6. Operation and maintenance
6.1 Pressure regulators have always to be protected against damage
(visual inspections in regular intervals).
6.2 Pay attention to a perfect status of seals, sealing surfaces and pressure gauges.
!
6.3 In case of malfunctions, e. g. an increase in the outlet pressure during the supply, or
in case of leakage versus atmosphere or a defective pressure gauge, shut down the
upstream gas supply and take the pressure regulator out of operation.
7. Shut-down
7.1 For short-term interruption of work
Close the shut-off valve at the comsumer unit.
7.2 For longer interruptions or at the end of the work:
Close the gas cylinder valve and the shut-off valve at the consumer unit.
! 7.3 Before disassembly pay attention that pressure gauges and indicate zero.
8. Repair
8.1 Repairs may only be carried out in authorized workshops by expert persons.
8.2 Only original spare parts may be used.
type in each instance. So always specify the gas type.
8.3 In case of unauthorized repairs or use of non-original spare parts, any form of
liability for resulting damages will expire as well as the manufacturer's warranty.
8.4 After beeing repaired, the pressure regulator must be checked
proper function, leak-tightness and cleanliness of the gas-wetted surfaces.
9. Dimensions
LE 61
P P
V H
P
V
104
GES_LE61-71-81 Edition 0211
Subject to alteration without prior notice
© Spectron Gas Control Systems GmbH
- 4 -
The materials have been adapted to the gas
with respect to
LE 71 LE 81
P
V
P
H
144
134
Instructions for use
LE 61, LE 71, LE 81
pressure regulator
Contents
1. Application
1.1 Designated use
1.2 Non-designated use
1.3 Technical data
2. Safety instructions
3. Labelling
4. Installation
5. Start-up
6. Operation and maintenance
7. Shut-down
8. Repair
9. Dimensions
1. Application
1.1 Designated use
Use the pressure regulator for gases dissolved under pressure, compressed or
liqufied gases. The pressure regulator LE 61, LE 71 and LE 81 reduce an inlet
pressure to an as constant as possible outlet pressure.
1.2 Non-designated use
!
Do not use the pressure regulator for gases in the liquid phase.
! Do not use the pressure regulator for unsuitable gas types or caustic gases.
1.3 Technical data
Materials:
Body:
P
H
Diaphragms:
Gas-wetted parts:
Valve seat:
Surface roughness:
optional:
Leak rate:
to atmosphere:
via valve seat:
The system has to be used according to these operating instructions and especially
spectro pur
page
1
1
1
2
2
3
3
3
4
4
4
4
Temperature: -30°C to +60°C
SS 1.4404 ESU/VAR Inlet pressure max. 200 bar
(SS 316L remelted) Max. Outlet pressure: 1,5 / 4 / 10 bar
Hastelloy C276 Flow rate: s. Flow curves
SS 1.4404 ESU/VAR C -value: c = 0,15
v
(SS 316L remelted) Weight: LE 61 1,4 kg
PCTFE
LE 71 1,5 kg
R <0,25 µm (standard) LE 81 1,7 kg
a
R <0,18 µm (e-polished) Connectors In-/Outlet:
a
•1/4" VCR-Female •1/4" VCR-Male (fixed)
-9
< 1x10 mbar l/s He •1/4" VCR-Male •others upon request
-6
< 1x10 mbar l/s He
the safety instructions!
- 1 -
v
