- Page 1 DeLaval in place ID reader IPR Instruction Book © DeLaval 2021. 89380401 2021-12-17, Version 6 Original instruction...
-
Page 3: Table Of Contents
DeLaval in place ID reader IPR Table of contents EU Declaration of Conformity - DeLaval in place ID reader IPR............. 5 Safety precautions..........................7 DeLaval in place ID reader IPR Foreword........................... 7 Disclaimer......................... 7 Definitions of admonishments................... 7 Safety regulations......................8 Safety regulations - General................ - Page 4 DeLaval in place ID reader IPR Table of contents © DeLaval 2021. 2021-12-17, Version 6 4 (22) 89380401...
-
Page 5: Eu Declaration Of Conformity - Delaval In Place Id Reader Ipr
EU Declaration of Conformity Name of product: DeLaval in place ID reader IPR Type/model: Report No. D0000106871 The product complies with requirements of the following directives: Restriction of the use of certain hazardous substances (RoHS) - 2011/65/EU Radio equipment directive RED 2014/53/EU Harmonized standards which have been used or parts thereof: EN 300 220-2 V2.4.1: 2012... - Page 6 Name and address of manufacturer: DeLaval International AB P.O. Box 39 SE 147 21 TUMBA Sweden © DeLaval 2021. 2021-12-17, Version 6 6 (22) 89380401...
-
Page 7: Safety Precautions
2 Disclaimer The information, instructions and parts listed are applicable and current on the date when issued. DeLaval reserves the right to make changes with- out notice. 3 Definitions of admonishments Admonishments are safety related warning mes- sages. -
Page 8: Safety Regulations
DeLaval in place ID reader IPR Safety precautions Note! Is intended to draw attention to specific points of importance in the text and advice to prevent equipment damage. This symbol signals risk of injury. This symbol signals risk of electric shock. -
Page 9: Compliance With National Regulations
DeLaval in place ID reader IPR Safety precautions Prohibited! Do not use inadequate parts or consumables. Using products which do not meet specified requirements, for example spare parts or consumables, or not appropriately trained personnel for the DeLaval product may lead to risks or damage. -
Page 10: Ised Compliance Statement
Ä Chapter 1 " Dis- posal and recycling information " on page 19. 7 Warranty Note! DeLaval will not take any responsibility for damage resulting from faulty installation, opera- tion, or for improper or inadequate care and maintenance. -
Page 11: Regulatory Compliance
DeLaval in place ID reader IPR Safety precautions 8 Regulatory compliance For more information on regulatory compliance, http://www.delavalcorporate.com/sustainability/ our-operations/regulatory-Compliance/. © DeLaval 2021. 2021-12-17, Version 6 11 (22) 89380401... -
Page 12: General Description
DeLaval in place ID reader IPR General description General description DeLaval in place ID reader IPR 1 Introduction DeLaval in place ID reader IPR identifies animals with B-transponders (for the neck), or with ISO transponders (HDX and FDX transponders for the ear). Fig. 2: B-transponder. - Page 13 DeLaval in place ID reader IPR General description The IPR is designed for various applications, including milking systems and feeding systems. The reader sends the scanned data to a receiving unit, for example, a milking station controller, when a transponder is within the range of the reader.
-
Page 14: Technical Data
70°C during storage) Minimum ambient humidity 27.5 Maximum ambient humidity Fig. 4: DeLaval in place ID reader IPR dimensions. Article number Description Type of animal transponder 2150015681 DeLaval in place ID reader IPR H/F ISO (HDX+FDX) 2150015688 DeLaval in place ID reader IPR B B-Transponder ©... - Page 15 DeLaval in place ID reader IPR General description Wire description for 2150015681/2150015688 and 2150009406/2150009407 IPR wire number MPC connection terminal for rod reader Function 12-24V DC Black Ground Green Data White Synchronization Wire description for 87486380 and 87486381 IPR wire colour...
-
Page 16: Planning
Planning DeLaval in place ID reader IPR 1 Suggested configuration layout DeLaval in place ID reader IPR is fastened directly with four bolts on the metal surface with- out the need for additional protection. However, the associated cable must be well protected. -
Page 17: Reading Volume
FDX), see Fig. 6 and Fig. 7. Note! Metal objects close to the reader may impact the reading volume (reading perform- ance). The DeLaval in place ID reader IPR is capable of handling different positions (angles) of the trans- ponder, which guarantees a highly accurate reading. -
Page 18: Troubleshooting
DeLaval in place ID reader IPR Troubleshooting Troubleshooting DeLaval in place ID reader IPR 1 Problems with the in-place reader (IPR) Symptom Cause Action Decreased reading distance. Disturbances caused by metal Remove all metal objects objects placed near the reader. -
Page 19: Disposal
DeLaval in place ID reader IPR Disposal Disposal DeLaval in place ID reader IPR 1 Disposal and recycling informa- tion When the product reaches end of life, dispose it properly in accordance with local laws and regu- lations. 1.1 Disposal of packaging material (Packaging EU Directive 94/62/EC) This symbol indicates that the product’s packag-... - Page 20 DeLaval in place ID reader IPR Disposal © DeLaval 2021. 2021-12-17, Version 6 20 (22) 89380401...
- Page 21 Tetra Laval Holdings & Finance S. A. and DeLaval is a registered trade/service mark of DeLaval Holding AB.
- Page 22 DeLaval International AB www.delaval.com Box 39 SE-147 21 Tumba SWEDEN...
