with securities page. 17 Dimensions page. 18 Legend wiring diagram page. 18 Electrical diagram pag. 19 Esplode nomenclature pag.
  • Page 5 CHEESE GRATER HP.1,5 HP.3 CLEANABLE 1. GENERALITY 1.4. Descriptions and features The grater is intended for professional use and intended only for grating cheese or hard bread. Description of the cheese grater • Machine body structure in anodized aluminum with feet •...

  • Page 6: Machine Positioning

    CHEESE GRATER HP.1,5 HP.3 CLEANABLE 1.6. Technical and dimensional data Type HP.1,5-HP.3 CLEANABLE HP.1,5 CLEANABLE HP. 3 CLEANABLE TYPE LENGHT CM. 51 CM. 51 HEIGHT CM. 42 CM. 46 WIDTH CM. 23 CM. 23 WEIGHT ABT. KG. 26 KG. 34 POWER HP.

  • Page 7: Electrical Connection

    CHEESE GRATER HP.1,5 HP.3 CLEANABLE 2.4. Electrical connection Check that the line voltage corresponds to that indicated on the machine plate. The connection of the three-phase grater must be carried out exclusively by a specialized electrician, since the machine is supplied complete with a power cable and a 16A CEE plug. The earth connection must be carried out in compliance with the relevant legislation.
  • Page 8 CHEESE GRATER HP.1,5 HP.3 CLEANABLE 2.9 Safety prescriptions for maintenance • • Maintenance operation to be carried out strictly with authorized personnel • • After any maintenance or adjustment, make sure that no tools remain • or foreign bodies between the moving parts to prevent damage to the machine and / or injury to personnel. •...

  • Page 9: Environmental Conditions

    CHEESE GRATER HP.1,5 HP.3 CLEANABLE INSTALLATION 3.1. Environmental conditions The grater must operate in a closed environment, in the absence of dust, at a temperature regulated by limited presence of moisture. Environmental conditions other than those indicated below may cause unexpected anomalies or breakages.
  • Page 10 CHEESE GRATER HP.1,5 HP.3 CLEANABLE 4 MACHINE USE 4.1. Starting up CAUTION !!!! generic danger before starting check that all fixed guards are in the correct position e check the efficiency of the safety devices by direct actuation. also check that the cheese processing unit is housed in its seat and that the clamps that fasten it are well screwed. To start the machine press the general button on position 1 WHITE 4.2.

  • Page 11: Maintenance And Repair

    CHEESE GRATER HP.1,5 HP.3 CLEANABLE 4.6. Cleaning Given that the machine described here is intended for the treatment of food products, the operator has the task of ensuring the maintenance of adequate hygienic conditions. After each use it is necessary to clean the device from processing residues. External cleaning is necessary as the machine is in a food factory for which particular precautions regarding the hygienic conditions of the premises are provided and machinery.

  • Page 12: Spare Parts

    CHEESE GRATER HP.1,5 HP.3 CLEANABLE check electrical and mechanical safety every day roller cleaning, presser, every day 5.3 Diagnostics PROBLEMS CAUSES REMEDIES the machine does not work to verify that the plug has been inserted in if it has not been inserted the electrical panel proceed with this operation the machine does not work...
  • Page 13 CHEESE GRATER HP.1,5 HP.3 CLEANABLE 7 DISPOSAL 7.1. Scrapping - disposal of components and materials The user according to EC directives or according to the laws in force in his country will take care of the disposal and elimination of the materials that make up the grater. In the event of scrapping, the user, in accordance with local legal regulations, must take special precautions regarding the disposal of significant environmental materials, Which: Plastic parts...

  • Page 14: Warranty

    CHEESE GRATER HP.1,5 HP.3 CLEANABLE WARRANTY The grater is guaranteed for a period of 12 months from delivery. The guarantee consists of replacing or crediting the defective parts and eliminating them any operational defects as long as they are reported within 8 days of discovery and before once the year has elapsed from delivery, without any charge being made against the seller for damages or expenses of any kind or cause.
  • Page 15 CHEESE GRATER HP.1,5 HP.3 CLEANABLE DECLARATION OF CONFORMITY DECLARATION DE CONFORMITE’ WERKSBESCHEINIGUNG DICHIARAZIONE DI CONFORMITA’ DECLARACION DE CONFORMIDAD Declares that the machine listed in boxes 1 and 2 complies with the essential requirements of the directive 2006/42/CE 2006/95/CE UNI EN ISO 12100-1:2009 UNI EN 13857:2008 UNI EN ISO 13850 :2008 12100-2 2004/108/CE EN 60204-1-2006 Nous declarons que la machine dèsignèe dans les cadres 1 et 2...
  • Page 16 CHEESE GRATER HP.1,5 HP.3 CLEANABLE DRAWING 1 INSTRUCTION MANUAL AND HANDBOOK CHEESE GRATER HP.1,5 HP.3 CLEANABLE CE...

  • Page 17: Mechanical Safety

    CHEESE GRATER HP.1,5 HP.3 CLEANABLE DRAWING 3 ELECTRICAL SAFETY MECHANICAL SAFETY INSTRUCTION MANUAL AND HANDBOOK CHEESE GRATER HP.1,5 HP.3 CLEANABLE CE...
  • Page 18 CHEESE GRATER HP.1,5 HP.3 CLEANABLE ELECTRICITY DIAGRAM LEGEND L1 L2 L3 line T1 T2 T3 motor TSCR electronic board transformer INSTRUCTION MANUAL AND HANDBOOK CHEESE GRATER HP.1,5 HP.3 CLEANABLE CE...

  • Page 19: Electrical Diagram

    CHEESE GRATER HP.1,5 HP.3 CLEANABLE ELECTRICAL DIAGRAM INSTRUCTION MANUAL AND HANDBOOK CHEESE GRATER HP.1,5 HP.3 CLEANABLE CE...

  • Page 20: Brake Group

    CHEESE GRATER HP.1,5 HP.3 CLEANABLE NUMERO DESCRIZIONE NUMERO DESCRIZIONE BRAKE GROUP PROTECTION SELF-BLOCKING DICE TRAY WASHER PROBE WHEAT HEADSET BRAKE COVER SPRING ELECTRIC BOX COMMAND DISKS BRAKE FEEDER MALE CONNECTOR ELECTRICAL CABLE MECHANICAL MICRO STATOR BEARING ROTOR BEARING FRONT FLANGE ROLLER FLANGE CHEESE-GRATER ROLLER LEFT THREADED FLANGE...
  • Page 21 CHEESE GRATER HP.1,5 HP.3 CLEANABLE EXPLODED CLEANABLE CHEESE- GRATER INSTRUCTION MANUAL AND HANDBOOK CHEESE GRATER HP.1,5 HP.3 CLEANABLE CE...
  • Page 24 CHEESE GRATER HP.1,5 HP.3 CLEANABLE Van Berkel International S.r.l. Via Ugo Foscolo, 22 20140, Oggiona S. Stefano (VA) – Italy Tel. +39 0331 214 311 info@berkelinternational.com www.theberkelworld.com INSTRUCTION MANUAL AND HANDBOOK CHEESE GRATER HP.1,5 HP.3 CLEANABLE CE...

This manual is also suitable for:

Hp. 3 cleanable
